RECORDING PROGRAMS

In order to record your own patches into the program memory you have to ENABLE the record
function. To do this, press PREFIX BUTTON C (3.6), hit 8, and hit ENTER. This will display the
status of the instrument. The Alphanumeric Display will read "DISABLED" or "ENABLED."
Now you must enter a four-digit security code (when each instrument is shipped, the code is 0000).
If you enter the wrong code, the display reads "BAD CODE" and returns to normal operation. If you
enter the correct code, the instrument shows the updated status (ENABLED or DISABLED) and re-
turns to normal operation. To change the code, hit C, hit 8, hit ENTER, then hit C again; the instru-
ment assumes you want to change the security code and displays "OLD CODE." You enter the ex-
isting code; if the code is incorrect the display reads "BAD CODE," and operation returns to nor-
mal. If the code is correct, the display reads "NEW CODE," and you enter any new four-digit code
number, followed by ENTER. A convenient code number is the last four digits of your telephone
number.
SYSTEM CONTROLLER
PROGRAM
1 2
4 5
7 8
0
RECORD
INTERLOCK
Once you've ENABLED the memory, you're ready to store patches. The memory position you
decide on should be one that has a patch you don't want, since once you record another patch over it,
it's gone (unless, of course, you've stored it on cassette tape using the procedure explained a little
later).
There are two ways of arriving at a patch you like: setting one up from scratch (starting from a
"live panel"), or editing (changing) a prerecorded patch. To set up a live panel – one where all the
controls are active, overriding the memory values – hit PREFIX C, number 9, and ENTER.
SYSTEM CONTROLLER
PROGRAM
LIVE PNL
1 2
4 5
7 8
0
RECORD
INTERLOCK
18
3 A
6 B
9 C
D
ENTER
3 A
6 B
9 C
D
ENTER
MEMORY ENABLE/DISABLE PROCEDURE
PRESS C
PRESS 8
PRESS ENTER = ENABLED OR DISABLED
LIVE FRONT PANEL
HIT C
HIT 9
HIT ENTER = LIVE PANEL
MEMORY RECORD FUNCTION
