Model(s):
EDV3633, EDV3633I, EDV3633IL
Direct Vent Gas Appliance
• Important operating and
maintenance instructions
included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fire may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or
the gas supplier.
This appliance may be installed as an OEM installation
in manufactured home (USA only) or mobile home and
must be installed in accordance with the manufacturer's
instructions and the manufactured home construction and
safety standard, Title 24 CFR, Part 3280 or Standard for
Installation in Mobile Homes, CAN/CSA Z240MH.
This appliance is only for use with the type(s) of gas
indicated on the rating plate.
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand and follow
•
these instructions for safe
installation and operation.
• CAREFULLY SUPERVISE children in same room as
• A l e r t c h i l d r e n a n d a d u l t s t o h a z a r d s o f h i g h
High temperatures may ignite clothing or other
flammable materials.
• Keep clothing, furniture, draperies and other combustibles
This appliance has been supplied with an integral
barrier to prevent direct contact with the fixed glass
panel. Do NOT operate the appliance with the barrier
removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts installation must
be performed by a licensed plumber or gas fitter;
See Table of Contents for location of additional
Commonwealth of Massachusetts requirements.
Heatilator • Eclipse • 4049-229 Rev I • 08/09
Owner's Manual
Installation and Operation
Leave this manual with
•
party responsible for
use and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation and cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
appliance.
temperatures.
away.
Installation and service of this appliance should be performed
by qualified personnel. Hearth & Home Technologies
suggests NFI certified or factory-trained professionals, or
technicians supervised by an NFI certified professional.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Heatilator Heatilator EDV3633
Summary of Contents for Heatilator Heatilator EDV3633
- Page 1 Owner’s Manual Installation and Operation Model(s): EDV3633, EDV3633I, EDV3633IL Direct Vent Gas Appliance CAUTION DO NOT DISCARD THIS MANUAL Read, understand and follow Leave this manual with • • • Important operating and these instructions for safe party responsible for maintenance instructions installation and operation.
-
Page 2: Congratulations
Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. A. Congratulations This owner’s manual should be retained for future reference. We suggest that you keep it with your other important Congratulations on selecting a Heatilator gas fireplace, an documents and product manuals. -
Page 3: Table Of Contents
Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •... - Page 4 14 Finishing A. Mantel and Wall Projections B. Facing Material 15 Appliance Setup A. Remove Packaging Materials B. Remove Glass Assembly C. Logs D. Place Lava Rock, Rockwool E. Replace Glass Install Floor Cover G. Grilles and Screen H. Air Shutter Setting Accessories 16 Troubleshooting A.
-
Page 5: Warranty
B. Warranty Hearth & Home Technologies LIMITED WARRANTY Hearth & Home Technologies (“HHT”) and its respective brands extends the following warranty for HHT gas, wood, pellet and electric appliances purchased from an authorized HHT dealer and installed in the United States of America or Canada. - Page 6 B. Warranty (continued) This limited warranty does not extend to or include surface finish on the appliance or terminations, door gasketing, glass gasketing, glass discoloration, firebrick, pellet logs, kaowool or other ceramic insulating materials. Rust and/or corrosion on any of the metal surfaces, cast iron components, baffles, firepots, doors, or firebox area are not covered by this warranty.
