System Map: LCD Panel Open - Model A

Wireless Device
Operation Aboard Aircraft
The use of any portable electronic
transmission devices aboard aircraft is
usually prohibited. Make sure the mod-
ule(s) are OFF if you are using the
computer aboard aircraft.
Use the key combinations to toggle
power to the 3.5G/WLAN/Bluetooth
modules, and check the LED indicator
icon to see if the modules are powered
on or not (see Table 1 - 5, on page 1 -
14/ Table 1 - 2, on page 1 -
6
5
3
11).
9
4
1
2
3
4
5
6
7
8
11
10
System Map: LCD Panel Open - Model A 1 - 9
Quick Start Guide
Figure 1 - 4
LCD Panel Open -
Model A
1. Built-In PC Camera
(Optional)
2. LCD
3. Speakers
4. Power Button
5. Hot Key Buttons
6. LED Status
Indicators
7. Keyboard
8. Touchpad &
Buttons
9. LED Power &
Communication
Indicators
10. Fingerprint Module
(Optional)
11. Built-In Microphone
Note the cleaning in-
structions for aluminum
covers - see page 1 - 2.
