Icom IC-M710 Service Manual page 38

[PA150W BOARD]
REF ORDER
NO. NO.
R4049 7010000281 RESISTOR
R4050 7010000411 RESISTOR
R4051 7030000340 S.RESISTOR
R4052 7030000150 S.RESISTOR
R4053 7030000340 S.RESISTOR
C4003 4010005360 CERAMIC
C4004 4010005360 CERAMIC
C4006 4310000360 MYLAR
C4007 4310000360 MYLAR
C4008 4030005050 S.CERAMIC
C4010 4030011760 S.CERAMIC
C4011 4030011760 S.CERAMIC
C4012 4010006410 CERAMIC
C4013 4030018370 S.CERAMIC
C4014 4030018370 S.CERAMIC
C4015 4030011760 S.CERAMIC
C4016 4030011760 S.CERAMIC
C4018 4030004740 S.CERAMIC
C4019 4030004740 S.CERAMIC
C4020 4510005120 ELECTROLYTIC
C4021 4510004990 ELECTROLYTIC
C4022 4030005110 S.CERAMIC
C4023 4510004510 ELECTROLYTIC
C4024 4030005110 S.CERAMIC
C4026 4510006160 ELECTROLYTIC
C4027 4030004740 S.CERAMIC
C4028 4510004600 ELECTROLYTIC
C4029 4030005110 S.CERAMIC
C4030 4030005110 S.CERAMIC
C4031 4030005110 S.CERAMIC
C4032 4030004990 S.CERAMIC
C4033 4030011790 S.CERAMIC
C4034 4030004740 S.CERAMIC
C4035 4510005040 ELECTROLYTIC
C4036 4030004740 S.CERAMIC
C4038 4030004740 S.CERAMIC
C4041 4030008960 S.CERAMIC
C4042 4030008960 S.CERAMIC
C4043 4030008960 S.CERAMIC
C4044 4030008960 S.CERAMIC
C4045 4320000961 DIP MICA
C4046 4030004740 S.CERAMIC
C4047 4030004740 S.CERAMIC
C4048 4030004740 S.CERAMIC
C4050 4510005040 ELECTROLYTIC
C4051 4510004590 ELECTROLYTIC
C4052 4510006160 ELECTROLYTIC
C4053 4030004740 S.CERAMIC
C4054 4030004740 S.CERAMIC
C4055 4030018370 S.CERAMIC
C4056 4030004740 S.CERAMIC
C4057 4320000811 DIP MICA
C4059 4030004740 S.CERAMIC
C4063 4510004590 ELECTROLYTIC
C4064 4030005030 S.CERAMIC
C4065 4020000990 CYLINDER
C4066 4020000990 CYLINDER
C4067 4010008570 CERAMIC
C4068 4030004740 S.CERAMIC
C4069 4030005110 S.CERAMIC
C4070 4030004720 S.CERAMIC
C4071 4030004930 S.CERAMIC
C4072 4030008960 S.CERAMIC
C4073 4030008960 S.CERAMIC
C4074 4030008960 S.CERAMIC
C4075 4030008960 S.CERAMIC
C4076 4030008960 S.CERAMIC
C4077 4030004720 S.CERAMIC
C4078 4030008960 S.CERAMIC
C4079 4030004990 S.CERAMIC
C4080 4040000260 BARRIERLAYR
C4081 4040000260 BARRIERLAYR
J4002 6510007020 CONNECTOR
J4003 6510018381 CONNECTOR
J4004 6510003080 CONNECTOR
J4005 6510003080 CONNECTOR
[GEN]: [GEN-21], [GEN-22], [GEN-23]
[GMDSS]: [GEN-23], [EUR-22]
DESCRIPTION
Ω
PSN1/4V 180
Ω
PSN1/4V 2.2 k
Ω
MCR10EZHJ 470 (471)
Ω
MCR10EZHJ 12 (120)
Ω
MCR10EZHJ 470 (471)
HM11SJ SL 301J 500V
HM11SJ SL 301J 500V
50 F2D 103J
50 F2D 103J
C2012 CH 1H 331J-T
GRM55R1X2D682JV01L
GRM55R1X2D682JV01L
HM13SJ SL 471J 500V
ERF22X 6C1H 102J D01L
ERF22X 6C1H 102J D01L
GRM55R1X2D682JV01L
GRM55R1X2D682JV01L
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
16 MV 47 HC
16 MV 100 HC
C2012 JB 1E 473K-T
25 MV 470 HC
C2012 JB 1E 473K-T
25 MV 10 HC
C2012 JB 1H 472K-T
16 MV 1000 HC
C2012 JB 1E 473K-T
C2012 JB 1E 473K-T
