Icom IC-M710 Service Manual page 39

[REG BOARD]
REF ORDER
NO. NO.
IC8001 1110003070 S.IC
IC8002 1110001820 S.IC
IC8003 1170000290 S.IC
Q8001 1560001180 S.TRANSISTOR
Q8003 1510000800 S.TRANSISTOR
D8002 1790001360 DIODE
D8003 1790001780 DIODE
L8001 5920000450 COIL
L8003 5920000450 COIL
R8001 7030000430 S.RESISTOR
R8002 7030000460 S.RESISTOR
R8003 7030000490 S.RESISTOR
R8004 7030000390 S.RESISTOR
R8005 7030000460 S.RESISTOR
R8006 7030000460 S.RESISTOR
R8007 7030000480 S.RESISTOR
R8008 7030000440 S.RESISTOR
R8009 7030001090 S.RESISTOR
R8010 7030001210 S.RESISTOR
R8011 7030000460 S.RESISTOR
R8012 7030000260 S.RESISTOR
R8013 7310005010 S.RESISTOR
R8014 7030000450 S.RESISTOR
R8015 7030000380 S.RESISTOR
R8016 7030000200 S.RESISTOR
R8019 7030000340 S.RESISTOR
R8020 7030000380 S.RESISTOR
C8001 4510004590 ELECTROLYTIC
C8002 4030005110 S.CERAMIC
C8003 4560000050 CERAMIC
C8004 4510007250 ELECTROLYTIC
C8005 4510007250 ELECTROLYTIC
C8006 4510006160 ELECTROLYTIC
C8007 4310000360 MYLAR
C8008 4030004740 S.CERAMIC
C8009 4510007250 ELECTROLYTIC
C8010 4510007250 ELECTROLYTIC
C8011 4560000050 CERAMIC
C8012 4030004730 S.CERAMIC
C8013 4510006020 ELECTROLYTIC
C8014 4560000050 CERAMIC
C8015 4560000050 CERAMIC
T8001 5920000440 TRANSFORMER
EP8001 0910045073 B4420C SX-1632
[MIC BOARD]
REF ORDER
NO. NO.
J2301 6510021050 CONNECTOR
J2302 6510018381 CONNECTOR
EP2301 0910044821 PCB
[GEN]: [GEN-21], [GEN-22], [GEN-23]
[GMDSS]: [GEN-23], [EUR-22]
DESCRIPTION
µPC494GS-E1
µPC1093T-E1
PS2701-1-F3
2SK2266
2SA1213-Y (TE12R,C)
SF10SC6
MA700
FK-080E-1020
FK-080E-1020
Ω
MCR10EZHJ 2.7 k
Ω
MCR10EZHJ 4.7 k
Ω
MCR10EZHJ 8.2 k
Ω
MCR10EZHJ 1.2 k
Ω
MCR10EZHJ 4.7 k
Ω
MCR10EZHJ 4.7 k
Ω
MCR10EZHJ 6.8 k
Ω
MCR10EZHJ 3.3 k
Ω
MCR50JZHJ 47 (470)
Ω
MCR50JZHJ 470 (471)
Ω
MCR10EZHJ 4.7 k
Ω
MCR10EZHJ 100 (101)
KVSF637AC 102
Ω
MCR10EZHJ 3.9 k
Ω
MCR10EZHJ 1 k
Ω
MCR10EZHJ 33 (330)
Ω
MCR10EZHJ 470 (471)
Ω
MCR10EZHJ 1 k
16 MV 470 HC
C2012 JB 1E 473K-T
D67X5T 1E 684M51
25 MV 1000 AX
25 MV 1000 AX
25 MV 10 HC
50 F2D 103J
C2012 JB 1H 472K-T
25 MV 1000 AX
25 MV 1000 AX
D67X5T 1E 684M51
C2012 JB 1H 222K-T
16 MV 2200 HC
D67X5T 1E 684M51
D67X5T 1E 684M51
TO-25
DESCRIPTION
A28 SOCKET
10FE-BT-VK-N
B 4503A
[EUR]: [EUR-21], [EUR-22]
[Others]: [GEN-21], [GEN-22], [EUR-21]
[VR1 BOARD]
REF ORDER
NO. NO.
R2401 7210002540 VARIABLE
J2401 6510018391 CONNECTOR
EP2401 0910044832 PCB
[VR2 BOARD]
REF ORDER
NO. NO.
R2401 7210002730 VARIABLE
J2501 6510018391 CONNECTOR
EP2501 0910044842 PCB
[PLL-A UNIT] ([GMDSS] only)
PLL REF
NO. NO.
IC3001 1140007880 S.IC
IC3002 1140004550 S.IC
IC3003 1180001070 S.IC
IC3004 1130004830 S.IC
IC3005 1130007660 S.IC
IC3006 1130004830 S.IC
IC3008 1130004830 S.IC
IC3009 1180000420 S.IC
IC3010 1110000960 S.IC
Q3002 1530002600 S.TRANSISTOR
Q3003 1560000720 S.FET
Q3004 1530002600 S.TRANSISTOR
Q3005 1560000330 S.FET
Q3006 1530002690 S.TRANSISTOR
Q3007 1530002600 S.TRANSISTOR
Q3008 1530002600 S.TRANSISTOR
Q3009 1530002690 S.TRANSISTOR
Q3010 1530002690 S.TRANSISTOR
Q3011 1530002600 S.TRANSISTOR
Q3021 1530002600 S.TRANSISTOR
Q3022 1590001330 S.TRANSISTOR
Q3024 1530002600 S.TRANSISTOR
Q3025 1530002690 S.TRANSISTOR
Q3026 1590000680 S.TRANSISTOR
D3001 1750000270 S.DIODE
D3002 1750000270 S.DIODE
D3003 1790000540 S.VARICAP
D3004 1720000670 S.VARICAP
D3005 1750000070 S.DIODE
D3006 1790000620 S.DIODE
D3015 1790000490 S.DIODE
D3016 1790000490 S.DIODE
D3017 1750000270 S.DIODE
D3020 1720000670 S.VARICAP
FI3001 2020001140 S.CERAMIC
X3002 6050011360 XTAL
5 - 18
DESCRIPTION
TP96N937-15F-10KB-1540
06FE-BT-VK-N
B 4367B
DESCRIPTION
TP96N944-15F-10KB-1632
06FE-BT-VK-N
B 4508B
ORDER
DESCRIPTION
TC190G08AF-0046-Z/SC-1246A
M65343FP/SC1287
TA7805F (TE16L)
TC7SU04F (TE85R)
LC7153M-TLM
TC7SU04F (TE85R)
TC7SU04F (TE85R)
TA78L05F (TE12R)
NJM4558M-TE1
2SC4215-O (TE85R)
2SK2171-4-TD
2SC4215-O (TE85R)
2SK210-GR (TE85R)
2SC4116-GR (TE85R)
2SC4215-O (TE85R)
2SC4215-O (TE85R)
2SC4116-GR (TE85R)
2SC4116-GR (TE85R)
2SC4215-O (TE85R)
2SC4215-O (TE85R)
DTA114EUA T106
2SC4215-O (TE85R)
2SC4116-GR (TE85R)
DTC114EUA T106
1SS301 (TE85R)
1SS301 (TE85R)
MA338 (TX)
HVU17D3005
1SS226 (TE85R)
MA77 (TX)
HSM88AS-TR
HSM88AS-TR
1SS301 (TE85R)
HVU17
SFECA10.7MA5-A-TC
CR-612 POCO 30.00000 MHz
S.=Surface mount
