Heatilator CNXT4236IT Owner's Manual

Heatilator CNXT4236IT Owner's Manual

Direct vent gas appliance
Hide thumbs Also See for Heatilator CNXT4236IT:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
Model(s):
CNXT4236IT
CNXT4842IT
CNXT4236IH
CNXT4842IH
CNXT4236ILT
CNXT4842ILT
CNXT4236ILH
CNXT4842ILH
Direct Vent Gas Appliance
• Important operating and
maintenance instructions
included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or
the gas supplier.
This appliance may be installed as an OEM installation
in manufactured home (USA only) or mobile home and
must be installed in accordance with the manufacturer's
instructions and the manufactured home construction and
safety standard, Title 24 CFR, Part 3280 or Standard for
Installation in Mobile Homes, CAN/CSA Z240MH.
This appliance is only for use with the type(s) of gas
indicated on the rating plate.
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand and follow
•
these instructions for safe
installation and operation.
In the Commonwealth of Massachusetts installation must
be performed by a licensed plumber or gas fi tter;
See Table of Contents for location of additional
Commonwealth of Massachusetts requirements.
Heatilator • Caliber CNXT Series • 4047-132 Rev T • 09/08
Owner's Manual
Leave this manual with
•
party responsible for
use and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation and cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
appliance.
• A l e r t c h i l d r e n a n d a d u l t s t o h a z a r d s o f h i g h
temperatures.
High temperatures may ignite clothing or other
fl ammable materials.
• Keep clothing, furniture, draperies and other combustibles
away.
This appliance has been supplied with an integral
barrier to prevent direct contact with the fi xed glass
panel. Do NOT operate the appliance with the barrier
removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
Installation and service of this appliance should be performed
by qualifi ed personnel. Hearth & Home Technologies suggests
NFI certifi ed or factory-trained professionals, or technicians
supervised by an NFI certifi ed professional.
Installation and Operation
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Heatilator CNXT4236IT and is the answer not in the manual?

Questions and answers

Related Manuals for Heatilator Heatilator CNXT4236IT

Summary of Contents for Heatilator Heatilator CNXT4236IT

  • Page 1 Owner’s Manual Installation and Operation Model(s): CNXT4236IT CNXT4842IT CNXT4236IH CNXT4842IH CNXT4236ILT CNXT4842ILT CNXT4236ILH CNXT4842ILH Direct Vent Gas Appliance CAUTION DO NOT DISCARD THIS MANUAL Read, understand and follow Leave this manual with • Important operating and • • these instructions for safe party responsible for maintenance instructions installation and operation.

  • Page 2: Congratulations

    Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. A. Congratulations This owner’s manual should be retained for future reference. We suggest that you keep it with your other important Congratulations on selecting a Heatilator gas fi replace, an documents and product manuals.

  • Page 3: Table Of Contents

    Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •...
  • Page 4 13 Finishing A. Mantel and Wall Projections B. Facing Material 14 Appliance Setup A. Remove Glass Assembly B. Remove the Shipping Materials C. Clean the Appliance D. Accessories E. Heat-Zone-Gas Lava Rock, Vermiculite, Rockwool Placement G. Log Assembly H. Fixed Glass Assembly Install Trim and/or Surrounds Install Hood K.

  • Page 5: Warranty

    B. Warranty Hearth & Home Technologies LIMITED WARRANTY Hearth & Home Technologies (“HHT”) and its respective brands extends the following warranty for HHT gas, wood, pellet and electric appliances purchased from an authorized HHT dealer and installed in the United States of America or Canada.
  • Page 6 B. Warranty (continued) This limited warranty does not extend to or include surface fi nish on the appliance or terminations, door gasketing, glass gasketing, glass discoloration, fi rebrick, pellet logs, kaowool or other ceramic insulating materials. Rust and/or corrosion on any of the metal surfaces, cast iron components, baffl es, fi repots, doors, or fi rebox area are not covered by this warranty.

