Icom IC-M710 Service Manual page 36

[FILTER BOARD]
REF ORDER
NO. NO.
L4331 6180000900 COIL
L4332 6140003580 COIL
L4333 6140002290 COIL
L4334 6180000900 COIL
L4335 6180000900 COIL
L4336 6140002890 COIL
L4337 6140002890 COIL
L4338 6180000900 COIL
L4339 6180000900 COIL
L4340 6180000900 COIL
L4341 6140002530 COIL
L4342 6140001460 COIL
L4343 6180000900 COIL
L4344 6180000900 COIL
L4345 6140002830 COIL
L4346 6140003570 COIL
R4301 7010004372 RESISTOR
R4302 7010007240 RESISTOR
R4303 7010006980 RESISTOR
R4304 7010007240 RESISTOR
R4305 7010007180 RESISTOR
R4306 7010006980 RESISTOR
R4307 7010004701 RESISTOR
R4308 7010000911 RESISTOR
R4309 7540000010 ABSORBER
R4312 7010004272 RESISTOR
R4313 7010007140 RESISTOR
R4314 7010007290 RESISTOR
C4301 4020000980 CYLINDER
C4302 4320000651 DIP MICA
C4303 4010006410 CERAMIC
C4304 4010006410 CERAMIC
C4305 4320000981 DIP MICA
C4306 4010005360 CERAMIC
C4307 4010005880 CERAMIC
C4308 4320000951 DIP MICA
C4309 4010005850 CERAMIC
C4310 4010005480 CERAMIC
C4311 4010005930 CERAMIC
C4312 4010005930 CERAMIC
C4313 4010005370 CERAMIC
C4314 4010005930 CERAMIC
C4315 4020000980 CYLINDER
C4316 4020000980 CYLINDER
C4317 4010005690 CERAMIC
C4318 4010005370 CERAMIC
C4319 4010006410 CERAMIC
C4320 4010005370 CERAMIC
C4321 4010005880 CERAMIC
C4322 4010005880 CERAMIC
C4323 4010005880 CERAMIC
C4324 4010006410 CERAMIC
C4325 4010006410 CERAMIC
C4326 4010006410 CERAMIC
C4327 4010005880 CERAMIC
C4328 4010005370 CERAMIC
C4329 4010005370 CERAMIC
C4330 4010006410 CERAMIC
C4331 4010005930 CERAMIC
C4332 4010005370 CERAMIC
C4333 4010005820 CERAMIC
C4334 4010005820 CERAMIC
C4335 4010005930 CERAMIC
C4336 4010005930 CERAMIC
C4337 4010005750 CERAMIC
C4338 4020000980 CYLINDER
C4339 4010006900 CERAMIC
C4340 4010005870 CERAMIC
C4341 4010005370 CERAMIC
C4342 4010005370 CERAMIC
C4343 4010005930 CERAMIC
C4344 4010005830 CERAMIC
C4345 4010005370 CERAMIC
C4346 4010006410 CERAMIC
C4347 4010005780 CERAMIC
C4348 4010005360 CERAMIC
C4349 4010006900 CERAMIC
C4350 4010006900 CERAMIC
[GEN]: [GEN-21], [GEN-22], [GEN-23]
[GMDSS]: [GEN-23], [EUR-22]
DESCRIPTION
LAL 03NA 101K
LR-399 (3.5%)
LR-242L4334
LAL 03NA 101K
LAL 03NA 101K
LR-262 <KN>
LR-262 <KN>
LAL 03NA 101K
LAL 03NA 101K
LAL 03NA 101K
LR-291 (TR10X5X5 3A6)
LR-170
LAL 03NA 101K
LAL 03NA 101K
LR-236 <KN>
LR-398 (3.5%)
Ω
PSD1/4 22 k
Ω
PSD1/4V 100 K
Ω
PSD1/4 10 K
Ω
PSD1/4V 100 K
