Model(s):
CD4236R
CD4842R
CD4236LR CD4842LR
CD4236IR
CD4842IR
CD4236ILR CD4842ILR
Direct Vent Gas Appliance
• Important operating and
maintenance instructions
included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or
the gas supplier.
This appliance may be installed as an OEM installation
in manufactured home (USA only) or mobile home and
must be installed in accordance with the manufacturer's
instructions and the manufactured home construction and
safety standard, Title 24 CFR, Part 3280 or Standard for
Installation in Mobile Homes, CAN/CSA Z240MH.
This appliance is only for use with the type(s) of gas
indicated on the rating plate.
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand and follow
•
these instructions for safe
installation and operation.
• CAREFULLY SUPERVISE children in same room as
• A l e r t c h i l d r e n a n d a d u l t s t o h a z a r d s o f h i g h
High temperatures may ignite clothing or other
fl ammable materials.
• Keep clothing, furniture, draperies and other combustibles
This appliance has been supplied with an integral
barrier to prevent direct contact with the fi xed glass
panel. Do NOT operate the appliance with the barrier
removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts installation must
be performed by a licensed plumber or gas fi tter;
See Table of Contents for location of additional
Commonwealth of Massachusetts requirements.
Heatilator • Caliber CD Series • 4040-263 Rev M • 06/08
Owner's Manual
Installation and Operation
Leave this manual with
•
party responsible for
use and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation and cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
appliance.
temperatures.
away.
Installation and service of this appliance should be performed
by qualifi ed personnel. Hearth & Home Technologies suggests
NFI certifi ed or factory-trained professionals, or technicians
supervised by an NFI certifi ed professional.
1
Advertisement
Table of Contents
Related Manuals for Heatilator Heatilator D4236R
Summary of Contents for Heatilator Heatilator D4236R
- Page 1 Owner’s Manual Installation and Operation Model(s): CD4236R CD4842R CD4236LR CD4842LR CD4236IR CD4842IR CD4236ILR CD4842ILR Direct Vent Gas Appliance CAUTION DO NOT DISCARD THIS MANUAL Read, understand and follow Leave this manual with • Important operating and • • these instructions for safe party responsible for maintenance instructions installation and operation.
-
Page 2: Congratulations
Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. A. Congratulations This owner’s manual should be retained for future reference. We suggest that you keep it with your other important Congratulations on selecting a Heatilator gas fi replace, an documents and product manuals. -
Page 3: Table Of Contents
Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •... - Page 4 14 Appliance Setup A. Remove Fixed Glass Assembly B. Remove the Shipping Materials C. Clean the Appliance D. Accessories E. Place the Lava Rock Place the Vermiculite G. Place the Rockwool H. Install the Refractory Install the Log Assembly Fixed Glass Assembly K.
-
Page 5: Limited Lifetime Warranty
B. Limited Lifetime Warranty Gas Appliance (Fireplace) Limited Lifetime Warranty HEARTH & HOME TECHNOLOGIES INC. (“HHT”) extends the following warranty for HEATILATOR® gas appliances installed in the United States of America or Canada (the "Appliance"). Dealers and employees of HHT have no authority to make any warranty or authorize any remedies in addition to or inconsistent with the terms of this warranty. -
Page 6: Listing And Code Approvals
Listing and Code Approvals A. Appliance Certifi cation C. BTU Specifi cations Caliber CD Series CD4236 CD4842 MODELS:CD4236R, CD4236LR, CD4236IR, CD4236ILR Standing Pilot or IPI CD4842R, CD4842LR, CD4842IR, CD4842ILR Max/Min Input Rate (NG) 30,000/20,000 33,000/22,000 LABORATORY: Underwriters Laboratories, Inc. (UL) Orifi... -
Page 7: Requirements For The Commonwealth Of
Inspection Note: The following requirements reference various The state or local gas inspector of the side wall horizon- Massachusetts and national codes not contained in this tally vented gas fueled equipment shall not approve the document. installation unless, upon inspection, the inspector ob- serves carbon monoxide detectors and signage installed G. -
Page 8: User Guide
User Guide Operating Instructions A. Gas Fireplace Safety • Install a physical barrier such as: A decorative fi rescreen. WARNING Adjustable safety gate. • Install a switch lock or a wall/remote control with child HOT SURFACES! protection lockout feature. Glass and other surfaces are hot •... -