  • Page 7: Listing And Code Approvals

    Listing and Code Approvals A. Appliance Certifi cation D. High Altitude Installations MODELS: CNXT4236IT, CNXT4842IT, CNXT4236IH, NOTICE: If the heating value of the gas has been reduced, CNXT4842IH, CNXT4236ILT, CNXT4842ILT, these rules do not apply. Check with your local gas utility or CNXT4236ILH, CNXT4842ILH authorities having jurisdiction.

  • Page 8: Requirements For The Commonwealth Of Massachusetts

    Inspection Note: The following requirements reference various The state or local gas inspector of the side wall horizon- Massachusetts and national codes not contained in this tally vented gas fueled equipment shall not approve the document. installation unless, upon inspection, the inspector ob- serves carbon monoxide detectors and signage installed H.

  • Page 9: User Guide

    User Guide Operating Instructions A. Gas Fireplace Safety • Install a physical barrier such as: A decorative fi rescreen. WARNING Adjustable safety gate. • Install a switch lock or a wall/remote control with child HOT SURFACES! protection lockout feature. Glass and other surfaces are hot •...

  • Page 10: Fan Kit (Optional)

    C. Fan Kit (optional) F. Fixed Glass Assembly If desired, a fan kit may be added. Contact your dealer to See Section 14. order the correct fan kit. G. Remote Controls, Wall Controls and Wall D. Clear Space Switches Follow the instructions supplied with the control installed WARNING! DO NOT place combustible objects in front of to operate your fi...

  • Page 11: Lighting Instructions (Ipi)

    I. Lighting Instructions (IPI) • For normal use, activate/deactivate your fi replace with the wall switch or remote control. • The IPI system may be operated with two D-cell batteries. When using batteries, unplug the transformer. To prolong battery life, remove them when using the transformer. •...

  • Page 12: After Fireplace Is Lit

    J. After Fireplace is Lit Initial Break-in Procedure • The fireplace should be run three to four hours continuously on high. • Turn the fi replace off and allow it to completely cool. • Remove fi xed glass assembly. See Section 14.H. •...

  • Page 13: Maintenance And Service

    Maintenance and Service • Carefully set fi xed glass assembly in place on fi replace. Any safety screen or guard removed for servicing must be Hold glass in place with one hand and secure glass replaced prior to operating the fi replace. latches with the other hand.

  • Page 14: Maintenance Tasks-Qualifi Ed Service Technician

    B. Maintenance Tasks-Qualifi ed Service Burner Ignition and Operation Technician Frequency: Annually The following tasks must be performed by a qualifi ed By: Qualifi ed Service Technician service technician. Tools needed: Protective gloves, vacuum cleaner, whisk Gasket Seal and Glass Assembly Inspection broom, fl...

  • Page 15: Installer Guide

    Installer Guide Getting Started A. Typical Appliance System NOTICE: Illustrations and photos refl ect typical installations and are for design purposes only. Illustrations/diagrams are not drawn to scale. Actual product may vary from pictures in manual Note: Dual venting confi gurations ARE NOT allowed.

  • Page 16: Design And Installation Considerations

    B. Design and Installation Considerations D. Inspect Appliance and Components Heatilator direct vent gas appliances are designed to op- • Carefully remove the appliance and components from erate with all combustion air siphoned from outside of the the packaging. building and all exhaust gases expelled to the outside. No •...

  • Page 17: Framing And Clearances

    Framing and Clearances A. Selecting Appliance Location NOTICE: Illustrations refl ect typical installations and are FOR DESIGN PURPOSES ONLY. Illustrations/diagrams When selecting a location for the appliance it is important are not drawn to scale. Actual installation may vary due to to consider the required clearances to walls (see Figure individual design preference.

  • Page 18: Constructing The Appliance Chase

    B. Constructing the Appliance Chase To further prevent drafts, the wall shield and ceiling fi re- stops should be caulked with high temperature caulk to A chase is a vertical box-like structure built to enclose the seal gaps. Gas line holes and other openings should be gas appliance and/or its vent system.

