- Page 1 SL07, SLC310 & SLC410 Marine Lanterns Installation & Service Manual Version 2.0...
- Page 2 Version No. Description Date Approved Manual Launch: SLC410 added & IR Control March 2012 C. Procter Addition of Configuration Settings Information April 2012 S. Turner Configuration Settings update April 2012 C. Procter Addition of LUX Table April 2012 J. Dore Update to Max Intensities &...
-
Page 3: Table Of Contents
GPS Synchronisation ..................Page 18 Lantern Status ....................Page 19 Optional IR Remote Control ................Page 21 Sealite IR Controller / Universal Remote Compatibility ......Page 21 IR Controller Functions .................. Page 22 Test Mode / Configure ................. Page 22 Security Access................... -
Page 4: Introduction
As a commitment to producing the highest quality products for our customers, Sealite has been independently certified as complying with the requirements of ISO9001:2008 quality management system. Sealite lanterns comply with requirements of the US Coast Guard in 33 CFR part 66 for Private Aids To Navigation. -
Page 5: Sl07 Model
The SL07 model is fitted with a GPS unit to synchronise flashing lights over any distance. This model has an IR sensor which allows it to be operated via Sealite’s IR remote control. -
Page 6: Installation Of Sl07 Model
EN61000-6-3:1997. EN61000-6-1:1997 Quality Assurance ISO9001:2008 Waterproof IP68 Intellectual Property Trademarks SEALITE® is a registered trademark of Sealite Pty Ltd Warranty * 3 years Options Available • 50mm pole mount adapter plate • Additional cable • Light sensor disabled • IR Controller •... -
Page 7: Slc310 & Slc410 Models
The SLC310 and SLC410 models are fitted with a GPS unit to synchronise flashing lights over any distance. These models have an IR sensor which allows it to be operated via Sealite’s IR remote control. All this is backed by Sealite’s industry leading 3-year warranty. - Page 8 Internal 24Ah battery the battery 3 & 4 hole bolt pattern Internal 12Ah battery on 200 mm OD base for ease of installation SLC310 Model SLC410 Model Latest products and information available at www.sealite.com...
- Page 9 Quality Assurance ISO9001:2008 ISO9001:2008 Waterproof IP68 IP68 Intellectual Property Trademarks SEALITE® is a registered trademark of Sealite SEALITE® is a registered trademark of Sealite Pty Ltd Pty Ltd Warranty * 3 years 3 years Options Available • 50mm pole mount adapter plate •...
-
Page 10: Installation Of Slc310 & Slc410 Models
Assembly Battery 12v 12Ah Battery Clamp Washer M4 M4 Cap Screw O-Ring, ID 145 x 4.0 Socket Head Screw M6 x 20 Mounting Insert Fig 2. SLC310 / SLC410 Solar Marine Lantern components Latest products and information available at www.sealite.com... -
Page 11: Selecting An Intensity/Power Setting
Selecting an Intensity/Power Setting SL07, SLC310 & SLC410 Models Intensity/power settings on Sealite lanterns operate via DIP switches, located near the rotary switches on the flasher unit. The intensity/power settings may be used to reduce the power consumption and intensity of the lantern. Setting the lantern to 25% intensity will reduce the power consumption to 25% of the normal 100% setting and the range by 25%. -
Page 12: Selecting A Flash Code
A comprehensive list of available flash codes is listed on in the ‘Flash Codes’ section of this manual. Example: SWITCH FLASH CODE FL 3 S Note – if setting the lantern to a demanding duty-cycle such as steady-on, the power setting must be reduced to ensure reliable operation Latest products and information available at www.sealite.com... -
Page 13: Flash Codes
Compact 3-5nm+ Solar Marine Lanterns Flash Codes The Sealite SL07, SLC310 & SLC410 may be set to any of 256 IALA recommended flash settings which are user-adjustable onsite without the need for external devices. SEALITE® code reference is listed by number of flashes For the latest version of this document visit www.sealite.com... - Page 14 FL 15 S 14.0 FL 5 S LFL 15 S 11.0 FL 5 S OC 15 S FL 5 S LFL 20 S 18.0 FL 5 S FL 26 S 25.0 FL 5 S Latest products and information available at www.sealite.com...
- Page 15 FL (2) 25 S 22.0 SWITCH Controller FLASH CODE Q (3) 5 S VQ (3) 5 S VQ (3) 5 S VQ (3) 5 S FL (3) 6 S FL (2+1) 6 S Latest products and information available at www.sealite.com...
- Page 16 FL (4) 20 S FL (4) 20 S 13.5 FL (4) 20 S 10.5 FL (4) 20 S Q (4) 20 S 16.5 Q (4) 28 S 24.5 FL (4) 30 S 26.5 Latest products and information available at www.sealite.com...
- Page 17 MO (A) 10 S MO (D) 10 S MO (A) 15 S 11.0 MO (U) 15 S 11.8 MO (U) 15 S 10.7 MO (U) 15 S 10.1 MO (B) 15 S 10.5 Latest products and information available at www.sealite.com...