Page 9: Fan Kit (Optional)
C. Fan Kit (optional) F. Fixed Glass Assembly If desired, a fan kit may be added. Contact your dealer to See Section 14.K. order the correct fan kit. G. Remote Controls, Wall Controls and Wall D. Clear Space Switches Follow the instructions supplied with the control installed WARNING! DO NOT place combustible objects in front of to operate your fi... -
Page 10: Lighting Instructions (Ipi)
I. Lighting Instructions (IPI) • For normal use, activate/deactivate your fi replace with the wall switch or remote control. • The IPI system may be operated with two D-cell batteries. When using batteries, unplug the transformer. To prolong battery life, remove them when using the transformer. •... -
Page 11: Lighting Instructions (Standing Pilot)
J. Lighting Instructions (Standing Pilot) • For normal use, activate/deactivate your fi replace with the wall switch or remote control. • If your fi replace must be deactivated for service or an extended period of time, follow the instructions below. VENT Heatilator •... -
Page 12: After Fireplace Is Lit
K. After Fireplace is Lit Initial Break-in Procedure • The fireplace should be run three to four hours continuously on high. • Turn the fi replace off and allow it to completely cool. • Remove fi xed glass assembly. See Section 14.K. •... -
Page 13: Maintenance And Service
Maintenance and Service Doors, Surrounds, Fronts Any safety screen or guard removed for servicing must be Frequency: Annually replaced prior to operating the fi replace. By: Homeowner When properly maintained, your fi replace will give you many years of trouble-free service. We recommend an- Tools needed: Protective gloves, stable work surface nual service by a qualifi... -
Page 14: Maintenance Tasks-Qualifi Ed Service Technician
B. Maintenance Tasks-Qualifi ed Service Burner Ignition and Operation Technician Frequency: Annually The following tasks must be performed by a qualifi ed By: Qualifi ed Service Technician service technician. Tools needed: Protective gloves, vacuum cleaner, whisk Gasket Seal and Glass Assembly Inspection broom, fl... -
Page 15: Installer Guide
Installer Guide Getting Started A. Typical Appliance System NOTICE: Illustrations and photos refl ect typical installations and are for design purposes only. Illustrations/diagrams are not drawn to scale. Actual product may vary from pictures in manual Note: Dual venting confi gurations ARE NOT allowed. -
Page 16: Design And Installation Considerations
B. Design and Installation Considerations D. Inspect Appliance and Components Heatilator direct vent gas appliances are designed to op- • Carefully remove the appliance and components from erate with all combustion air siphoned from outside of the the packaging. building and all exhaust gases expelled to the outside. No •... -
Page 17: Framing And Clearances
Framing and Clearances A. Select Appliance Location NOTICE: Illustrations refl ect typical installations and are FOR DESIGN PURPOSES ONLY. Illustrations/diagrams When selecting a location for the appliance it is important are not drawn to scale. Actual installation may vary due to to consider the required clearances to walls (see Figure individual design preference. -
Page 18: Construct The Appliance Chase
B. Construct the Appliance Chase To further prevent drafts, the wall shield and ceiling fi re- stops should be caulked with high temperature caulk to A chase is a vertical box-like structure built to enclose the seal gaps. Gas line holes and other openings should be gas appliance and/or its vent system. -
Page 19: Mantel And Wall Projections
D. Mantel and Wall Projections WARNING! Risk of Fire! Comply with all minimum clear- ances to combustibles as specifi ed. Framing or fi nishing material closer than the minimums listed must be construct- ed entirely of noncombustible materials (i.e., steel studs, concrete board, etc). -
Page 20: Termination Locations
Termination Locations A. Vent Termination Minimum Clearances Direct Vent Gas, Wood or Fuel WARNING Oil Termination 20 in. Fire Risk. (508 mm) (minimum) to 18 in. Maintain vent clearance to combustibles as Perpendicular (457 mm) Wall specifi ed. (DV only) •... - Page 21 Fixed Openable Fixed Closed Closed GAS METER V TERMINATION CAP AIR SUPPLY INLET RESTRICTION ZONE (TERMINATION NOT ALLOWED) Measure vertical clearances from this surface Electrical Service Covered Alcove Measure horizontal clearances Clearances to Electrical Service Applications from this surface. Dimension Descriptions P 6”...