  • Page 19: Mantel And Wall Projections

    D. Mantel and Wall Projections WARNING! Risk of Fire! Comply with all minimum clear- ances to combustibles as specifi ed. Framing or fi nishing material closer than the minimums listed must be construct- ed entirely of noncombustible materials (i.e., steel studs, concrete board, etc).

  • Page 20: Termination Locations

    Termination Locations A. Vent Termination Minimum Clearances Direct Vent Gas, Wood or Fuel WARNING Oil Termination 20 in. Fire Risk. (508 mm) (minimum) to 18 in. Maintain vent clearance to combustibles as Perpendicular (457 mm) Wall specifi ed. (DV only) •...
  • Page 21 Fixed Openable Fixed Closed Closed GAS METER V TERMINATION CAP AIR SUPPLY INLET RESTRICTION ZONE (TERMINATION NOT ALLOWED) Measure vertical clearances from this surface Electrical Service Covered Alcove Measure horizontal clearances Clearances to Electrical Service Applications from this surface. Dimension Descriptions P 6”...

  • Page 22: Vent Information And Diagrams

    Vent Information and Diagrams A. Approved Pipe This appliance is approved for use with Hearth & Home Technologies DVP and/or SLP venting systems. Refer to Section 16B for vent component information. Vertical DO NOT mix pipe, fi ttings or joining methods from differ- ent manufacturers.

  • Page 23: Vent Diagrams

    E. Vent Diagrams Note: The CNXT series appliances can adapt to SLP series vent pipe when venting off the top of To replace the fi rst starter elbow with two 45° elbows, the appliance. You must use a DVP-SLP24 adapter refer to Figure 7.4.
  • Page 24 1. Top Vent - Horizontal Termination - (continued) Two 45° Elbows replacing One 90° Elbow 4 ft min. (1.22 m) 25 ft max. (7.62 m) Figure 7.4 min. max. max. H max. Two Elbows 0.15 1.83 0.30 3.35 3.35 0.46 5.49 5.49 0.61...
  • Page 25 1. Top Vent - Horizontal Termination - (continued) min. max. max. Three Elbows 0.30 7.32 5.79 0.30 6.71 5.79 Installed Vertically Figure 7.6 Heatilator • Caliber CNXT Series • 4047-132 Rev T • 09/08...
  • Page 26 2. Top Vent - Vertical Termination Note: If installing a vertical vent/ No Elbow termination off the top of the appli- ance, the vertical termination baffl e should be used. 12 ft (3.66 m) min. 60 ft (18.29 m) max. Figure 7.7 Note: If installing a vertical vent/ Two Elbows...
  • Page 27 2. Top Vent - Vertical Termination - (continued) Note: If installing a vertical vent/ Three Elbows termination off the top of the appli- ance, the vertical termination baffl e should be used. Maximum horizontal run is 100% of vertical, but cannot exceed 26 ft (7.92 m) 12 ft (3.66 m) min.
  • Page 28 3. Rear Vent - Horizontal Termination No Elbow 18 in. (457 mm) max. Figure 7.10 One 45° Elbow 18 in. (457 mm) max. Figure 7.11 Heatilator • Caliber CNXT Series • 4047-132 Rev T • 09/08...
  • Page 29 3. Rear Vent - Horizontal Termination - (continued) max. min. max. Two Elbows 0.61 0.30 0.91 1.22 0.61 1.83 1.83 0.91 2.74 2.44 1.22 3.66 2.44 1.52 4.57 2.44 1.83 5.49 Figure 7.12 Three Elbows max. min. max. 0.61 0.30 0.91 1.22 0.61...
  • Page 30 4. Rear Vent - Vertical Termination One Elbow 0 min. 6 ft (1.83 m) max. 12 ft (3.66 m) min. 60 ft (18.29 m) max. Figure 7.14 Two Elbows 0 min. 12 ft (3.66 m) min. 6 ft (1.83 m) max. 60 ft (18.29 m) max.
  • Page 31 4. Rear Vent - Vertical Termination - (continued) Three Elbows 0 min. 6 ft (1.83 m) max. 12 ft (3.66 m) min. 60 ft (18.29 m) max. Maximum horizontal run is 100% of vertical, but can- not exceed 26 ft (7.92 m). Figure 7.16 Heatilator •...