-
Page 7: Listing And Code Approvals
Listing and Code Approvals A. Appliance Certification C. BTU Specifications EDV3633 Series MODELS: EDV3633, EDV3633I, EDV3633IL Input Rate (NG) 20,000 20,000 LABORATORY: Underwriters Laboratories, Inc. (UL) Orifice Size (NG) 0.08 0.08 TYPE: Vented Gas Fireplace Input Rate (LP) 20,000 20,000 STANDARD: ANSI Z21.88b-2008•CSA 2.33b-2008 Orifice Size (LP) 0.05... -
Page 8: Requirements For The Commonwealth Of Massachusetts
Inspection Note: The following requirements reference various The state or local gas inspector of the side wall horizon- Massachusetts and national codes not contained in this tally vented gas fueled equipment shall not approve the document. installation unless, upon inspection, the inspector ob- serves carbon monoxide detectors and signage installed H. -
Page 9: User Guide
User Guide Operating Instructions A. Gas Fireplace Safety • Install a physical barrier such as: A decorative firescreen. WARNING Adjustable safety gate. • Install a switch lock or a wall/remote control with child HOT SURFACES! protection lockout feature. Glass and other surfaces are hot •... -
Page 10: Fan Kit 0
C. Fan Kit G. Before Lighting Fireplace • Optional Before operating this fireplace for the first time, have a qualified service technician: • Contact your dealer for the correct fan kit. • Verify all shipping materials have been removed from D. -
Page 11: Lighting Instructions (Ipi)
H. Lighting Instructions (IPI) The IPI system may be operated with two D-cell batteries. When using batteries, unplug the transformer. To prolong bat- tery life, remove them when using the transformer. Heatilator • Eclipse • 4049-229 Rev I • 08/09... -
Page 12: Lighting Instructions (Standing Pilot) 2
I. Lighting Instructions (Standing Pilot) VENT Heatilator • Eclipse • 4049-229 Rev I • 08/09... -
Page 13: After Fireplace Is Lit
J. After Fireplace is Lit Initial Break-in Procedure Indicator • The fireplace should be run three to four hours continuously on high. • Turn the fireplace off and allow it to completely cool. • Remove fixed glass assembly. See Section 15.B. •... -
Page 14: Maintenance And Service
Maintenance and Service • Clean glass with a non-abrasive commercially available Any safety screen or guard removed for servicing must be cleaner. replaced prior to operating the fireplace. Light deposits: Use a soft cloth with soap and water When properly maintained, your fireplace will give you Heavy deposits: Use commercial fireplace glass many years of trouble-free service. -
Page 15: Maintenance Tasks-Qualified Service Technician
Venting Control Compartment and Firebox Top Frequency: Seasonally Frequency: Annually By: Homeowner By: Qualified Service Technician Tools needed: Protective gloves and safety glasses. Tools needed: Protective gloves, vacuum cleaner, dust cloths • Inspect venting and termination cap for blockage or obstruction such plants, bird nests, leaves, snow, debris, •... - Page 16 (Either cobrahead or SIT) Figure 3.1 IPI Pilot Flame Patterns Figure 3.2 Standing Pilot Flame Patterns Heatilator • Eclipse • 4049-229 Rev I • 08/09...
-
Page 17: Installer Guide
Installer Guide Getting Started A. Typical Appliance System NOTICE: Illustrations and photos reflect typical installations and are for design purposes only. Illustrations/diagrams are not drawn to scale. Actual product may vary from pictures in manual Vertical Termination Cap (SECTION 10) Noncombustible roof Storm Collar flashing maintains minimum... -
Page 18: Design And Installation Considerations 8
B. Design and Installation Considerations D. Inspect Appliance and Components Heatilator direct vent gas appliances are designed to op- • Carefully remove the appliance and components from erate with all combustion air siphoned from outside of the the packaging. building and all exhaust gases expelled to the outside. No •... -
Page 19: Framing And Clearances
Framing and Clearances A. Selecting Appliance Location NOTICE: Illustrations reflect typical installations and are FOR DESIGN PURPOSES ONLY. Illustrations/diagrams When selecting a location for the appliance it is important are not drawn to scale. Actual installation may vary due to to consider the required clearances to walls (see Figure individual design preference. -
Page 20: Constructing The Appliance Chase
B. Constructing the Appliance Chase To further prevent drafts, the wall shield and ceiling fire- stops should be caulked with high temperature caulk to A chase is a vertical box-like structure built to enclose the seal gaps. Gas line holes and other openings should be gas appliance and/or its vent system. -
Page 21: Mantel And Wall Projections
D. Mantel and Wall Projections Mantel Legs or Wall Projections WARNING! Risk of Fire! Comply with all minimum clear- ances to combustibles as specified. Framing or finishing material closer than the minimums listed must be construct- ed entirely of non-combustible materials (i.e., steel studs, concrete board, etc). -
Page 22: Termination Locations
Termination Locations A. Vent Termination Minimum Clearances 6 in. (minimum) up to 20 in. 18 in. minimum WARNING 152 mm/508 mm 457 mm 20 in. and over 0 in. minimum Fire Risk. Gas, Wood or Fuel Oil Maintain vent clearance to combustibles as Termination Cap specified. - Page 23 Fixed Openable Fixed Closed Closed GAS METER V TERMINATION CAP AIR SUPPLY INLET RESTRICTION ZONE (TERMINATION NOT ALLOWED) Measure vertical clearances from this surface Electrical Service Covered Alcove Measure horizontal clearances Clearances to Electrical Service Applications from this surface. Dimension Descriptions P 6”...
