ViewSonic VX2245wm-1 Service Manual page 25

USB Hub Installation
Refer to the following information
Connect any USB devices via the USB ports on the ViewDock.
Windows will auto detect and install the generic Windows USB driver for USB 1.1/2.0 device operation.
You do not need to install any special drivers for the USB Hub if your OS is Windows 2000/ ME/XP.
USB hub installation guide for Windows 98SE :
Insert the included CD into the CD-ROM drive. The Autorun feature will automatically begin the installation process. Follow
the instructions on the screen to install the driver. If the setup program does not start automatically, go to "My Computer" and
double-click on the CD-ROM drive, and select "Setup.exe" from the CD.
Note: If USB device is not detected , does not work properly:
1. Double click the "System" icon in Control Panel.
2. Select the "Device Manager" tab from System Properties dialog window.
3. Select "Other devices" to see the contents.
4. Select "Unknown device" and click "Remove" button.
5. Click the "Refresh" button and system will find a new device.
ViewDockTM Connecting with iPod
Refer to the following information
1. Make sure the ViewDock power is ON.
2. Dock your iPod into the universal iPod docking station with the appropriate adapter insert.
3. The iPod LED indicator will turn on amber
4. Wait for a few seconds for the iTunes software to launch.
5. Play your favorite song with iTunes software (for all iPod models) or play music from iPod directly (excluding iPod
shuffle.)
ViewSonic Corporation
Downstream port
Connect to device
Type A female
Confidential - Do Not Copy
22
VX2245wm-1