-
Page 22: Vent Information And Diagrams
Vent Information and Diagrams A. Approved Pipe This appliance is approved for use with Hearth & Home Technologies DVP and/or SLP venting systems. Refer to Section 16B for vent component information. Vertical DO NOT mix pipe, fi ttings or joining methods from differ- ent manufacturers. -
Page 23: Vent Diagrams
E. Vent Diagrams Note: The CD series appliances can adapt to SLP series vent pipe when venting off the top of the appliance. To replace the fi rst starter elbow with two 45° elbows, You must use a DVP-SLP24 adapter which can only refer to Figure 7.4. - Page 24 1. Top Vent - Horizontal Termination - (continued) Two 45° Elbows replacing One 90° Elbow 4 ft min. (1.22 m) 25 ft max. (7.62 m) Figure 7.4 min. max. max. H max. Two Elbows 0.15 1.83 0.30 3.35 3.35 0.46 5.49 5.49 0.61...
- Page 25 1. Top Vent - Horizontal Termination - (continued) min. max. max. Three Elbows 0.30 7.32 5.79 0.30 6.71 5.79 Installed Vertically Figure 7.6 Heatilator • Caliber CD Series • 4040-263 Rev M • 06/08...
- Page 26 2. Top Vent - Vertical Termination Note: If installing a vertical vent/ No Elbow termination off the top of the appli- ance, the vertical termination baffl e should be used. 12 ft (3.66 m) min. 60 ft (18.29 m) max. Figure 7.7 Note: If installing a vertical vent/ Two Elbows...
- Page 27 2. Top Vent - Vertical Termination - (continued) Note: If installing a vertical vent/ Three Elbows termination off the top of the appli- ance, the vertical termination baffl e should be used. Maximum horizontal run is 100% of vertical, but cannot exceed 26 ft (7.92 m) 12 ft (3.66 m) min.
- Page 28 3. Rear Vent - Horizontal Termination No Elbow 18 in. (457 mm) max. Figure 7.10 One 45° Elbow 18 in. (457 mm) max. Figure 7.11 Heatilator • Caliber CD Series • 4040-263 Rev M • 06/08...
- Page 29 3. Rear Vent - Horizontal Termination - (continued) max. min. max. Two Elbows 0.61 0.30 0.91 1.22 0.61 1.83 1.83 0.91 2.74 2.44 1.22 3.66 2.44 1.52 4.57 2.44 1.83 5.49 Figure 7.12 Three Elbows max. min. max. 0.61 0.30 0.91 1.22 0.61...
- Page 30 4. Rear Vent - Vertical Termination One Elbow 0 min. 6 ft (1.83 m) max. 12 ft (3.66 m) min. 60 ft (18.29 m) max. Figure 7.14 Two Elbows 0 min. 12 ft (3.66 m) min. 6 ft (1.83 m) max. 60 ft (18.29 m) max.
- Page 31 4. Rear Vent - Vertical Termination - (continued) Three Elbows 0 min. 6 ft (1.83 m) max. 12 ft (3.66 m) min. 60 ft (18.29 m) max. Maximum horizontal run is 100% of vertical, but can- not exceed 26 ft (7.92 m). Figure 7.16 Heatilator •...
