Audio Output Line [1..2] Equalizer ID
Select the audio output line equalizer ID.
Requires user role: ADMIN
Value space: <1..8>
Range: Select EqualizerID 1 to 8.
Example: Audio Output Line 1 Equalizer ID: 1
Audio Output Line [1..2] Equalizer Mode
Set the audio output line equalizer mode.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the equalizer for the audio output line.
Off: No equalizer.
Example: Audio Output Line 1 Equalizer Mode: Off
Audio Output Line [1..2] Level
Define the output level of the Audio Output Line connector, in steps of 1 dB.
See the Audio Level tables in the Physical Interfaces Guide for the codec for a complete overview
of the menu values represented in dB.
Requires user role: ADMIN
Value space: <-24..0>
Range: Select a value from -24 to 0 dB.
Example: Audio Output Line 1 Level: -10
Audio Output Line [1..2] Mode
Set the audio output line mode.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the Audio Line output.
Off: Disable the Audio Line output.
Example: Audio Output Line 1 Mode: On
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
Web interface Advanced settings Advanced settings
Audio Output Line [1] Type
Determine if the Audio Line output will be analog or digital type output. The digital output on the
Cisco TelePresence Profile systems are identified as DNAM (Digital Natural Audio Module).
Requires user role: ADMIN
Value space: <Auto/SPDIF>
Example: Audio Output Line 1 Type: Auto
Audio Output Line [2] Type
Line output 2 is a dedicated analog output, hence type can be set to analog only.
Requires user role: ADMIN
Value space: <Analog>
Example: Audio Output Line 2 Type: Analog
Audio Microphones Mute Enabled
Determine whether audio-mute is allowed or not. The default value is True.
Requires user role: ADMIN
Value space: <True/InCallOnly>
Example: Audio Microphones Mute Enabled: True
Audio SoundsAndAlerts KeyTones Mode
The system can produce a sound every time a key on the remote control is pressed.
Requires user role: USER
Value space: <On/Off>
Example: Audio SoundsAndAlerts KeyTones Mode: Off
41
Password protection
Auto: If a Digital NAM is detected then SPDIF mode will be selected, otherwise analog mode will
be selected.
SPDIF: Set to SPDIF when you want the line output to be in digital mode.
Analog: Can be set to analog only.
True: Muting of audio is always available.
InCallOnly: Muting of audio is only available when the device is in a call. When Idle it is not
possible to mute the microphone. This is useful when an external telephone service/audio
system is connected via the codec and is to be available when the codec is not in a call. When
set to InCallOnly this will prevent the audio-system from being muted by mistake.
On: There will be a sound indicator when pressing keys on the remote control.
Off: The remote control Key Tones is switched off.
