• ENTERING THE ADJUSTMENT MODE
1) Connect the JIG cable "#1" to [SP]. (See page 5-1)
2) While holding down [SQL] and
[SQL]
Push to turn ON the power.
• KEY ASSIGNMENTS FOR THE ADJUSTMENT MODE
Mode
Adjustment frequency
Adjustment item
TX output power
Selects the next adjustment item
(without storing value)
Selects the previous adjustment item
• QUITING THE ADJUSTMENT MODE
1) Remove the JIG cable "#1" from [SP].
2) Turn OFF the power, and then turn ON the power.
, turn ON the power.
Adjusts the value for the item
5 - 2
Connect the JIG cable "#1" (See page 5-1) here.
[QUICK/MENU]
Adjustment value
Stores the value for the item