-
Page 32: Install Vertical Termination Baffl E
F. Install Vertical Termination Baffl e • Squeeze the open end of the bent baffl e with one Note: For vertically terminated installations only. hand. Insert the baffl e bent side up into the inner fl ue so that the bottom of the baffl e is above the bead on Note: If installing a vertical vent/termination run off the the inside of the collar. -
Page 33: Vent Clearances And Framing
Vent Clearances and Framing A. Pipe Clearances to Combustibles B. Wall Penetration Framing WARNING! Risk of Fire! Maintain air space clearance to Combustible Wall Penetration vent. DO NOT pack insulation or other combustibles: Whenever a combustible wall is penetrated, you must •... -
Page 34: Install The Ceiling Firestop
C. Install the Ceiling Firestop A ceiling fi restop MUST be used between fl oors and attics. • DVP pipe only - Frame an opening 10 in. by 10 in. (254 mm by 254 mm) whenever the vent penetrates a ceiling/fl oor (see ATTIC ABOVE Figure 8.4). -
Page 35: Install Attic Insulation Shield
D. Install Attic Insulation Shield WARNING! Fire Risk. DO NOT allow loose materials or insulation to touch vent. Hearth & Home Technologies Inc. requires the use of an attic shield. The National Fuel Gas Code ANSI Z223.1 and NFPA 54 requires an attic shield constructed of 26 gauge minimum metal that extends at least 2 in. -
Page 36: Appliance Preparation
Appliance Preparation A. Convert from Top Vent to Rear Vent • Remove three remaining screws holding the plate surrounding fl ue. See Figure 9.3. Remove plate and set CAUTION! Risk of Cuts, Abrasions or Flying Debris. aside. Wear protective gloves and safety glasses during installa- tion. - Page 37 • Remove four screws holding outer collar to appliance • Remove four screws holding outer cover plate to top. See Figure 9.5. Remove outer collar. appliance back. See Figure 9.8. Remove outer cover. Figure 9.8 Outer Cover, Rear - Remove Plate •...
- Page 38 • Place outer collar on rear of appliance and replace four • Place inner cover plate on appliance top and replace screws to hold collar in place. See Figure 9.11. Make four screws to hold inner cover plate in place. See sure insulation is attached to the collar base! Figure 9.14.
- Page 39 • Locate heat shield cover plate removed in the fi rst step. Place the heat shield cover plate on top of heat shield. Replace four screws to hold this plate in place. See Figure 9.16. Figure 9.18 Screw Cover into Place •...
-
Page 40: Secure And Level The Appliance
B. Secure and Level the Appliance WARNING! Risk of Fire! Prevent contact with: • Sagging or loose insulation • Insulation backing or plastic • Framing and other combustible materials Block openings into the chase to prevent entry of blown-in insulation. Make sure insulation and other materials are secured. -
Page 41: Install Vent Pipe
Install Vent Pipe A. Assemble Pipe Sections (DVP Only) Attach Pipe to the Firebox Assembly Note: The end of the pipe sections with the lanced tabs will face towards the appliance. Attach the fi rst pipe section to the starting collar: •... -
Page 42: Assemble Vent Sections (Slp Only)
B. Assemble Vent Sections (SLP Only) C. Assemble Slip Sections To attach the fi rst vent component to the starting collars WARNING! Risk of Fire or Asphyxiation! Overlap pipe of the appliance sections at least 1 1/2 in. (38 mm). Secure slip sections •... -
Page 43: Secure The Vent Sections
D. Secure the Vent Sections E. Disassemble Vent Sections • Vertical runs of DVP pipe must be supported every 8 ft. • Rotate either section (see Figure 10.10) so the seams (2.44 m) after the 25 ft. (7.62 m) maximum unsupported on both pipe sections are aligned as shown in Figure rise. -
Page 44: Install Decorative Ceiling Components (Slp Only)
F. Install Decorative Ceiling Components (SLP only) Level A decorative ceiling thimble can be installed on a fl at ceil- ing through which the vent passes. The decorative ceiling Cathedral ceiling thimble is used to cover the fi restop, which is installed support box according to section 8.C. -
Page 45: Install Metal Roof Flashing
G. Install Metal Roof Flashing NOTICE: Failure to properly caulk the roof fl ashing could cause water entry. Note: Skip to Section 10.I. if using the RF4-8. • Caulk the gap between the roof fl ashing and the outside • See minimum vent heights for various pitched roofs diameter of the pipe. -
Page 46: Install Rf4-8
I. Install RF4-8 The RF4-8 may be used in place of the roof fl ashing and storm collar (Sections 10.G. and 10.H.) Pipe must be supported within 12 in. (305 mm) of the roofl ine using plumbers strapping or an SLP-FS when us- ing the RF4-8 Flashing. -
Page 47: Install Vertical Termination Cap