Ω
PSD1/4V 22 K
Ω
PSD1/4 10 K
Ω
PSD1/2 68
Ω
R25X T-24J 10
DSA-301LA
Ω
PSD1/4 4.7 k
Ω
PSD1/4V 4.7K
Ω
PSD1/4V 1 M
UP050 B 104K-NA-CZ
KD20C 102J5A
HM13SJ SL 471J 500V
HM13SJ SL 471J 500V
KD20C 222J5A
HM11SJ SL 301J 500V
HM95SJ SL 271J 500V
KD20C 272J5A
HM95SJ SL 181J 500V
HM60SJ CH 100D 500V
HM11SJ SL 391J 500V
HM11SJ SL 391J 500V
HM11SJ SL 331J 500V
HM11SJ SL 391J 500V
UP050 B 104K-NA-CZ
UP050 B 104K-NA-CZ
HM60SJ SL 300J 500V
HM11SJ SL 331J 500V
HM13SJ SL 471J 500V
HM11SJ SL 331J 500V
HM95SJ SL 271J 500V
HM95SJ SL 271J 500V
HM95SJ SL 271J 500V
HM13SJ SL 471J 500V
HM13SJ SL 471J 500V
HM13SJ SL 471J 500V
HM95SJ SL 271J 500V
HM11SJ SL 331J 500V
HM11SJ SL 331J 500V
HM13SJ SL 471J 500V
HM11SJ SL 391J 500V
HM11SJ SL 331J 500V
HM74SJ SL 121J 500V
HM74SJ SL 121J 500V
HM11SJ SL 391J 500V
HM11SJ SL 391J 500V
HM60SJ SL 680J 500V
UP050 B 104K-NA-CZ
HE80SJ YB 472K 50V
HM95SJ SL 221J 500V
HM11SJ SL 331J 500V
HM11SJ SL 331J 500V
HM11SJ SL 391J 500V
HM74SJ SL 151J 500V
HM11SJ SL 331J 500V
HM13SJ SL 471J 500V
HM60SJ SL 101J 500V
HM11SJ SL 301J 500V
HE80SJ YB 472K 50V
HE80SJ YB 472K 50V
[EUR]: [EUR-21], [EUR-22]
[Others]: [GEN-21], [GEN-22], [EUR-21]
[FILTER BOARD]
REF ORDER
NO. NO.
C4351 4010005850 CERAMIC
C4352 4010005370 CERAMIC
C4353 4010005820 CERAMIC
C4354 4010005880 CERAMIC
C4355 4010005360 CERAMIC
C4356 4010005740 CERAMIC
C4357 4010005560 CERAMIC
C4358 4010005360 CERAMIC
C4359 4010006900 CERAMIC
C4360 4010006900 CERAMIC
C4361 4010005930 CERAMIC
C4362 4010005820 CERAMIC
C4363 4010005930 CERAMIC
C4364 4010005770 CERAMIC
C4365 4010005870 CERAMIC
C4366 4010006900 CERAMIC
C4367 4010006900 CERAMIC
C4368 4010005880 CERAMIC
C4369 4010008600 CERAMIC
C4370 4010005370 CERAMIC
C4371 4010005750 CERAMIC
C4372 4010005770 CERAMIC
C4373 4010006900 CERAMIC
C4374 4010006900 CERAMIC
C4377 4010005860 CERAMIC
C4378 4010008610 CERAMIC
C4379 4010005870 CERAMIC
C4380 4010006900 CERAMIC
C4381 4010006900 CERAMIC
C4382 4010005830 CERAMIC
C4383 4010005660 CERAMIC
C4384 4010005360 CERAMIC
C4385 4010008610 CERAMIC
C4386 4010005830 CERAMIC
C4387 4010006900 CERAMIC
C4388 4010006850 CERAMIC
C4389 4010006850 CERAMIC
C4390 4010006380 CERAMIC
C4391 4010006380 CERAMIC
C4392 4610002240 TRIMMER
C4393 4010006310 CERAMIC
C4394 4010006900 CERAMIC
C4395 4010006900 CERAMIC
C4396 4010006900 CERAMIC
C4398 4010007600 CERAMIC
C4399 4010007600 CERAMIC
