Pll Unit - Icom IC-M710 Service Manual

[MAIN UNIT]
REF ORDER
NO. NO.
W18 7030003860 S.RESISTOR
W23 7030003860 S.RESISTOR
W24 7030003860 S.RESISTOR
W25 7030003860 S.RESISTOR
W27 7030003860 S.RESISTOR
W30 7030003860 S.RESISTOR
W31 7030003860 S.RESISTOR
W33 7030003860 S.RESISTOR
W34 7030003860 S.RESISTOR
EP1 0910049858 PCB

[PLL UNIT]

REF ORDER
NO. NO.
IC3001 1140007880 S.IC
IC3002 1140004550 S.IC
IC3003 1180001070 S.IC
IC3004 1130004830 S.IC
IC3005 1130007660 S.IC
IC3006 1130004830 S.IC
IC3008 1130004830 S.IC
Q3001 1530002600 S.TRANSISTOR
Q3002 1530002600 S.TRANSISTOR
Q3003 1560000720 S.FET
Q3004 1530002600 S.TRANSISTOR
Q3005 1560000330 S.FET
Q3006 1530002690 S.TRANSISTOR
Q3007 1530002600 S.TRANSISTOR
Q3008 1530002600 S.TRANSISTOR
Q3010 1530002690 S.TRANSISTOR
Q3011 1530002600 S.TRANSISTOR
Q3021 1530002600 S.TRANSISTOR
Q3022 1590001330 S.TRANSISTOR
Q3024 1530002600 S.TRANSISTOR
Q3025 1530002690 S.TRANSISTOR
D3001 1750000270 S.DIODE
D3002 1750000270 S.DIODE
D3003 1790000540 S.VARICAP
D3004 1720000670 S.VARICAP
D3005 1750000070 S.DIODE
D3015 1790000490 S.DIODE
D3016 1790000490 S.DIODE
D3020 1720000670 S.VARICAP
FI3001 2020001140 S.CERAMIC
X3001 6050011400 XTAL
L3001 6200001830 S.COIL
L3002 6170000230 COIL
L3003 6150004370 COIL
L3004 6150004250 COIL
L3005 6150004250 COIL
L3007 6200003260 S.COIL
L3008 6180001220 COIL
L3009 6200003260 S.COIL
L3010 6200003100 S.COIL
L3012 6200003260 S.COIL
L3013 6130001850 COIL
L3015 6200001830 S.COIL
L3016 6200003260 S.COIL
L3017 6200001830 S.COIL
L3019 6200001830 S.COIL
L3020 6170000180 COIL
L3021 6170000230 COIL
L3022 6200003260 S.COIL
L3023 6200003260 S.COIL
[GEN]: [GEN-21], [GEN-22], [GEN-23]
[GMDSS]: [GEN-23], [EUR-22]
DESCRIPTION
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V [EUR]
ERJ3GE JPW V [EUR]
ERJ3GE JPW V
ERJ3GE JPW V [GEN], [EUR-21]
B 4248R
DESCRIPTION
TC190G08AF-0046-Z/SC-1246A
M65343FP/SC1287
TA7805F (TE16L)
TC7SU04F (TE85R)
LC7153M-TLM
TC7SU04F (TE85R)
TC7SU04F (TE85R)
2SC4215-O (TE85R)
2SC4215-O (TE85R)
2SK2171-4-TD
2SC4215-O (TE85R)
2SK210-GR (TE85R)
2SC4116-GR (TE85R)
2SC4215-O (TE85R)
2SC4215-O (TE85R)
2SC4116-GR (TE85R)
2SC4215-O (TE85R)
2SC4215-O (TE85R)
DTA114EUA T106
2SC4215-O (TE85R)
2SC4116-GR (TE85R)
1SS301 (TE85R)
1SS301 (TE85R)
MA338 (TX)
HVU17TRF
1SS226 (TE85R)
HSM88AS-TR
HSM88AS-TR
HVU17TRF
SFECA10.7MA5-A-TC
CR-282. (30.00000 MHz)
NL 322522T-100J
LW-25
LS-472C (C-15045)
LS-471A (C-14922)
LS-471A (C-14922)
NL 322522T-101J
LAL 04NA 100K
NL 322522T-101J
NL 322522T-3R9J-3
NL 322522T-101J
LB-185
NL 322522T-100J
NL 322522T-101J
NL 322522T-100J
NL 322522T-100J
LW-19
LW-25
NL 322522T-101J
NL 322522T-101J
[EUR]: [EUR-21], [EUR-22]
[Others]: [GEN-21], [GEN-22], [EUR-21]
[PLL UNIT]
REF ORDER
NO. NO.
