Wall Mounting Instructions - Dascom DP-520 User Manual

A bracket suitable for attaching the printer to a wall is available
The bracket snaps into the bottom of the printer. Prior to use, two small 'break-outs' must be removed
from the battery cover of the printer as shown below:
When attaching to a wall, the bracket must be located on the wall using screws and wall plugs as shown.
The printer may then be clipped into place and removed as required.
8

WALL MOUNTING INSTRUCTIONS

Remove the two 'break-outs' using a
small screwdriver.
Use a finger or small screwdriver to
release the clip and then gently lift
the printer to remove from the wall
bracket.
