LED Indicators

The two sets of LED indicators (LED Status Indica-
tors and LED Power & Communication Indicators)
on the computer display helpful information about the
current status of the computer.
Icon Color
Green Silent Mode Activated (see over)
Off Normal Mode Activated (see over)
Green
Green
Green
Scroll Lock Activated (to activate
Green
Table 1 - 2 - LED Status Indicators
Description
Hard Disk Activity
Number Lock Activated
Caps Lock Activated
press Fn & Scr Lk)
Icon Color
Orange
Green
Blinking Green
Orange
Green
Blinking Orange
Green
Orange
Green
Table 1 - 3 - LED Power & Communication Indicators
System Map: LCD Panel Open - Model B 1 - 11
Quick Start Guide
Description
DC Power is Plugged In
The Computer is On
The Computer is in Sleep
Mode
The Battery is Charging
The Battery is Fully Charged
The Battery Has Reached
Critically Low Power Status
The (optional) Wireless LAN
Module is Powered On
The (optional) Bluetooth
Module is Powered On
The (optional) 3.5G Module is
Powered On
