Instruments
Configuration menu structure
Read more about this display mode
System
Information
on the next page
Language
Settings
Bleep
Engine
Engine series
Settings
Display
Units
System
Demo
Com Viewer
Prog. tx
About
38
(8 available)
ON, OFF
PORT, STARBOARD
Engine
TWIN, SINGLE
Speed
D1/D2, >D2
Speed
GLOBAL, LOCAL
Graph interval
Speed
Distance
Oil pressure
Turbo pressure
Feul consumption
Temperature
Volume
Depth (std distance)
Menu
vice technicians
Set display contrast
Press button 5 (furthest right) to set display contrast.
Then press the appropriate buttons to adapt the le-
vels, then save the settings by pressing EXIT. The
display unit has 5 contrast settings.
Configuration menu (button 5)
(depressed for longer than 3 s)
The configuration menu is used to:
- access the display mode SYSTEM INFORMA-
TION.
- do various settings for the display.
- reach information and functions for servicing the
display.
Please refer to the configuration menu structure below
and read the following section, which explains each
section in the menu.
Note! The port engine or both engines must have the
ignition switched on when display settings are chan-
ged.
[2500 rpm: 9000 r/min] in stages of 500 rpm
On, off
[10 KNOT: 100 KNOT] in stages of 10 (in appropriate units)
2MIN, 10MIN, 30MIN, 60MIN, 2 H, 4 H, 8 H
Knots, mph, km/hr
NM, Miles, km
kPa, psi
kPa, psi
Liter/hr, Gal(US)/hr, IGal/hr
degrees C, degrees F
Liter, Gal(US), Imperial Gallons
m, ft
is for ser-
SYSTEM
The menu is
UNITS
only available if
LOCAL
has been selected in
the menu SETTINGS
