4. Load the paper in the cassette.
5. Turn the paper size dial so that it shows
the paper size you are going to use.
6. Insert the cassette.
Connecting the interface cable
1. Connect the interface cable to the
machine and PC or network.
Size dial
Figure 1-2-12
Figure 1-2-13
1-2-8
2KT/2KV
Paper
Cassette
Network interface
USB interface
