  • Page 1 Videoconferencing Systems HD100 Videoconferencing Engine Getting Started Guide DOC00034 Rev. 2.0 08.03...
  • Page 2: Limited Warranty

    ONE (1) year from the date of receipt. This Limited Warranty shall not apply to any product that in the opinion of VCON Ltd. has not been installed or upgraded according to accompanying documentation from VCON Ltd. or been subject to misuse, misapplication, negligence r accident while in the hands of the purchaser.
  • Page 3 LIABILITIES VCON’s entire liability and the Purchaser’s exclusive remedy shall be at VCON’s option, either return of the price paid or repair/replacement of the Product not meeting VCON’s declared Limited warranty. VCON or its suppliers shall not be liable in any event to anyone for any indirect, incidental, consequential,...
  • Page 4 VCON Technical Support This API & Setup Guide was designed to help you set up and work with the HD100 Integrator system easily. If a situation occurs that is not covered by the supplied documentation, please request help from our Technical Support channels. VCON’s organization will make its strongest efforts to help you resume your software integration activities as soon as possible.
  • Page 5: Table Of Contents

    Welcome to HD100................6 1.1 Package Checklist ..................7 Setting Up the HD100 Network Configuration........8 2.1 Setup from the HD100 Demo User Interface ...........8 2.2 Setup from the HD100 Debug Terminal...........9 Making a call ..................11 3.1 Dialing Through the HD100 Embedded WEB Server......11 3.2 Dialing Through the HD100 Demo Application ........12...
  • Page 6: Welcome To Hd100

    IP conferencing data rates up to 2 Mbps. With an embedded MCU and streaming capabilities, as well as a suite of integration APIs, the HD100 can be used to create any custom application in an array of industries such as healthcare, large education facilities and corporate boardrooms.
  • Page 7: Package Checklist

    Welcome to HD100 Package Checklist When opening the HD100 package, make sure the following items are included: : Item Quantity HD100 codec Remote Control Microphone + cable Power cord RCA-to-RCA video cable (Composite TV) S-Video + audio cable RS-232 cable...
  • Page 8: Setting Up The Hd100 Network Configuration

    P THE ETWORK ONFIGURATION Before working with the HD100 for the first time, you must set up its network configuration. Setup from the HD100 Demo User Interface This procedure requires that you work with the HD100 demo’s user interface with the supplied remote control.
  • Page 9: Setup From The Hd100 Debug Terminal

    To exit the Status dialog, press the <CH-> button. Setup from the HD100 Debug Terminal To configure the HD100 through the debug terminal, you may gain access over a RS-232 connection. Use COM1 to configure basic LAN parameters and to get debugging information.
  • Page 10 Press any key to stop the running of the HD100. After the prompt, “[VxWorks Boot]:”, type C and press <Enter>. A series of HD100 parameters will appear with their current values. To change a parameter, type the change in the line after the current value and then press <Enter>.
  • Page 11: Making A Call

    Making a call AKING A CALL To demonstrate the HD100’s videoconferencing application, dial a remote user through one of the following methods: ❑ Dialing Through the HD100 Embedded WEB Server ❑ Dialing Through the HD100 Demo Application ❑ Dialing Through a Telnet Connection Dialing Through the HD100 Embedded WEB Server In Internet Explorer, enter the HD100 IP address.
  • Page 12: Dialing Through The Hd100 Demo Application

    After the opening screen appears, press any digit button on the remote control. The HD100 manual dial dialog appears. Press the digit buttons to enter the IP address of a remote HD100 (or any other H.323 endpoint). Press the <OK> button to dial.
  • Page 13: Dialing Through A Telnet Connection

    From the Connect Using list, choose TCP/IP (Winsock). Enter the HD100 IP address. As the Port Number, type 5005. Click OK. You are now in an active Telnet session. Information from the HD100 appears on the screen. Welcome to HD100: Version : 0150.M07.D16.H14...
  • Page 14 To display the list of available API commands, type help. The HD100 API system events, commands, and parameters are described, along with syntaxes and examples, in the HD100 API Programmer’s Guide. You may download this publication from the VCON website’s (http://www.vcon.com) Support>Documentation>Manuals page.
  • Page 15: The Remote Control

    The Remote Control EMOTE ONTROL For the functions relevant to the operation of the HD100’s videoconferencing demo with the remote control, refer to the following illustrations. The model of the supplied remote control is subject to change. This section provides layouts for possible supplied models.
  • Page 16 The Remote Control VCON HD100 Getting Started Guide...
