User Manual
V
What's in the Box?
Audio Line Cable
Dual RCA (red/white)
(CAB00024)
VCR Video/Audio Cable
Dual RCA (yellow/white)
Remote
(CAB00042)
Control
User's Guide
LAN cable
(CAB42001)
Microphone
Power
Supply
Power
Cable
HD3000 Quick Start Guide
Required Setup
HD3000 /
HD3000 LT
RS-232
Serial to Dual
Terminal Cable
)
(CAB00026
Power
Supply
Composite video
RCA to RCA
(CAB72010)
* The composite connection in the VCR
section must be used in order to connect a
S-Video
single TV monitor using a "composite"
MiniDIN to MiniDIN
cable. The composite connection in the
TV section is for a 2nd monitor.
(CAB90051)
*
S-Video
cable
Mic
Audio Line
Cable to
Audio In
S-Video In
www.vcon.com
LAN cable