  • Page 32: Installing Vertical Termination Baffl E

    • Part of the refractory must be removed before installing F. Installing Vertical Termination Baffl e the vertical baffl e. Remove the four screws holding the refractory Note: For vertically terminated installations only. retainers in place. See Figure 7.19. Note: If installing a vertical vent/termination run off the top or rear of the appliance, the vertical termination baffl...
  • Page 33 • Squeeze the open end of the bent baffl e with one hand. Insert the baffl e bent side up into the inner fl ue so that the bottom of the baffl e is above the bead on the inside of the collar. See Figure 7.22. Figure 7.22 Placing the Baffl...

  • Page 34: Vent Clearances And Framing

    Vent Clearances and Framing A. Pipe Clearances to Combustibles B. Wall Penetration Framing WARNING! Risk of Fire! Maintain air space clearance to Combustible Wall Penetration vent. DO NOT pack insulation or other combustibles: Whenever a combustible wall is penetrated, you must •...

  • Page 35: Install The Ceiling Firestop

    C. Install the Ceiling Firestop A ceiling fi restop MUST be used between fl oors and attics. • DVP pipe only - Frame an opening 10 in. by 10 in. (254 mm by 254 mm) whenever the vent penetrates a ceiling/fl oor (see ATTIC ABOVE Figure 8.3).

  • Page 36: Install Attic Insulation Shield

    D. Install Attic Insulation Shield WARNING! Fire Risk. DO NOT allow loose materials or insulation to touch vent. Hearth & Home Technologies Inc. requires the use of an attic shield. The National Fuel Gas Code ANSI Z223.1 and NFPA 54 requires an attic shield constructed of 26 gauge minimum metal that extends at least 2 in.

  • Page 37: Appliance Preparation

    Appliance Preparation A. Convert from Top Vent to Rear Vent • Remove three remaining screws holding the plate surrounding fl ue. See Figure 9.3. Remove plate and set CAUTION! Risk of Cuts, Abrasions or Flying Debris. aside. Wear protective gloves and safety glasses during installa- tion.
  • Page 38 • Remove four screws holding outer collar to appliance • Remove four screws holding outer cover plate to top. See Figure 9.5. Remove outer collar. appliance back. See Figure 9.8. Remove outer cover. Figure 9.8 Outer Cover, Rear - Remove Plate •...
  • Page 39 • Place outer collar on rear of appliance and replace four • Place inner cover plate on appliance top and replace screws to hold collar in place. See Figure 9.11. Make four screws to hold inner cover plate in place. See sure insulation is attached to the collar base! Figure 9.14.
  • Page 40 • Locate heat shield cover plate removed in the fi rst step. Place the heat shield cover plate on top of heat shield. Replace four screws to hold this plate in place. See Figure 9.16. Figure 9.18 Screw Cover into Place •...

  • Page 41: Securing And Leveling The Appliance

    B. Securing and Leveling the Appliance WARNING! Risk of Fire! Prevent contact with: • Sagging or loose insulation • Insulation backing or plastic • Framing and other combustible materials Block openings into the chase to prevent entry of blown- in insulation. Make sure insulation and other materials are secured.

  • Page 42: Installing Vent Pipe

    Installing Vent Pipe A. Assemble Pipe Sections (DVP Only) Attach Pipe to the Firebox Assembly Note: The end of the pipe sections with the lanced tabs will face towards the appliance. Attach the fi rst pipe section to the starting collar: •...

