5-3 TRANSMIT ADJUSTMENT (Continued)
• TRANSMIT POWER ADJUSTMENT (at 5.5 V)
Select an adjustment item using
ADJUSTMENT
ADJUSTMENT
TRANSMIT
POWER
-VHF-
(BAND LOW)
(BAND HIGH)
-UHF-
(BAND LOW)
(BAND HIGH)
NOTE: When "IDLING CURRENT" is adjusted, "TRANSMIT POWER" must be also re-adjusted.
• TRANSMIT POWER ADJUSTMENT (at 7.4 V)
Select an adjustment item using
ADJUSTMENT
ADJUSTMENT
TRANSMIT POWER
-VHF-
(Hi power)
[BAND LOW]
[BAND HIGH]
-UHF-
(Hi power)
[BAND LOW]
[BAND HIGH]
-VHF-
(Mid power)
[BAND LOW]
[BAND HIGH]
-UHF-
(Mid power)
[BAND LOW]
[BAND HIGH]
-VHF-
(Low2 power)
[BAND LOW]
[BAND HIGH]
-UHF-
(Low2 power)
[BAND LOW]
[BAND HIGH]
-VHF-
(Low1 power)
[BAND LOW]
[BAND HIGH]
-UHF-
(Low1 power)
[BAND LOW]
[BAND HIGH]
-VHF-
(S-Low power)
[BAND LOW]
[BAND HIGH]
-UHF-
(S-Low power)
[BAND LOW]
[BAND HIGH]
/
, and then set the adjustment value as specifi ed using [DIAL].
ITEM
1 1) Set the power supply voltage to 5.5 V.
2) Connect an RF power meter to the antenna connector.
3) While transmitting, adjust the TX power using [DIAL], and then
2
push to store the adjustment value.
[PO5]
3
4
5
/
, and then set the adjustment value as specifi ed using [DIAL].
ITEM
1 1) Set the power supply voltage to 7.4 V.
2) Connect an RF power meter to the antenna connector.
2 • While transmitting, adjust the TX power using [DIAL], and then
push to store the adjustment value.
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
OPERATION
OPERATION
5 - 6
VALUE
80–120 mW
VALUE
–
4.8–5.2 W
2.3–2.7 W
0.9–1.1 W
0.4–0.6 W
80–120 mW
