General Information

Main Assemblies

(1) Nipping Station
(2) Glue Tank
(3) Notching Station
(4) Clamp Station
(5) Control Panel
(6) Nipping Pressure Control

Specification

Model
Maximum Book Size
Minimum Book Size
Maximum Binding Thickness
Glue Warm Up
Glue Warm Up in Stand-by Mode
Cycle Speed
Production Speed
Power Source
Power Consumption
Machine Weight
Machine Dimension

Accessories

Having unpacked your DB-250, you will find the accessories as follows:
Name
Cover-Sheet Holder
Bottom Cover
Screw Driver
Hex Wrench
Hex Wrench

Adhesive

AAG-DB250GLUE :
Physical Properties:
12.6" x 15.75" ( 320mm x 400mm )
3.15" x 1.97" ( 80mm x 50mm )
1.6" ( 40mm )
25 minutes ( varies depending upon glue type )
5 minutes
360 cycles per hour
Up to 200 books per hour
110V, 60 Hz ( Option: 220V, 50 Hz )
10 Amps.
255 LBS ( 116 Kg )
46"(L) x 22"(W) x 15"(H) (1150x560x370mm)
Specification
6" ( 150mm )
0.16" ( 4mm )
0.24" ( 6mm )
Available in 50 lbs. boxes
Appearance/Form:
Working Temperature:
Working Glue Viscosity:
Open Time:
2
DB-250 Perfect Binder
Opaque clear/Chips
320 °F (160 °C)
1,800 CPS @ 320 °F (160 °C)
10 to 13 second
Quality
1
1
1
1
1