-
Page 24: Vent Information And Diagrams
Vent Information and Diagrams A. Approved Pipe This appliance is approved for use with Hearth & Home Technologies SLP venting systems. Refer to Section 7.B for vent component information. Vertical DO NOT mix pipe, fittings or joining methods from differ- ent manufacturers. -
Page 25: Vent Diagrams
E. Vent Diagrams To replace the first starter elbow with two 45° elbows, refer to Figure 7.4. All other 90° elbows can be replaced with two 45° elbows. General Rules: • SUBTRACT ft. from the total H measurement for each 90°... - Page 26 1. Top Vent - Horizontal Termination - (continued) Two 45° Elbows replacing One 90° Elbow 4 ft min. (1.22 m) 25 ft max. (7.62 m) Figure 7.4 min. max. max. H max. Two Elbows Note: For corner installations: A 6 in. (52 mm) section of straight 0.5 .8 pipe may need to be attached...
- Page 27 1. Top Vent - Horizontal Termination - (continued) min. max. max. Three Elbows 0.0 7.2 5.79 Figure 7.6 Heatilator • Eclipse • 4049-229 Rev I • 08/09...
- Page 28 2. Top Vent - Vertical Termination Note: If installing a vertical vent/ No Elbow termination off the top of the ap- pliance, the flue restrictor should be used. 12 ft (3.66 m) min. 60 ft (18.29 m) min. Figure 7.7 Two Elbows Maximum horizontal run is 100% of...
- Page 29 2. Top Vent - Vertical Termination - (continued) Three Elbows Maximum horizontal run is 100% of vertical, but cannot exceed 26 ft (7.92 m) 12 ft (3.66 m) min. 60 ft (18.29 m) max. Figure 7.9 Heatilator • Eclipse • 4049-229 Rev I • 08/09...
-
Page 30: Vent Clearances And Framing
Vent Clearances and Framing A. Pipe Clearances to Combustibles B. Wall Penetration Framing Combustible Wall Penetration WARNING! Risk of Fire! Maintain air space clearance to vent. DO NOT pack insulation or other combustibles: Whenever a combustible wall is penetrated, you must frame a hole for the wall shield firestops. -
Page 31: Install The Ceiling Firestop
C. Install the Ceiling Firestop A ceiling firestop MUST be used between floors and attics. • Frame opening 9 in. x 9 in. (229 mm x 229 mm) whenever the vent penetrates Attic Above a ceiling/floor (see Figure 8.). • Frame the area with the same sized lumber 9 in. -
Page 32: Install Attic Insulation Shield 2
D. Install Attic Insulation Shield WARNING! Fire Risk. DO NOT allow loose materials or insulation to touch vent. Hearth & Home Technologies Inc. requires the use of an attic shield. The National Fuel Gas Code ANSI Z223.1 and NFPA 54 requires an attic shield constructed of 26 gauge minimum metal that extends at least 2 in. -
Page 33: Appliance Preparation
Appliance Preparation A. Securing and Leveling the Appliance WARNING! Risk of Fire! Prevent contact with: • Sagging or loose insulation • Insulation backing or plastic • Framing and other combustible materials Block openings into the chase to prevent entry of blown-in insulation. -
Page 34: Installing Slp Vent Pipe
Installing SLP Vent Pipe A. Assemble Vent Sections B. Assemble Slip Sections To attach the first vent component to the starting collars WARNING! Risk of Fire or Asphyxiation! Overlap pipe of the appliance sections at least 1 1/2 in. (38 mm). Secure slip sections •... -
Page 35: Securing The Vent Sections 5
C. Securing the Vent Sections D. Disassemble Vent Sections • Vertical runs of SLP pipe must be supported every 8 ft. • Rotate either section (see Figure 0.6) so the seams (2.44 m). on both pipe sections are aligned as shown in Figure 0.7. -
Page 36: Installing Metal Roof Flashing 6
E. Installing Metal Roof Flashing NOTICE: Failure to properly caulk the roof flashing could cause water entry. • See minimum vent heights for various pitched roofs (Figure 0.8) to determine the length of pipe to extend • Caulk the gap between the roof flashing and the outside through the roof. -
Page 37: Installing Vertical Termination Cap 7
F. Installing Vertical Termination Cap G. Assemble and Install Storm Collar • Attach the vertical termination cap by sliding the inner CAUTION! Risk of Cuts, Abrasions or Flying Debris. collar of the cap into the inner flue of the pipe section Wear protective gloves and safety glasses during installa- while placing the outer collar of the cap over the outer tion. -
Page 38: Install Heat Shields And Horizontal Termination Cap 8
