5-3 TRANSMIT ADJUSTMENT (Continued)
• DEVIATION ADJUSTMENTS (Continued)
Select an adjustment item using
ADJUSTMENT
ADJUSTMENT
DV BALANCE
-VHF-
[BAND LOW]
[BAND CENTER]
[BAND HIGH]
[DVR]
-UHF-
[BAND LOW]
[BAND CENTER]
[BAND HIGH]
/
, and then set the adjustment value as specifi ed using [DIAL].
ITEM
1 1) Set the power supply voltage to 7.4 V.
2) Connect a modulation analyzer to the antenna connector through
an attenuator, and then set it as;
HPF
–
LPF
De-emphasis : OFF
Detector
3) No audio signal is applied.
2 • While transmitting, adjust the deviation using [DIAL], and then
push to store the adjustment value.
3
4
5
6
7
OPERATION
: OFF
: 20 kHz
: (P-P)/2
5 - 9
VALUE
–
Minimum
deviation
