7. Recommended Spare Parts List

ViewSonic Model Number:VS11349
Rev: 1a
Serial No. Prefix: QD0
Item
1 Accessories:
2 PC Board Assembly:
3
4
5 Cabinets:
6
7
8
9
10 Cables:
11
12
13
14
15 Documentation:
16
17
19 Hardware:
20
21
22
23
24
25
26 Miscellaneous:
27
28 Packing Material:
29
30
31
32
Plastics:
Remark 1: Above listed items are examples, supplier can expand the rows to add more necessary items.
Remark 2:
ViewSonic Corporation
RECOMMENDED SPARE PARTS LIST (VX2245wm-1)
Description
Power Cord,LP-53 & VCTF 0.75mm^2 3C
Power Supply Board (Lips W/ Audio Vo.7)
Main Board Rev.04
PCBA Rev.02,ODM
Front Panel (Bezel)
Back Cover
Cover Hinge - Right
Cover Hinge - Left
Base Assembly - (Stand Seat Assy)
DVI Cable, S/L, 1.8M, W/2F
Audio Cable (Accessory Black, 28AWG)
Accessory Cable,D-Sub, (30AWG)
Flat Cable (FFC 36 Pins)
Flat Cable (FFC 15 Pins)
Safety Label - 149 mmx29 mm
Carton Label - 76.2 mmx76.2 mm
CD-Rom
Screw, 3,P=0.5 mm,L=4 mm,Pan Head
Screw, 3,P=0.5 mm,L=4 mm,Pan Head
Screw,M3*P0.5*6,Steel
Screw, M4, P=0.7 mm, L=8 mm Round Head
Screw, 4,P=0 mm,L=11.8 mm,Hexagon Stand Off,Socket
Screw, M3,P=0.5 mm,L=2.5 mm
Screw, M3,P=1.27 mm,L=10 mm
Tape Security, OPP,L900xW50x0.045mm
Decoration Plate
PE Bag,600 mmx650 mmx0.13 mm
Foam - (Left)
Foam - (Right)
Craft Box
Panel Cover (Panel Protector Film)
All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by
ViewSonic Corporation. This is to eliminate repeated cross checks of each item between this version and prior versions.
ECR/ECN ViewSonic P/N
A-00005071
B-00008026
B-00008027
B-00008028
C-00008041
C-00008042
C-00008142
C-00008143
C-00008144
CB-00002083
CB-00005678
CB-00005851
CB-00008014
CB-00008015
DC-00008137
DC-00008138
DC-00008139
HW-00000553
HW-00000553
HW-00000555
HW-00004042
HW-00006041
HW-00008002
HW-00008003
M-00000560
M-00008031
P-00008033
P-00008139
P-00008140
P-00008141
PL-00008008
Confidential - Do Not Copy
71
Ref. P/N Universal number#
32-D002330
27-D009542
35-D010627
35-D010238
40-D010959
40-D010948
40-D012465
40-D012466
40-D013541
32F0000004
32F2818011
32-D002132
32-D008479
32-D011077
77-D013049
77-D013048
76-D013047
42A9930008
42A9930008
42A9930014
42-D000649
42A9940007
42-D009237
42A9930015
7345511002
40-D013544
78-D009624
78-D013535
78-D013545
78-D013534
73-D009538
VX2245wm-1
