ViewSonic VX2245wm-1 Service Manual page 77

EXPLODED PARTS LIST (VX2245wm-1)
ViewSonic Model Number: VS11349
Rev: 1a
Serial No. Prefix: QD0
Item ViewSonic P/N
1 C-00008143
2 C-00008142
3 N/A
4 N/A
5 N/A
6 N/A
7 CB-00008015
8 C-00008144
9 N/A
10 MULTIPLE MATCH
11 N/A
12 N/A
13 N/A
14 N/A
15 HW-00008002
16 HW-00000553
18 HW-00004042
19 HW-00000553
20 N/A
21 HW-00000555
22 HW-00008003
ViewSonic Corporation
Ref. P/N
40-D012466 Cover Hinge,A220Z1-H08,LEFT
40-D012465 Cover Hinge,A220Z1-H08,RIGHT
40-D010955 Rear Assy,A220Z1-H05
PM0ZFH0R00 22"Wide,Function BOM,D-sub+DVI+Audio
40-D013832 Bezel Assy,A220Z1-H05
35-D0110238 PCBA_A220Z1-Z01-H-K2
32-D011077 FFC_15pin
40-D013541 Stand Seat Assy,A220Z1-H08
44-D009236 Backlight Unit,A220Z1
N/A Maylar
27-D008552 Lips Without Audio
35-D009418
PCBA for ,A220Z1-Z01-H,A170E2-E03-H-S6
41-D005024 Cover AD Assy
32-D009479 FFC,36pin
42-D009237
SCREW,M3,P=0.5mm,L=2.5mm,Pan Head
42A9930008
SCREW,M3,P=0.5mm,L=4mm,Pan Head
42-D000649
SCREW,M4,P=0.7mm,L=8mm,Round Head
42A9930008
SCREW,M3,P=0.5mm,L=4mm,Pan Head
42A993008 SCREW,M3,P=0.5mm,L=5mm,Pan Head
42A9930014 SCREW,M3,P=0.5mm,L=8mm,Pan Head
42A9930015 SCREW,M3,P=1.27mm,L=10mm,Pan Head
74
Description
Confidential - Do Not Copy
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
2
3
7
1
4
2
6
1
VX2245wm-1