J. Install Vertical Termination Cap L. Heat Shield Requirements for Horizontal Termination • Attach the vertical termination cap by sliding the inner collar of the cap into the inner fl ue of the pipe section WARNING! Risk of Fire! To prevent overheating and fi re, while placing the outer collar of the cap over the outer heat shields must extend through the entire wall thick- fl... -
Page 48: Install Horizontal Termination Cap
M. Install Horizontal Termination Cap • When installing a horizontal termination cap, follow the cap location guidelines as prescribed by current WARNING! Risk of Fire! The telescoping fl ue section ANSI Z223.1 and CAN/CGA-B149 installation codes of the termination cap MUST be used when connecting and refer to Section 6 of this manual. -
Page 49: Gas Information
11 11 Gas Information A. Fuel Conversion C. Gas Connection • Make sure the appliance is compatible with available • Refer to Reference Section 16.A. for location of gas line gas types. access in appliance. • Conversions must be made by a qualified service •... -
Page 50: Electrical Information
Electrical Information B. Standing Pilot Ignition System Wiring A. Wiring Requirements • The standing pilot ignition system wiring does not require NOTICE: This appliance must be electrically wired a 110 VAC supply to operate. and grounded in accordance with local codes or, in the •... -
Page 51: Electrical Service And Repair
E. Electrical Service and Repair WARNING! Risk of Shock! Replace damaged wire with type 105° C rated wire. Wire must have high temperature WARNING! Risk of Shock! Label all wires prior to insulation. disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. -
Page 52: Junction Box Installation
F. Junction Box Installation If the box is being wired from the OUTSIDE of the appli- ance: Romex Connector • Remove the cover plate located on the outer shell - right side (see Figure 12.4). 14/2WG • Install the supplied Romex™ connector in the cover plate. -
Page 53: Finishing
Finishing A. Mantel and Wall Projections B. Facing Material • Metal front faces may be covered with non-combustible WARNING! Risk of Fire! Comply with all minimum clear- materials only. ances to combustibles as specifi ed. Framing or fi nishing • Facing and/or fi... -
Page 54: Appliance Setup
Appliance Setup A. Remove Fixed Glass Assembly I. Install the Log Assembly See Section 14.J. • Base logs have been permanently mounted on the grate assembly and should not be moved. See Figure 12.5. B. Remove the Shipping Materials Remove shipping materials from inside or underneath the fi... -
Page 55: Fixed Glass Assembly
J. Fixed Glass Assembly K. Install Louvers and Trim • Install optional trim kits and/or surrounds using the WARNING! Risk of Asphyxiation! Handle fi xed glass instructions included with the accessory. assembly with care. Inspect the gasket to ensure it is •... -
Page 56: Troubleshooting
Troubleshooting With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualifi ed service technician in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualifi ed service technician. Con- tact your dealer to arrange a service call by a qualifi... - Page 57 A. Standing Pilot Ignition System (continued) Symptom Possible Cause Corrective Action 3. (Continued) C. Failed valve. Turn the valve knob to the ON position. Place the ON/OFF switch in the ON position. Check the millivolt meter a the thermopile terminals. The millivolt meter should read greater than 125mV. If the reading is acceptable, and if the burner does not come on, replace the gas valve.
-
Page 58: Intellifi Re Ignition System
B. Intellifi re Ignition System Symptom Possible Cause Corrective Action 1. Pilot won’t light. The A. Incorrect wiring. Verify “S” wire (white) for sensor and “I” wire (orange) for ignitor are ignitor/module makes connected to correct terminals on module and pilot assembly. noise, but no spark. - Page 59 B. Intellifi re Ignition System (continued) Symptom Possible Cause Corrective Action 4. Pilot lights but continues A. A shorted or loose connection Verify all connections to wiring diagram in manual. Verify to spark, and main burner in fl ame sensing rod. connections underneath pilot assembly are tight.
-
Page 60: Reference Materials
Reference Materials A. Appliance Dimension Diagram Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 3. 23 in. (584 mm) 15-1/4 in. (387 mm) Alternative Gas Line Access Gas Line 33-1/2 in. 38-1/2 in. -
Page 61: Vent Components Diagrams
B. Vent Components Diagrams Effective Height/Length 4-7/8 in. Pipe inches (124 mm) DVP4 10-1/2 in. DVP6 45° (267 mm) Effective DVP12 Height/Length DVP24 DVP36 DVP48 1219 DVP6A 3 - 6 76 - 152 10-7/8 in. DVP12A 3 - 12 76 - 305 (276 mm) DVP45 DVP Pipe... - Page 62 B. Vent Components Diagrams (continued) 31 in. (787 mm) 24-5/8 in. 13-1/4 in. (625 mm) (367 mm) 27-1/2 in. 24-5/8 in. 13-1/4 in. (698 mm) (625 mm) (367 mm) RF6M RF12M Roof Flashing Multi-pak Roof Flashing Multi-pak 13-3/4 in. 5 in. 11-7/8 in.
