Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40
Contents Introduction

Profile 65" using C60

UNIT DELIVERED COMPLETE WITH:
Full HD LCD display, Codec C60, Touch for C-series
user interface device, remote control, PrecisionHD
1080p Camera, microphones, Digital Audio Module,
integrated speakers and integrated cabling.
MONITOR available with:
65'' Full HD LCD, 16:9, 1080 × 1920 resolution
BASE available with:
Floor standing footplate
Wall mount on pedestal
BANDWIDTH
The same as Codec C60
FIREWALL TRAVERSAL
The same as Codec C60
VIDEO STANDARDS
The same as Codec C60
VIDEO FEATURES
The same as Codec C60
VIDEO INPUTS (5 INPUTS)
The same as Codec C60
VIDEO OUTPUTS (3 OUTPUTS)
The same as Codec C60
LIVE VIDEO RESOLUTIONS (ENCODE/DECODE)
The same as Codec C60
AUDIO STANDARDS
The same as Codec C60
AUDIO FEATURES
The same as Codec C60
All specifications are subject to change without notice, system specifics may vary.
All images in these materials are for representational purposes only, actual products may differ.
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other
countries. A listing of Cisco's trademarks can be found at www.cisco.com/go/trademarks. Third party trademarks
mentioned are the property of their respective owners. The use of the word partner does not imply a partnership
relationship between Cisco and any other company.
June 2011
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
Web interface Advanced settings
AUDIO INPUTS (7 INPUTS)
The same as Codec C60
AUDIO OUTPUTS (3 OUTPUTS)
The same as Codec C60
DUAL STREAM
The same as Codec C60
MULTISITE FEATURES*
The same as Codec C60
PROTOCOLS
The same as Codec C60
EMBEDDED ENCRYPTION
The same as Codec C60
IP NETWORK FEATURES
The same as Codec C60
IPV6 NETWORK SUPPORT
The same as Codec C60
SECURITY FEATURES
The same as Codec C60
NETWORK INTERFACES
The same as Codec C60
OTHER INTERFACES
The same as Codec C60
PRECISIONHD 1080P CAMERA
The same as Codec C60
SYSTEM MANAGEMENT
The same as Codec C60, as well as
Cisco TelePresence Touch for C-series user interface
device
DIRECTORY SERVICES
The same as Codec C60
Password protection
POWER
Auto-sensing power supply
100-120/200-240 VAC, 60/50 Hz
175 W max for codec and main camera
Maximum power rating complete system, 650 W
OPERATING TEMPERATURE AND HUMIDITY
0° C to 35° C (32° F to 95° F) ambient temperature
10% to 90% Relative Humidity (RH)
STORAGE AND TRANSPORT TEMPERATURE
-20° C to 60° C (-4° F to 140° F) at RH 10–90%
(non-condensing)
DIMENSIONS
Height: 65 in. / 165 cm
Width: 59.1 in. / 150 cm
Depth: 5.9 in. / 15 cm
Weight: 330 lbs / 150 kg (with floor standing footplate)
* Requires option
91
Administrator guide
Appendices Appendices Contact us
APPROVALS
EU/EEC
Directive 2006/95/EC (Low Voltage Directive)
– Standard EN 60950-1
Directive 2004/108/EC (EMC Directive)
– Standard EN 55022, Class A
– Standard EN 55024
– Standard EN 61000-3-2/-3-3
Warning: This is a class A product. In a domestic
environment this product may cause radio interference
in which case the user may be required to take
adequate measures.
USA
Approved according to UL 60950-1
Complies with FCC15B Class A
Note: This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications. Operation of
this equipment in a residential area is likely to cause
harmful interference in which case the user will
be required to correct the interference at his own
expense.
Canada
Approved according to CAN/ CSA-C22.2 No. 60950-1
This Class A digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe A est conforme à
la norme NMB-003 du Canada.
MTBF PRODUCT RELIABILITY/MTBF
The predicted reliability is expressed in the expected
random Mean Time Between Failures (MTBF) for the
electronic components based on the Power On Hours:
Power On Hours (POH) > 69 000 hours
Useful Life Cycle > 6 years
ISO 9001 certificate is available upon request
