MODEL:
WINS18-AU
WOOD BURNING
APPLIANCE
•
WARNING
If the information in these instructions
is not followed exactly, a fire may result
causing property damage, personal injury,
or death.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
•
Do not over fire - If heater or chimney connector
glows, you are over firing. Over firing will void your
warranty.
•
Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house fire.
Consumer Care 1-877-427-3316 - Prior to calling, please
have the model and serial number of the unit you are
calling about. This information can be found at the front of
the unit.
www.heatilator.com
DO NOT DISCARD THIS MANUAL
Important operating
•
and maintenance
instructions
included.
7065-144D • 20 August, 2018
Owner's Manual
Installation and Operation
WINS18
CAUTION
Read, understand and
follow these instructions
for safe installation and
operation.
Hot glass and appliance will cause burns.
•
Do not touch glass until it is cooled
•
Use leather gloves when reloading fuel
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
appliance.
•
Alert children and adults to hazards of high
temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other
flammable materials away.
Fire Risk.
For use with solid wood fuel only.
Other fuels may over fire and generate poisonous
gases (i.e. carbon monoxide).
•
Leave this
manual with party
responsible for use
and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
WARNING