- Page 63 B. Vent Components Diagrams (continued) 7-3/8 in. (187 mm) 1-1/2 in. (38 mm) 17-3/4 in. 14 in. (451 mm) (356 mm) PVK-80 (For use with IPI and DSI appliances only) 12 in. (305 mm) 3-7/8 in. (98 mm) DVP-TB1 Basement Vent Cap 10-1/2 in.
- Page 64 B. Vent Components Diagrams (continued) Note: Heat shields MUST overlap by a minimum of 1-1/2 in. (38 mm). The heat shield is designed to be used on a wall 4 in. to 7-1/4 in. (102 mm to 184 mm) thick. If wall thickness is less than 4 in. (102 mm) the existing heat shields must be field trimmed.
- Page 65 B. Vent Components Diagrams (continued) Fillers DVP-TRAP to DVP-HPC Side Filler Kit 8-1/8 in. 13 in. (206 mm) (330 mm) 15 in. (381 mm) DVP-HRC-SS Effective Length 5-1/2 in. 8-3/8 in. 5-3/4 to 8-3/8 in. 140 mm 213 mm 146 to 213 mm 3°...
- Page 66 B. Vent Components Diagrams (continued) 6-1/2 in. 165 mm 6-1/2 in. 165 mm 6-1/2 in. 165 mm 8-3/4 in. 9-1/4 in. 222 mm 6 in. 235 mm 152 mm 6-5/8 in. 168 mm 6-5/8 in. SLP-45 - 45° Elbow 168 mm 9-7/8 in.
- Page 67 B. Vent Components Diagrams (continued) SLK-SNKD SLP-CCS-BK SLP-TVHW Snorkel Cathedral Ceiling Sup- Vertical PVK-80 Termination Cap port Box-Black Termination Cap Power Vent SL-2DVP DVP-FBHT Adapter Firebrick Termination Cap (This termination cap requires an SL-2DVP adapter when used with SLP Pipe) 8-1/8 in.
-
Page 68: Service Parts
C. Service Parts Heatilator • Caliber CD Series • 4040-263 Rev M • 06/08... - Page 69 C. Service Parts (continued) Heatilator • Caliber CD Series • 4040-263 Rev M • 06/08...
- Page 70 C. Service Parts (continued) Heatilator • Caliber CD Series • 4040-263 Rev M • 06/08...
- Page 71 C. Service Parts (continued) Heatilator • Caliber CD Series • 4040-263 Rev M • 06/08...
-
Page 72: Optional Components
D. Optional Components WTBC36D 36 in. Weathered Brick Refractory Liner Kit WTBC42D 42 in. Weathered Brick Refractory Liner Kit Arts & Crafts Faux Front Modernist Faux Front Jamestown Faux Front FFCAC FFCM FFCJ Heatilator • Caliber CD Series • 4040-263 Rev M • 06/08... - Page 73 D. Optional Components (continued) CD4236 41 in. Caliber Top/Rear Direct Vent Circu- CD4842 47 in. Caliber Top-Rear Direct Vent Circu- lating Gas Appliance lating Gas Appliance Model # Description Model # Description FFCM36 Modernist-style black decorative faux front FFCM42 Modernist-style black decorative faux front FFCM36PT Modernist-style pewter decorative faux front FFCM42PT...
- Page 74 This page intentionally left blank. Heatilator • Caliber CD Series • 4040-263 Rev M • 06/08...
- Page 75 This page intentionally left blank. Heatilator • Caliber CD Series • 4040-263 Rev M • 06/08...
-
Page 76: Contact Information
E. Contact Information Please contact your Heatilator dealer with any questions or concerns. For the location of your nearest Heatilator dealer, please visit www.heatilator.com. - NOTES - ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ NOTICE DO NOT DISCARD THIS MANUAL •...
