4. Insert the expansion memory into the
memory socket so that the notches on
the memory align with the correspond-
ing protrusions in the slot.
5. Close the bracket.
6. Refit the memory cover.
7. Print a status page to check the mem-
ory expansion (see page 1-3-2).
If memory expansion has been properly
performed, information on the installed
memory is printed with the total memory
capacity has been increased. Standard
memory capacity 256 MB.
Expansion memory
Memory socket
Bracket
Figure 1-2-17
