(2) Machine (rear side)
22
24
23
25
26
15. Rear cover
16. Rear cover lever
17. IF cover
18. Memory cover
19. Power cord cover
20. Paper conveying unit
20
18
19
Figure 1-1-2
21. Power cord connector
22. Network indicators
23. Network interface connector
24. USB interface connector
25. USB memory slot
26. Interface slot
1-1-4
17
21
2KT/2KV
16
15
