ViewSonic VX2245wm-1 Service Manual page 12

15 720 x 576 @ 50 Hz, 31.3 KHz
16 800 x 600 @ 56 Hz, 35.1 KHz
17 800 x 600 @ 60 Hz, 37.9 KHz
18 800 x 600 @ 72 Hz, 48.1 KHz
19 800 x 600 @ 75 Hz, 46.9 KHz
20 800 x 600 @ 85 Hz, 53.7 KHz
21 832 x 624 @ 75 Hz, 49.7 KHz
22 1024 x 768 @ 50 Hz, 39.6 KHz
23 1024 x 768 @ 60 Hz, 48.4 KHz
24 1024 x 768 @ 70 Hz, 56.5 KHz
25 1024 x 768 @ 75 Hz,
26 1024 x 768 @ 75 Hz, 60.2 KHz
27 1024 x 768 @ 85 Hz, 68.7 KHz
28 1152 x 864 @ 75 Hz, 67.5 KHz
29 1152 x 870 @ 75 Hz, 68.7 KHz
30 1280 x 768 @ 50 Hz, 39.6 KHz
31 1280 x 768 @ 60 Hz, 47.4 KHz
32 1280 x 768 @ 60 Hz, 47.8 KHz
33 1280 x 768 @ 75 Hz, 60.3 KHz
34 1280 x 768 @ 85 Hz, 68.6 KHz
35 1280 x 960 @ 50 Hz, 49.4 KHz
36 1280 x 960 @ 60 Hz, 59.7 KHz
37 1280 x 960 @ 75 Hz, 75.2 KHz
38 1280 x 1024 @ 50 Hz, 52.7 KHz
39 1280 x 1024 @ 60 Hz,
40 1280 x 1024 @ 70 Hz, 74.6 KHz
41 1280 x 1024 @ 72 Hz, 76.8 KHz
42 1280 x 1024 @ 75 Hz,
43 1360 x 768 @ 60 Hz, 47.7 KHz
44 1400 x 1050 @ 50 Hz, 54.1 KHz
45 1400 x 1050 @ 60 Hz, 64.7 KHz
46 1400 x 1050 @ 60 Hz, 65.3 KHz
47 1400 x 1050 @ 75 Hz, 82.3 KHz
48 1440 x 900 @ 60 Hz, 55.5 KHz
49 1440 x 900 @ 60 Hz, 59.9 KHz
50 1440 x 900 @ 75 Hz,
51 1600 x 1200 @ 60 Hz,
52 1680 x 1050 @ 60 Hz, 65.3 KHz
*1. Tolerance ±2KHz. (if the range dose not cover other timing mode)
≧
*2. Any timing not in the list, it should display as normal or show on "OUT OF RANGE" OSD message with blanking.
*3. The image quality of 85Hz mode might be worse than 75Hz.
Primary Presets
1680x1050 @ 60Hz
User Presets
Number of User Presets (recognized timings) Available: 10 presets total in FIFO configuration
ViewSonic Corporation
60 KHz
64 KHz
80 KHz
75 KHz
75 KHz
9
be not full screen (Still at the center),and the
information OSD shows 640x480
For Analog sync, the image vertical size image will
be not full screen (Still at the center),and the
information OSD shows 800x600
For Analog sync, Switch 1024x768@50Hz and
1280x768@50Hz by [1]+[2] short cut key (primary
= 1024x768@50Hz)
For Analog sync, Switch 1024x768@50Hz and
1280x768@50Hz by [1]+[2] short cut key (primary
= 1024x768@50Hz)
For Analog sync, Switch 1024x768@75Hz and
1280x768@75Hz by [1]+[2] short cut key (primary
= 1024x768@75Hz)
For Analog sync, Switch 1024x768@85Hz and
1280x768@85Hz by [1]+[2] short cut key (primary
= 1024x768@85Hz)
For analog sync,, Switch 1400x1050@60Hz and
1680x1050@60Hz by [1]+[2] short cut key
(primary = 1680x1050@60Hz)
For analog sync,, Switch 1400x1050@60Hz and
1680x1050@60Hz by [1]+[2] short cut key
(primary = 1680x1050@60Hz)
Confidential - Do Not Copy
VX2245wm-1
