WALL AND BELT MOUNTING INSTRUCTIONS
A combined bracket/clip suitable for attaching the printer to a wall or belt is available
The bracket snaps into the bottom of the printer, and when used to clip to a belt, it may be secured by using the
supplied extended screw (replaces the battery compartment screw). Prior to use, two small 'break-outs' must be
removed from the battery cover of the printer as shown below:
When attaching to a belt, the bracket should be put on the printer first, and then the entire assembly clipped over the
belt as shown:
The securing screw may be used if required.
When attaching to a wall, the bracket must be located on the wall using screws and wall plugs as shown. The printer
may then be clipped into place and removed as required.
Remove the two 'break-outs'
using a small screwdriver.
Use a finger or small screwdriver to
release the clip and then gently lift the
printer to remove from the wall bracket.
13
