Quick Start Guide
1
Figure 1 - 5
LCD Panel Open -
Model B
1. Built-In PC Camera
(Optional)
2. LCD (LED Backlight
LCD Optional)
3. Built-In Microphone
4. Power Button
5. Hot Key Buttons
6. LED Status
Indicators
7. Keyboard
8. Touchpad &
Buttons
9. LED Power &
Communication
Indicators
10. Fingerprint Module
(Optional)
Note the cleaning in-
structions for aluminum
covers - see page

1 - 10 System Map: LCD Panel Open - Model B

System Map: LCD Panel Open - Model B
9
1 - 2.
6
1
2
3
4
5
6
7
8
10
5
Wireless Device
Operation Aboard Aircraft
The use of any portable electronic trans-
mission devices aboard aircraft is usually
prohibited. Make sure the module(s) are
OFF if you are using the computer
aboard aircraft.
Use the key combinations to toggle pow-
er to the 3.5G/WLAN/Bluetooth mod-
ules, and check the LED indicator icon to
see if the modules are powered on or not
(see Table 1 - 5, on page 1 - 14/
- 2, on page 1 - 11).
4
Touchpad Buttons
(valid operation area)
Table 1
