FUSE TABLE

DASHBOARD
AND CONTROLS
Fuse box on dashboard fig. 200
USERS
SAFETY
Right dipped beam headlight
Left dipped beam headlight, headlight alignment corrector
Engine compartment control unit relay, instrument panel control unit relay (+key)
STARTING
AND DRIVING
Minibus interior lights (emergency)
Rear current socket
Absent
WARNING LIGHTS
AND MESSAGES Reversing lights, Servotronic control unit, water in diesel filter sensor, (+key)
Central locking control unit (+battery)
Brake light control (main), third brake light, instrument panel (+key)
IN AN EMERGENCY
Instrument panel control unit relay (+battery)
EOBD socket, Radio, A/C control, Alarm, Tachograph,
Webasto timer (+battery)
MAINTENANCE
Left heated rear window, driver side mirror demister
AND CARE
Right heated rear window, passenger side mirror demister
ABS, ASR, ESP, Brake light control (secondary) (+key)
TECHNICAL
Windscreen washer (+key)
SPECIFICATIONS
Cigar lighter, Front power point
Controls on driver's side door, Controls on passenger side door
INDEX Absent
192
FUSE AMPERES
F12 7.5
F13 7.5
F31 7.5
F32 10
F33 15
F34 –
F35 7.5
F36 15
F37 7.5
F38 10
F39 10
F40 15
F41 15
F42 7.5
F43 30
F44 20
F45 7.5
F46 –