C4400 4010006280 CERAMIC
C4401 4010006110 CERAMIC
C4402 4010006280 CERAMIC
C4404 4010006900 CERAMIC
C4406 4020000990 CYLINDER
C4407 4510006160 ELECTROLYTIC
C4408 4010005730 CERAMIC
C4409 4010005480 CERAMIC
C4410 4010005820 CERAMIC
C4411 4010005480 CERAMIC
C4412 4010005770 CERAMIC
C4413 4010005740 CERAMIC
C4414 4010005480 CERAMIC
C4415 4010005780 CERAMIC
C4416 4010006900 CERAMIC
C4417 4010005780 CERAMIC
C4420 4010005770 CERAMIC
C4421 4010005660 CERAMIC
C4422 4510005480 ELECTROLYTIC
C4423 4510005480 ELECTROLYTIC
C4424 4510005480 ELECTROLYTIC
C4425 4510005480 ELECTROLYTIC
C4426 4510005480 ELECTROLYTIC
C4427 4510005480 ELECTROLYTIC
C4428 4510005480 ELECTROLYTIC
C4429 4010005640 CERAMIC
C4430 4010006900 CERAMIC
C4431 4010005480 CERAMIC
RL4301 330001570 RELAY
RL4302 6330001570 RELAY
RL4303 6330001570 RELAY
RL4304 6330001570 RELAY
RL4305 6330001570 RELAY
RL4306 6330001570 RELAY
5 - 15
DESCRIPTION
HM95SJ SL 181J 500V
HM11SJ SL 331J 500V
HM74SJ SL 121J 500V
HM95SJ SL 271J 500V
HM11SJ SL 301J 500V
HM60SJ SL 560J 500V
HM60SJ SL 050C 500V
HM11SJ SL 301J 500V
HE80SJ YB 472K 50V
HE80SJ YB 472K 50V
HM11SJ SL 391J 500V
HM74SJ SL 121J 500V
HM11SJ SL 391J 500V
HM60SJ SL 820J 500V
HM95SJ SL 221J 500V
HE80SJ YB 472K 50V
HE80SJ YB 472K 50V
HM95SJ SL 271J 500V
HP74SJ SL 101J 1KV
HM11SJ SL 331J 500V
HM60SJ SL 680J 500V
HM60SJ SL 820J 500V
HE80SJ YB 472K 50V
HE80SJ YB 472K 50V
HM95SJ SL 201J 500V
HP60SJ SL 470J 1KV
HM95SJ SL 221J 500V
HE80SJ YB 472K 50V
HE80SJ YB 472K 50V
HM74SJ SL 151J 500V
HM60SJ SL 220J 500V
HM11SJ SL 301J 500V
HP60SJ SL 470J 1KV
HM74SJ SL 151J 500V
HE80SJ YB 472K 50V
HE40SJ YB 471K 50V
HE40SJ YB 471K 50V
HE90SJ SL 471J 50V
HE90SJ SL 471J 50V
ECR-LA030E52
HE60SJ SL 181J 50V
HE80SJ YB 472K 50V
HE80SJ YB 472K 50V
HE80SJ YB 472K 50V
HM17SJ YB 103K 500V
HM17SJ YB 103K 500V
HE50SJ SL 101J 50V
HE40SJ SL 180J 50V
HE50SJ SL 101J 50V
HE80SJ YB 472K 50V
UP050 B 473K-NA-CZ
25 MV 10 HC
HM60SJ SL 470J 500V
HM60SJ CH 100D 500V
HM74SJ SL 121J 500V
HM60SJ CH 100D 500V
HM60SJ SL 820J 500V
HM60SJ SL 560J 500V
HM60SJ CH 100D 500V
HM60SJ SL 101J 500V
HE80SJ YB 472K 50V
HM60SJ SL 101J 500V
HM60SJ SL 820J 500V
HM60SJ SL 220J 500V
50 MV 1 HC
50 MV 1 HC
50 MV 1 HC
50 MV 1 HC
50 MV 1 HC
50 MV 1 HC
50 MV 1 HC
HM60SJ SL 180J 500V
HE80SJ YB 472K 50V
HM60SJ CH 100D 500V
AJS1315
AJS1315
AJS1315
AJS1315
AJS1315
AJS1315
S.=Surface mount