  • Page 43: Assemble Vent Sections (Slp Only)

    B. Assemble Vent Sections (SLP Only) To attach the fi rst vent component to the starting collars of the appliance • Attach an SLP-DVP24 adapter to the starting collar of the appliance. • Lock the vent components into place by sliding the pipe section onto the collar.

  • Page 44: Assemble Slip Sections

    C. Assemble Slip Sections D. Secure the Vent Sections • Vertical runs of DVP pipe must be supported every 8 ft. WARNING! Risk of Fire or Asphyxiation! Overlap pipe (2.44 m) after the 25 ft. (7.62 m) maximum unsupported sections at least 1 1/2 in. (38 mm). Secure slip sections rise.

  • Page 45: Disassemble Vent Sections

    E. Disassemble Vent Sections • Use a plumb-bob to mark the center line of the venting system on the ceiling and drill a small hole through the • Rotate either section (see Figure 10.11) so the seams ceiling and roof at this point. Locate the hole and mark on both pipe sections are aligned as shown in Figure the outline of the cathedral ceiling support box on the 10.12.

  • Page 46: Install Metal Roof Flashing

    G. Install Metal Roof Flashing NOTICE: Failure to properly caulk the roof fl ashing could cause water entry. Note: Skip to Section I if using the RF4-8. • Caulk the gap between the roof fl ashing and the outside • See minimum vent heights for various pitched roofs diameter of the pipe.

  • Page 47: Assemble And Install Storm Collar

    H. Assemble and Install Storm Collar CAUTION! Risk of Cuts, Abrasions or Flying Debris. Wear protective gloves and safety glasses during installa- tion. Sheet metal edges are sharp. • Connect both halves of the storm collar with two screws (see Figure 10.17). •...

  • Page 48: Install Rf4-8

    I. Install RF4-8 The SLP-FS shown in this The RF4-8 may be used in place of the roof fl ashing and photo will not storm collar (Sections 10.H. and 10.I.) be used with DVP pipe. Pipe must be supported within 12 in. (305 mm) of the roofl...

  • Page 49: Installing Vertical Termination Cap

    J. Installing Vertical Termination Cap L. Heat Shield Requirements for Horizontal Termination • Attach the vertical termination cap by sliding the inner collar of the cap into the inner fl ue of the pipe section WARNING! Risk of Fire! To prevent overheating and fi re, while placing the outer collar of the cap over the outer heat shields must extend through the entire wall thick- fl...

  • Page 50: Install Horizontal Termination Cap

    M. Install Horizontal Termination Cap • When installing a horizontal termination cap, follow the cap location guidelines as prescribed by current WARNING! Risk of Fire! The telescoping fl ue section ANSI Z223.1 and CAN/CGA-B149 installation codes of the termination cap MUST be used when connecting and refer to Section 6 of this manual.

  • Page 51: Gas Information

    11 11 Gas Information A. Fuel Conversion C. Gas Connection • Make sure the appliance is compatible with available • Refer to Reference Section 16 for location of gas line gas types. access in appliance. • Conversions must be made by a qualified service •...

  • Page 52: Electrical Information

    Electrical Information C. Electrical Service and Repair A. Wiring Requirements WARNING! Risk of Shock! Label all wires prior to NOTICE: This appliance must be electrically wired disconnection when servicing controls. Wiring errors can and grounded in accordance with local codes or, in the cause improper and dangerous operation.

  • Page 53: Wsk-Mlt Multifunction Wall Switch

    E. WSK-MLT Multifunction Wall Switch Determine Location Determine the location for the wall switch. The chosen The WSK-MLT multifunctional wall switch is designed to location should provide an accessible location in the control fl ame height, blower speed and auxilary func- same space as the gas fi...
  • Page 54 Wiring the Wall Switch • Feed the wire to the electrical junction box and through a provided or approved strain relief. • Install the provided control wire from the fi replace to the • Connect the wires to the terminals as shown in Figure switch location.