C2012 JB 1E 473K-T
C2012 CH 1H 101J-T
GRM55RF52A684ZD01L
C2012 JB 1H 472K-T
25 MV 1000 HC
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
C2012 JB 1C 104K-T
C2012 JB 1C 104K-T
C2012 JB 1C 104K-T
C2012 JB 1C 104K-T
KD20C 472J5A
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
25 MV 1000 HC
16 MV 470 HC
25 MV 10 HC
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
ERF22X 6C1H 102J D01L
C2012 JB 1H 472K-T
KD20C 681J5A
C2012 JB 1H 472K-T
16 MV 470 HC
C2012 CH 1H 221J-T
UP050 B 473K-NA-CZ
UP050 B 473K-NA-CZ
RPER11H473K2K1A01
C2012 JB 1H 472K-T
C2012 JB 1E 473K-T
C2012 JB 1H 102K-T
C2012 CH 1H 330J-T
C2012 JB 1C 104K-T
C2012 JB 1C 104K-T
C2012 JB 1C 104K-T
C2012 JB 1C 104K-T
C2012 JB 1C 104K-T
C2012 JB 1H 102K-T
C2012 JB 1C 104K-T
C2012 CH 1H 101J-T
UZE 08X 104M
UZE 08X 104M
TMP-J01X-V6
10FE-BT-VK-N
RT01T-1.0B
RT01T-1.0B
[EUR]: [EUR-21], [EUR-22]
[Others]: [GEN-21], [GEN-22], [EUR-21]
[PA150W BOARD]
REF ORDER
NO. NO.
S4001 6910006900 THERMAL
S4002 6910000050 THERMAL
W4001 7120000010 JUMPER
9040300020 WIRE
W4002 7120000010 JUMPER
9040300010 WIRE
W4003 7120000010 JUMPER
9040300020 WIRE
W4004 7120000010 JUMPER
9040300020 WIRE
W4008 9045201001 WIRE
W4009 9045201001 WIRE
W4010 9040401001 JUMPER
W4011 9056000180 WIRE
WS1 8970022030 M.OTHER
WS2 8970022040 M.OTHER
EP4001 0910045048 PCB
EP4003 6910000610 BEAD
EP4004 6910000610 BEAD
EP4006 6910000630 BEAD
EP4008 6510018330 TERMINAL
EP4009 6510018330 TERMINAL
EP4010 9001602001 TUBE
EP4011 9001602001 TUBE
EP4012 9034701901 TUBE
EP4014 9029305901 TUBE
[TERMINAL BOARD]
REF ORDER
NO. NO.
D7001 1710000830 S.DIODE
C7001 4510005980 ELECTROLYTIC
C7002 4010006900 CERAMIC
C7003 4010006890 CERAMIC
C7004 4010006890 CERAMIC
C7005 4010006900 CERAMIC
C7006 4010006900 CERAMIC
C7008 4030001370 S.CERAMIC
C7009 4030001370 S.CERAMIC
C7010 4030001370 S.CERAMIC
J7001 6510010020 CONNECTOR
EP7001 0910044565 PCB
EP7003 6510018330 TERMINAL
EP7004 6510018330 TERMINAL
EP7010 9017680190 TUBE
[EUR]
[EUR]
5 - 17
DESCRIPTION
OHD-3 110M
OHD-3 50M
JPW-02A [Others]
15/08/065/W07/W07 [GMDSS]
JPW-02A [Others]
15/08/065/W07/W07 [GMDSS]
JPW-02A [Others]
15/08/065/W07/W07 [GMDSS]
JPW-02A [Others]
15/08/065/W07/W07 [GMDSS]
74/98/040/X98/X98
74/98/040/X98/X98
74/98/050/X98/X98
74/98/080/X98/X98
SX1632 J LEAD SET (1)
SX1632 1.5D COAXAL TUBE (1)
B 4250H
FSRH050100RN000B
FSRH050100RN000B
FSRH070140RN000B
F4053A
F4053A
IRRAX 0.7 (d) L=10 mm
IRRAX 0.7 (d) L=10 mm
IRRAX 0.7 (d) L=20 mm
IRRAX 1 (d) L=15 mm
DESCRIPTION
DF30SC4M-4072 [GMDSS]
16 MV 4700 HC
HE80SJ YB 472K 50V
HE60SJ YB 222K 50V
HE60SJ YB 222K 50V
HE80SJ YB 472K 50V
HE80SJ YB 472K 50V
GR44 CH 682K [GMDSS]
GR44 CH 682K [GMDSS]
GR44 CH 682K [GMDSS]
RTB-1.5-2F
B 4421E
F4053A
F4053A
10 (d) L=25 mm [Others]
S.=Surface mount