-
Page 18: Gps Synchronisation
GPS Synchronisation SL07, SLC310 & SLC410 Models The SL07, SLC310 and SLC410 models come with GPS fitted as standard, and provide the user with the ability to install independently operating lanterns that all flash in synchronisation. No additional power supplies, aerials or control systems are required, and with its microprocessor- based system, the GPS option is specifically designed to provide maximum reliability and performance over a wide range of environmental conditions. -
Page 19: Lantern Status
There is one red and one yellow status LED. The red status LED is used to indicate the health of the lantern’s power system. The yellow status LED is used to indicate the operational status of the lantern. These indicator LED’s can be viewed at the base of the lens. Latest products and information available at www.sealite.com... - Page 20 SL07, SLC310 & SLC410 Compact 3-5nm+ Solar Marine Lanterns All Sealite boards are fitted with two Indicator LED’s. These are positioned near the Flash Code Rotary Switches. Use the table below to help determine operational status. Yellow LED Lantern Status...
-
Page 21: Optional Ir Remote Control
Sealite IR Controller / Universal Remote Compatibility If you lose your Sealite IR Controller, the following Universal Remote Controller has been tested for compatibility: RCA Type RCR312WR programmed for Phillips TV Type Code 10054... -
Page 22: Ir Controller Functions
The light flashes the current battery status. The light flashes the sunset level in Lux, followed by a 2 second gap, followed by the sunrise level. Levels are in the range of 1 to 9. Latest products and information available at www.sealite.com... -
Page 23: Flash Code
This function reads the battery status. The response from the light is High Voltage: 4 flashes, Good Voltage: 3 flashes, Low Voltage 2 flashes, Cutoff Voltage or below: 1 flash. Example Key sequence: Latest products and information available at www.sealite.com... -
Page 24: Lux
On successful programming, the light will flash the sunset level (D-N), followed by a 2 second gap, followed by the sunrise level (N-D). Latest products and information available at www.sealite.com... -
Page 25: Error Indication
IR Remote Control, the lamp will flash 49 which is the corresponding number for switches A=3, B=1. Use the IR Remote Control to read the current lamp intensity setting and flash code. Latest products and information available at www.sealite.com... -
Page 26: Gps Synchronisation Control And Status
To assist with diagnosing a problem with the GPS module, the following key sequence will trigger the lantern to flash a predetermined number of times indicating the current status of the GPS synchronisation module. Latest products and information available at www.sealite.com... - Page 27 UTC status data was detected. It may take up to 13min to complete this stage. Four, GPS enabled, The GPS synchronisation module is 1 second flashes synchronised to UTC time and valid functioning correctly. Latest products and information available at www.sealite.com...
-
Page 28: Maintenance & Servicing
Maintenance & Servicing SL07 Model Designed to be maintenance free, the SL07 requires minimal attention, though the following maintenance and servicing information is provided to help ensure the life of your product. 1. Cleaning Lens- occasional cleaning of the light lens may be required. Using a cloth and warm soapy water, wipe off any foreign matter before rinsing the lens with fresh water. -
Page 29: Slc310 & Slc410 Models
SLC310 & SLC410 Models Designed to be almost maintenance-free, the SL310 and SLC410 require minimal attention, though the following maintenance and servicing information is provided to help ensure the life of your Sealite product. 1. Cleaning Solar Panels- occasional cleaning of the solar panels may be required. Using a cloth and warm soapy water, wipe off any foreign matter before rinsing the panels with fresh water. -
Page 30: Solar Panel Replacement (Slc310 & Slc410 Models)
The replacement of a solar panel should only be performed by a confident technician. Sealite cannot guarantee the chassis will remain waterproof, if it not performed by Sealite staff. To test for any leaks remove the gore vent and pressurise the assembled Light to 1.5psi. -
Page 31: How To Change The Regulator (Slc310 & Slc410 Models)
M6 x 20 socket head cap screws with the 4 x M6 nylon washers evenly. DO NOT OVERTIGHTEN. Use the label to ensure correct location SL10 AMP Regulator shown when of wires during assembly correctly fitted Latest products and information available at www.sealite.com... -
Page 32: Trouble Shooting
• Expose lantern to direct sunlight and monitor operation for entire night. several days. Sealite products typically require 2.5 hours of direct sunlight per day to retain full autonomy. From a discharged state, the lantern may require several days of operational conditions to ‘cycle’... - Page 33 SL07, SLC310 & SLC410 Compact 3-5nm+ Solar Marine Lanterns Notes Latest products and information available at www.sealite.com...
-
Page 34: Sealite Led Light Warranty
2. Online Registration - please complete the Online Registration Form at; www.sealite.com Sealite Pty Ltd will repair or replace your LED light in the event of electronic failure for a period of up to three years from the date of purchase. - Page 35 SL07, SLC310 & SLC410 Compact 3-5nm+ Solar Marine Lanterns 3. The customer must give Sealite Pty Ltd notice of any defect with the product within 30 days of the customer becoming aware of the defect. 4. Rechargeable batteries have a limited number of charge cycles and may eventually need to be replaced.
- Page 36 (up to 3mt in diameter) Area Lighting Mooring Systems & Accessories Head Office Sealite Pty Ltd 11 Industrial Drive Somerville, Vic 3912 Australia Tel: +61 3 5977 6128 Fax: +61 3 5977 6124 Email: info@sealite.com Internet: www.sealite.com Latest products and information available at www.sealite.com...
