Eco-Choice WS Series Wood Burner Installation Instructions
Model:
WS18-AU
IMPORTANT: Read all instructions carefully before starting installation. Failure to follow these
instructions may result in a fire hazard and will void the warranty.
• Fig. 3,4,5,6, 7 and Table 1,2,3,4 relate to installations with tested flue systems; as per AS/NZS
2918:2001 - Appendix F, with a ceiling angle between 0° - 30° inclusive.
• For installations with a ceiling angle greater than 30°, refer to Fig. 7 & 8 and AS/NZS 2918:2001
4.6.3(b)
• Ceiling Plate may vary in size depending on ceiling angle. Please specify ceiling pitch prior to
ordering the ceiling plate.
• Heatilator Eco Choice series wood burner's are tested and approved to the N.Z. National Environ-
mental Standards;
Particulate Emissions = 1.3 g/kg Space Heating Efficiency = 85%
Particulate Emissions = 1.2 g/kg Space Heating Efficiency = 82%
Page 1
INSTALLATIONS TO COMPLY WITH AS/NZS2918:2001
AND WILL REQUIRE A BUILDING CONSENT
WS18-AU Eco-Choice Hardwood Certified
WS22-AU Eco-Choice Hardwood Certified
7056-153A
Model:
WS22-AU
February 7, 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eco-Choice WS18-AU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heatilator Eco-Choice WS18-AU

Summary of Contents for Heatilator Eco-Choice WS18-AU

  • Page 1 • Ceiling Plate may vary in size depending on ceiling angle. Please specify ceiling pitch prior to ordering the ceiling plate. • Heatilator Eco Choice series wood burner’s are tested and approved to the N.Z. National Environ- mental Standards; WS18-AU Eco-Choice Hardwood Certified Particulate Emissions = 1.3 g/kg Space Heating Efficiency = 85%...
  • Page 2 Hearth & Home Technologies welcomes you to our tradi- our stoves, inserts and fireplaces. And yet we are old-fash- tion of excellence! In choosing a Heatilator appliance, you ioned when it comes to craftsmanship. Each unit is meticu- have our assurance of commitment to quality, durability, and lously fabricated and surfaces are hand-finished for lasting performance.
  • Page 3 WS Series Wood Burner Heatilator WS18 Wood Burner Dimensions 19-1/16 in. (484 mm) 25 in. (635mm) 9-5/16 in. 12-1/2 in. (236 mm) (317mm) 14-13/16 in. (376 mm) 13-13/16 in. 9-9/16 in. (350 mm) (242 mm) 29 in. (736 mm) 19-11/16 in. (500 mm) 21-11/16 in.

  • Page 4: Floor Protector

    WS Series Wood Burner FLOOR PROTECTOR Heatilator WS18 does not require a insulating Floor Protector, as they are tested and comply with the minimum Floor Protector requirements of AS/NZS 2918:2001. Note: ▪ The minimum Floor Protector sizes are specified in the clearance chart, see Table 1 & 2.

  • Page 5: Firebox Installation

    WS Series Wood Burner CORNER POSITIONING (45°) Fig. 4 FLOOR PROTECTOR Table 2 DESCRIPTION Default Flue Kit Min. clearance from firebox corner to corner walls Min. distance from center of spigot to corner walls Min. distance from corner wall to floor protector front 1219 Min.
  • Page 6 WS Series Wood Burner Heatilator WS22 Wood Burner Dimensions 19-1/16 in. 26 in. (660mm) (484mm) 13 in. (330mm) 9-13/16 in. (249mm) 14-13/16 in. 13-13/16 in. (376mm) (351mm) 9-9/16 in. (243mm) 34 in. (864mm) 19-5/8 in. (499mm) 21-11/16 in. (551mm) Figure 29.1 - Front View Figure 29.2 -Top View...
  • Page 7 WS Series Wood Burner FLOOR PROTECTOR Heatilator WS22 does not require a insulating Floor Protector, as they are tested and comply with the minimum Floor Protector requirements of AS/NZS 2918:2001. Note: ▪ The minimum Floor Protector sizes are specified in the clearance chart, see Table 3 & 4.
  • Page 8 WS Series Wood Burner CORNER POSITIONING (45°) CORNER POSITIONING (45°) Fig. 6 FLOOR PROTECTOR Table 4 DESCRIPTION Default Flue Kit Min. clearance from firebox corner to corner walls Min. distance from center of spigot to corner walls Min. distance from corner wall to floor protector front 1217 Min.

  • Page 9: General Instructions For Flue System

    WS Series Wood Burner GENERAL INSTRUCTIONS FOR FLUE SYSTEM ▪ Flue pipe installed crimp/narrow end down ▪ Outer casings installed crimped/narrow end up. (Critical when exposed above the roof) ▪ Inner casings - direction not critical ▪ Flue pipes - seal all joints including firebox spigot. - fix with a minimum of 3 stainless steel rivets ▪...
  • Page 10 WS Series Wood Burner FLUE PENETRATION Tested flue systems, as per AS/NZS 2918:2001 Fig. 7 ADD Cowl Fig. 5 Casing Cover oversized casing cover minimum 25mm gap is necessary between flue pipe casing & Spider Bracket combustible material Non combustible material Hebel block or 12mm Promina board or similar under the flashing...
  • Page 11 WS Series Wood Burner   FLUE PENETRATION 1.QF.1F     Un-tested flue systems, as per AS/NZS 2918:2001, 4.6.3(b)         ADD Cowl Fig. 8 Fig. 6       AS/NZS2918:2001   Casing Cover   Un-tested flue with sloped ceiling Spider Bracket penetration greater than 30°...

  • Page 12: Minimum Height Of Flue System Exit

    WS Series Wood Burner GENERAL INSTRUCTIONS FOR FLUE SYSTEM 1. Unpack the Flue Mounted Shield, detach the three brackets and familiarize yourself with the illus- trations. 2. Using a sharp knife or razor blade, carefully cut through the plastic film on the “inside face” where it meets the outer shield (refer sketch).
  • Page 13 WS Series Wood Burner AS/NZS 2918:2001 GENERAL NOTES WARNINGS: WARNING: THE APPLIANCE AND FLUE SYSTEM SHALL BE INSTALLED IN ACCORDANCE WITH AS/NZS 2918 AND THE APPROPRIATE REQUIREMENTS OF THE RELEVANT BUILDING CODE OR CODES. WARNING: APPLIANCES INSTALLED IN ACCORDANCE WITH THIS STANDARD SHALL COMPLY WITH THE REQUIREMENTS OF AS/NZS 4013 WHERE REQUIRED BY THE REGULA- TORY AUTHORITY, I.E.

  • Page 14: Service & Maintenance Log

    WS Series Wood Burner SERVICE & MAINTENANCE LOG Date of Service Performed By Description of Service Page 14 7056-153A February 7, 2014...
  • Page 15 WS Series Wood Burner SERVICE & MAINTENANCE LOG Date of Service Performed By Description of Service Page 15 February 7, 2014 7056-153A...
  • Page 16 Please contact your Heatilator dealer with any questions or concerns. For the number of your nearest Heatilator dealer log onto www.heatilatorecochoice.com CAUTION DO NOT DISCARD THIS MANUAL Read, understand and Leave this manual with • Important operating and • • follow these instruc-...
