Remote Control, cont'd

Timeout

Pauses of 10 seconds or longer between command ASCII
characters result in a timeout. The command operation is
aborted with no other indication.

Using the command/response table

The command/response table is on the next page. Lowercase
letters are allowed in the command field only as indicated.
Symbols are used throughout the table to represent variables in
the command/response fields. Command and response
examples are shown throughout the table. The ASCII to HEX
conversion table below is for use with the command/response
table.

Symbol definitions

= CR/LF (carriage return/line feed) (0x0D 0A)
• = space
= Input number
X1
= Input signal status
X2
= On/off status
X3
= Software version
X4
= Switch mode
X5
ASCII to HEX Conversion Table
SW VGArs / Ars Series Switchers • Remote Control
4-4
0 through 6 (0 = output mute)
0 = no signal detected
1 = signal detected
0 = off
1 = on
x.xx
1 = normal switch mode
2 = auto switch mode
•
SW VGArs / Ars Series Switchers • Remote Control
4-5
