RJ12 Combined Data Socket Detail
Signal
Pin
Direction
1 Not Used
2 Not Used
3 To Printer
4 To Host
5 To Host
6

DATA CABLE

An optional serial data cable suitable for connecting the printer to a standard PC is available. (Note: This
cable features an integrated charger connector in the housing of the DB-9 connector which is not required
for this printer. Please make no connection to this integrated connector.)
The connections to a standard PC COM port are as follows:
DB-9 Pin Name
3 TxD
2 RxD
6 & 8 CTS & DSR
5 SGND

EMC STATEMENT

The DT-520 printers are fully EMC (Electro-Magnetic Compatibility) compliant and are CE marked
accordingly. A Declaration of Conformity, in accordance with the EMC Directive 89/336/EEC (and as
amended) is available on request.

EMC Caution

System EMC compliance remains the responsibility of the system designer. It is recommended that
shielded cables are used; grounding arrangements will depend on the application.
Description
Do Not Connect
Do Not Connect
RS-232 Rx data
RS-232 Tx data
RS-232 Busy
--- 0V Common (RS-232 signal return and Charger return)
Description (refers to PC)
Serial Data Output
Serial Data Input
Busy Input
Signal Common 0V
RJ12 Pin
3
4
5
6
7