  • Page 55: Install The Flame Solenoid

    F. Install the Flame Solenoid Gas Control Valve Knob Screw Washer Variable Washer Regulator Variable Regulator Solenoid Jam Nut Flame Control Variable Plunger Solenoid Regulator Figure 12.3 Install the Flame Solenoid • Remove the screw and knob from the variable regulator and discard.

  • Page 56: Install The Remote Cover Plate

    H. Install the Remote Cover Plate The remote cover plate shipped in the bottom of the • Place over control plate so that all of the control plate is appliance MUST be placed over the control plate before covered and legs are on bottom pan of appliance. See operating the appliance.

  • Page 57: Wsk-Mlt Operating Instructions

    I. WSK-MLT Operating Instructions J. Setting Flame Height/Manifold Pressure The ON/OFF rocker switch in the fi replace (located near (To be done by a qualifi ed service technician.) Upon initial the gas valve) must be in the “OFF” position for use with power-up of this device, valve pressure must be set for the WSK-MLT system.

  • Page 58: Service Parts List

    SET Set Temperature Button Operation Under Battery Power • Button Press: Displays Set Point A switch on the control box allows for battery power under no-power conditions (see Figure 12.9). By control- • Use UP and Down Arrows to adjust set point ling the power supply with this switch, the batteries are •...

  • Page 59: Finishing

    Finishing A. Mantel and Wall Projections B. Facing Material • Metal front faces may be covered with non-combustible WARNING! Risk of Fire! Comply with all minimum clear- materials only. ances to combustibles as specifi ed. Framing or fi nishing • Facing and/or fi...

  • Page 60: Appliance Setup

    Appliance Setup A. Remove Glass Assembly F. Lava Rock, Vermiculite, Rockwool Place- ment See Section 12.H. B. Remove the Shipping Materials Remove shipping materials from inside or underneath the fi rebox. C. Clean the Appliance Vermiculite and Rock wool Vermiculite and placement Clean/vacuum any sawdust that may have accumulated lava rock...

  • Page 61: Log Assembly

    G. Log Assembly Place the Rockwool • See Figures 14.1 and 14.4. • Base logs have been permanently mounted on the grate • Place a small amount of 1/2 in. diameter pieces assembly and should not be moved. (dime-size) of rockwool on the burner pan so that rockwool touches but does not cover the holes in the burner pan.

  • Page 62: Fixed Glass Assembly

    H. Fixed Glass Assembly I. Install Trim and/or Surrounds • Install optional trim kits and/or surrounds using the WARNING! Risk of Asphyxiation! Handle fi xed glass instructions included with the accessory. assembly with care. Inspect the gasket to ensure it is •...

  • Page 63: Troubleshooting

    Troubleshooting With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualifi ed service technician in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualifi ed service technician. Con- tact your dealer to arrange a service call by a qualifi...
  • Page 64 A. Intellifi re Ignition System (continued) Symptom Possible Cause Corrective Action 4. Pilot lights but continues A. A shorted or loose connection Verify all connections to wiring diagram in manual. Verify to spark, and main burner in fl ame sensing rod. connections underneath pilot assembly are tight.

  • Page 65: Reference Materials

    Reference Materials A. Appliance Dimension Diagram Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 5. 23 in. (584 mm) 15 in. (381 mm) 38 in. Electric 38-5/8 in. (965 mm) Access (981 mm) Gas Line Alternative...