H. Install Heat Shields and Horizontal Termi- nation Cap WARNING! Risk of Fire! To prevent overheating and fire, heat shields must extend through the entire wall thick- ness. • DO NOT remove the heat shields attached to the wall shield firestop and the horizontal termination cap. - Page 39 Install Horizontal Termination Cap • When installing a horizontal termination cap, follow the cap location guidelines as prescribed by current WARNING! Risk of Fire! The telescoping flue section ANSI Z223.1 and CAN/CGA-B149 installation codes of the termination cap MUST be used when connecting and refer to Section 6 of this manual.
-
Page 40: Shrouds
Shrouds A. HHT Shrouds • You may install a shroud with this fireplace. See Section 17.D. for a list of UL Listed shrouds. Follow the instructions included with these optional components B. Field Constructed Shrouds WARNING! Risk of Fire! Shrouds must be constructed as specified. - Page 41 Mailbox Style Shroud (may be used with DVP-TV, DVP-TVHW, SLP-TVHW) Min. Base Dims. Min. Height 20 x 20 508 x 508 Min. Height Min. Base Dim Min. Base Dim Figure 11.2 Mailbox Style Shroud Dimensions Roofed Style Shroud (may be used with DVP-TV, DVP-TVHW, SLP-TVHW) Min.
-
Page 42: Gas Information
Gas Information A. Fuel Conversion C. Gas Connection • Make sure the appliance is compatible with available • Refer to Reference Section 7 for location of gas line gas types. access in appliance. • Conversions must be made by a qualified service •... -
Page 43: Electrical Information
Electrical Information B. Standing Pilot Ignition System Wiring A. Wiring Requirements • Refer to Figure 13.2, Standing Pilot Wiring Diagram NOTICE: This appliance must be electrically wired • The standing pilot ignition system wiring does not require and grounded in accordance with local codes or, in the a 0 VAC supply to operate. -
Page 44: Electrical Service And Repair
E. Electrical Service and Repair WARNING! Risk of Shock! Replace damaged wire with type 105° C rated wire. Wire must have high temperature WARNING! Risk of Shock! Label all wires prior to insulation. disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. -
Page 45: Junction Box Installation
F. Junction Box Installation If the box is being wired from the OUTSIDE of the appli- ance: Romex • Remove the cover plate located on the outer shell - right Connector side (see Figure .4). • Install the supplied Romex™ connector in the cover 14/2WG plate. -
Page 46: Finishing
Finishing A. Mantel and Wall Projections B. Facing Material • Metal front faces may be covered with non-combustible WARNING! Risk of Fire! Comply with all minimum clear- materials only. ances to combustibles as specified. Framing or finishing • Facing and/or finishing materials must not interfere with material closer than the minimums listed must be construct- air flow through louvers, operation of louvers or doors, ed entirely of non-combustible materials (i.e., steel studs,... -
Page 47: Appliance Setup
Appliance Setup A. Remove Packaging Materials • Pull the four glass assembly latches out of the groove on the glass frame. See Figure 5. Face parts are shipped in tube on glass protector. To remove glass protector unlatch top glass latches and remove glass protector. -
Page 48: Replace Glass
G. Grilles and Screen • Place a small amount of /2 in. ( mm) diameter pieces (dime-size) of rockwool on the burner pan so that the • Lay top grille face down so the thin tabs are pointing rockwool touches but does not cover the holes in the burner pan. -
Page 49: Air Shutter Setting
H. Air Shutter Setting • Swivel the top grill toward the unit and apply slight pressure downward and push forward until the notch This appliance has an adjustable air shutter (which locks into the slot. Refer to Figure 5.. controls the primary air) that can be accessed under the •... -
Page 50: Troubleshooting
Troubleshooting With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualified service technician in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualified service technician. Con- tact your dealer to arrange a service call by a qualified service technician. - Page 51 Troubleshooting (continued) Symptom Possible Cause Corrective Action . (Continued) C. Failed valve. Turn the valve knob to the ON position. Place the ON/OFF switch in the ON position. Check the millivolt meter a the thermopile terminals. The millivolt meter should read greater than 25mV. If the reading is acceptable, and if the burner does not come on, replace the gas valve.