L3024 6190001550 COIL
L3026 6200003260 S.COIL
L3028 6200003260 S.COIL
L3035 6200003430 S.COIL
L3036 6200003430 S.COIL
L3037 6200003120 S.COIL
L3038 6200001830 S.COIL
L3040 6200003320 S.COIL
L3041 2040000490 COIL
L3042 2040000490 COIL
L3043 6200003420 S.COIL
L3044 6200003430 S.COIL
L3045 6180000880 COIL
L3046 6200001830 S.COIL
L3047 6200001830 S.COIL
R3001 7030003580 S.RESISTOR
R3002 7030003520 S.RESISTOR
R3003 7030003400 S.RESISTOR
R3005 7030003280 S.RESISTOR
R3006 7030003320 S.RESISTOR
R3007 7030003600 S.RESISTOR
R3008 7030003560 S.RESISTOR
R3009 7030003360 S.RESISTOR
R3010 7070000820 RESISTOR
R3011 7030003320 S.RESISTOR
R3012 7030003440 S.RESISTOR
R3014 7030003800 S.RESISTOR
R3017 7030003440 S.RESISTOR
R3018 7030003430 S.RESISTOR
R3019 7030003340 S.RESISTOR
R3020 7030005400 S.RESISTOR
R3021 7030005400 S.RESISTOR
R3022 7030005390 S.RESISTOR
R3023 7030005400 S.RESISTOR
R3024 7030005390 S.RESISTOR
R3025 7030005400 S.RESISTOR
R3026 7030005390 S.RESISTOR
R3027 7030005400 S.RESISTOR
R3028 7030005390 S.RESISTOR
R3029 7030005400 S.RESISTOR
R3030 7030005390 S.RESISTOR
R3031 7030005400 S.RESISTOR
R3032 7030005390 S.RESISTOR
R3033 7030005400 S.RESISTOR
R3034 7030005380 S.RESISTOR
R3035 7030005370 S.RESISTOR
R3036 7030005380 S.RESISTOR
R3037 7030005370 S.RESISTOR
R3038 7030005380 S.RESISTOR
R3039 7030005370 S.RESISTOR
R3040 7030005380 S.RESISTOR
R3041 7030005370 S.RESISTOR
R3042 7030005380 S.RESISTOR
R3043 7030005370 S.RESISTOR
R3044 7030003380 S.RESISTOR
R3045 7030003800 S.RESISTOR
R3046 7030003570 S.RESISTOR
R3048 7030003360 S.RESISTOR
R3050 7030003360 S.RESISTOR
R3052 7030003340 S.RESISTOR
R3053 7030003270 S.RESISTOR
R3054 7030003340 S.RESISTOR
R3055 7030003320 S.RESISTOR
R3056 7030003650 S.RESISTOR
R3057 7030003360 S.RESISTOR
R3058 7030003250 S.RESISTOR
R3060 7030003320 S.RESISTOR
R3061 7030003680 S.RESISTOR
R3062 7030003680 S.RESISTOR
R3063 7030003340 S.RESISTOR
R3064 7030003690 S.RESISTOR
R3065 7030003320 S.RESISTOR
R3066 7030003400 S.RESISTOR
R3067 7030003400 S.RESISTOR