  • Page 66: Vent Components Diagrams

    B. Vent Components Diagrams Effective Height/Length 4-7/8 in. Pipe inches (124 mm) DVP4 10-1/2 in. DVP6 45° (267 mm) Effective DVP12 Height/Length DVP24 DVP36 DVP48 1219 DVP6A 3 - 6 76 - 152 10-7/8 in. DVP12A 3 - 12 76 - 305 (276 mm) DVP45 DVP Pipe...
  • Page 67 B. Vent Components Diagrams (continued) 31 in. (787 mm) 24-5/8 in. 13-1/4 in. (625 mm) (367 mm) 27-1/2 in. 24-5/8 in. 13-1/4 in. (698 mm) (625 mm) (367 mm) RF6M RF12M Roof Flashing Multi-pak Roof Flashing Multi-pak 13-3/4 in. 5 in. 11-7/8 in.
  • Page 68 B. Vent Components Diagrams (continued) 7-3/8 in. (187 mm) 1-1/2 in. (38 mm) 17-3/4 in. 14 in. (451 mm) (356 mm) PVK-80 (For use with IPI and DSI appliances only) 12 in. (305 mm) 3-7/8 in. (98 mm) DVP-TB1 Basement Vent Cap 10-1/2 in.
  • Page 69 B. Vent Components Diagrams (continued) Note: Heat shields MUST overlap by a minimum of 1-1/2 in. (38 mm). The heat shield is designed to be used on a wall 4 in. to 7-1/4 in. (102 mm to 184 mm) thick. If wall thickness is less than 4 in. (102 mm) the existing heat shields must be field trimmed.
  • Page 70 B. Vent Components Diagrams (continued) Fillers DVP-TRAP to DVP-HPC Side Filler Kit 8-1/8 in. 13 in. (206 mm) (330 mm) 15 in. (381 mm) DVP-HRC-SS Effective Length 5-1/2 in. 8-3/8 in. 5-3/4 to 8-3/8 in. 140 mm 213 mm 146 to 213 mm 3°...
  • Page 71 B. Vent Components Diagrams (continued) 6-1/2 in. 165 mm 6-1/2 in. 165 mm 6-1/2 in. 165 mm 8-3/4 in. 9-1/4 in. 222 mm 6 in. 235 mm 152 mm 6-5/8 in. 168 mm 6-5/8 in. SLP-45 - 45° Elbow 168 mm 9-7/8 in.
  • Page 72 B. Vent Components Diagrams (continued) SLK-SNKD SLP-CCS-BK SLP-TVHW Snorkel Cathedral Ceiling Sup- Vertical PVK-80 Termination Cap port Box-Black Termination Cap Power Vent SL-2DVP DVP-FBHT Adapter Firebrick Termination Cap (This termination cap requires an SL-2DVP adapter when used with SLP Pipe) 8-1/8 in.

  • Page 73: Service Parts

    C. Service Parts Heatilator • Caliber CNXT Series • 4047-132 Rev T • 09/08...
  • Page 74 C. Service Parts (continued) Heatilator • Caliber CNXT Series • 4047-132 Rev T • 09/08...
  • Page 75 C. Service Parts (continued) Heatilator • Caliber CNXT Series • 4047-132 Rev T • 09/08...
  • Page 76 C. Service Parts (continued) Heatilator • Caliber CNXT Series • 4047-132 Rev T • 09/08...
  • Page 77 C. Service Parts (continued) Heatilator • Caliber CNXT Series • 4047-132 Rev T • 09/08...
  • Page 78 C. Service Parts (continued) Heatilator • Caliber CNXT Series • 4047-132 Rev T • 09/08...

  • Page 79: Optional Components

    D. Optional Components CNXT4236 41 in. Caliber Top/Rear Direct Vent Cir- CNXT4842 47 in. Caliber Top-Rear Direct Vent Cir- culating Gas Appliance culating Gas Appliance Model Description Model Description FFCM36 Modernist-style black decorative faux front FFCM42 Modernist-style black decorative faux front FFCM36PT Modernist-style pewter decorative faux front FFCM42PT...

  • Page 80: Contact Information

    E. Contact Information Please contact your Heatilator dealer with any questions or concerns. For the location of your nearest Heatilator dealer, please visit www.heatilator.com. - NOTES - ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ NOTICE DO NOT DISCARD THIS MANUAL •...
