ViewSonic VX2245wm-1 Service Manual page 63

22” color tft lcd display

Table of Contents

6.Change New OSD Board

Step 1 :

Place New OSD Board.

Step 2 :

Insert Audio cable to connectors of New OSD Board.

Step 3:

Completed.

7. Add Cover to AD PCB Heatsink

Step 1 :

Join the PCB Cover.

Step 2 :

Fasten 4 fixed screws.

ViewSonic Corporation

Confidential - Do Not Copy

VX2245wm-1