-
Page 52: Intellifire Ignition System
B. Intellifire Ignition System Symptom Possible Cause Corrective Action . Pilot won’t light. The A. Incorrect wiring. Verify “S” wire (white) for sensor and “I” wire (orange) for ignitor are ignitor/module makes connected to correct terminals on module and pilot assembly. noise, but no spark. - Page 53 Intellifire Ignition System - (continued) Symptom Possible Cause Corrective Action 4. Pilot lights but continues A. A shorted or loose connection Verify all connections to wiring diagram in manual. Verify connections to spark, and main burner in flame sensing rod. underneath pilot assembly are tight.
-
Page 54: Reference Materials
Reference Materials A. Appliance Dimension Diagram Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section . 17-1/8 in. 435 mm 10-7/8 in. 10-7/8 in. 276 mm 276 mm 33-1/4 in./845 mm 35-1/2 in./902 mm 5 in. -
Page 55: Vent Components Diagrams
B. Vent Components Diagrams 6-1/2 in. 165 mm 6-1/2 in. 165 mm 6-1/2 in. 165 mm 8-3/4 in. 9-1/4 in. 222 mm 6 in. 235 mm 152 mm 6-5/8 in. 168 mm 6-5/8 in. SLP-45 - 45° Elbow 168 mm 9-7/8 in. - Page 56 B. Vent Components Diagrams (continued) SLK-SNKD SLP-TVHW Snorkel Vertical PVK-80 Termination Cap Termination Cap Power Vent DVP-FBHT SL-2DVP Horizontal Termination Cap Adapter (This termination cap requires an SL-2DVP adapter when used with SLP Pipe) 8-1/8 in. 13 in. (206 mm) (330 mm) 15 in.
- Page 57 B. Vent Components Diagrams (continued) Note: Heat shields MUST overlap by a minimum of 1-1/2 in. (38 mm). The heat shield is designed to be used on a wall 4 in. to 7-1/4 in. (102 mm to 184 mm) thick. If wall thickness is less than 4 in. (102 mm) the existing heat shields must be field trimmed.
-
Page 58: Service Parts
C. Service Parts Heatilator • Eclipse • 4049-229 Rev I • 08/09... - Page 59 C. Service Parts (continued) Heatilator • Eclipse • 4049-229 Rev I • 08/09...
- Page 60 C. Service Parts (continued) Heatilator • Eclipse • 4049-229 Rev I • 08/09...
-
Page 61: Optional Components
D. Optional Components 20 in. [508 mm] 17 in. [432 mm] 9-3/8 in. [238 mm] LDS33/LDS46 Decorative Shroud TCG375 Terra Cotta Cap Catalog # LDS LDS46 29 829 LDSCP-M Shroud Leg Multipack (not shown) LDS-BV Decorative Shroud Catalog # 2.5 5.5 LDS-BV See your Heatilator dealer for a complete listing of optional components. - Page 62 This page intentionally left blank. Heatilator • Eclipse • 4049-229 Rev I • 08/09...
- Page 63 This page intentionally left blank. Heatilator • Eclipse • 4049-229 Rev I • 08/09...
-
Page 64: Contact Information
E. Contact Information Please contact your Heatilator dealer with any questions or concerns. For the location of your nearest Heatilator dealer, please visit www.heatilator.com. - NOTES - ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ NOTICE DO NOT DISCARD THIS MANUAL •...