R3068 7030003320 S.RESISTOR
R3069 7030003480 S.RESISTOR
R3070 7030003400 S.RESISTOR
R3071 7030003320 S.RESISTOR
R3072 7030003640 S.RESISTOR
R3074 7030003600 S.RESISTOR
5 - 12
DESCRIPTION
MC138-E544GN-110272
NL 322522T-101J
NL 322522T-101J
NL 322522T-R10J
NL 322522T-R10J
NL 322522T-8R2J
NL 322522T-100J
NL 322522T-3R3J-3
EXC-ELDR25C
EXC-ELDR25C
NL 322522T-R15J-3
NL 322522T-R10J
LAL 03NA 100K
NL 322522T-100J
NL 322522T-100J
Ω
ERJ3GEYJ 153 V (15 k )
Ω
ERJ3GEYJ 472 V (4.7 k )
Ω
ERJ3GEYJ 471 V (470 )
Ω
ERJ3GEYJ 470 V (47 )
Ω
ERJ3GEYJ 101 V (100 )
Ω
ERJ3GEYJ 223 V (22 k )
Ω
ERJ3GEYJ 103 V (10 k )
Ω
ERJ3GEYJ 221 V (220 )
Ω
ERG1SJ 220 (22 )
Ω
ERJ3GEYJ 101 V (100 )
Ω
ERJ3GEYJ 102 V (1 k )
Ω
ERJ3GEYJ 105 V (1 M )
Ω
ERJ3GEYJ 102 V (1 k )
Ω
ERJ3GEYJ 821 V (820 )
Ω
ERJ3GEYJ 151 V (150 )
Ω
RR0816P-202-D (2 k )
Ω
RR0816P-202-D (2 k )
Ω
RR0816P-102-D (1 k )
Ω
RR0816P-202-D (2 k )
Ω
RR0816P-102-D (1 k )
Ω
RR0816P-202-D (2 k )
Ω
RR0816P-102-D (1 k )
Ω
RR0816P-202-D (2 k )
Ω
RR0816P-102-D (1 k )
Ω
RR0816P-202-D (2 k )
Ω
RR0816P-102-D (1 k )
Ω
RR0816P-202-D (2 k )
Ω
RR0816P-102-D (1 k )
Ω
RR0816P-202-D (2 k )
Ω
RR0816P-102-B (1 k )
Ω
RR0816P-202-B (2 k )
Ω
RR0816P-102-B (1 k )
Ω
RR0816P-202-B (2 k )
Ω
RR0816P-102-B (1 k )
Ω
RR0816P-202-B (2 k )
Ω
RR0816P-102-B (1 k )
Ω
RR0816P-202-B (2 k )
Ω
RR0816P-102-B (1 k )
Ω
RR0816P-202-B (2 k )
Ω
ERJ3GEYJ 331 V (330 )
Ω
ERJ3GEYJ 105 V (1 M )
Ω
ERJ3GEYJ 123 V (12 k )
Ω
ERJ3GEYJ 221 V (220 )
Ω
ERJ3GEYJ 221 V (220 )
Ω
ERJ3GEYJ 151 V (150 )
Ω
ERJ3GEYJ 390 V (39 )
Ω
ERJ3GEYJ 151 V (150 )
Ω
ERJ3GEYJ 101 V (100 )
Ω
ERJ3GEYJ 563 V (56 k )
Ω
ERJ3GEYJ 221 V (220 )
Ω
ERJ3GEYJ 270 V (27 )
Ω
ERJ3GEYJ 101 V (100 )
Ω
ERJ3GEYJ 104 V (100 k )
Ω
ERJ3GEYJ 104 V (100 k )
Ω
ERJ3GEYJ 151 V (150 )
Ω
ERJ3GEYJ 124 V (120 k )
Ω
ERJ3GEYJ 101 V (100 )
Ω
ERJ3GEYJ 471 V (470 )
Ω
ERJ3GEYJ 471 V (470 )
Ω
ERJ3GEYJ 101 V (100 )
Ω
ERJ3GEYJ 222 V (2.2 k )
Ω
ERJ3GEYJ 471 V (470 )
Ω
ERJ3GEYJ 101 V (100 )
Ω
ERJ3GEYJ 473 V (47 k )
Ω
ERJ3GEYJ 223 V (22 k )
S.=Surface mount
