  • Page 1 OPERATOR’S MANUAL...

  • Page 2: Proposition 65 Warning

    This operator’s manual is also available in the following languages: Diese Betriebsanleitung ist auch auf Denne instruktionsbog kan bestilles Deutsch erhältlich. på dansk. Ein Bestellcoupon ist am Ende der Be- Bestillingskupon findes i slutningen af instruk- triebsanleitung zu finden. tionsbogen. Ce manuel d’instructions peut être Tämän ohjekirjan voi tilata myös suo- commandé...
  • Page 3 Please pay attention to the safety instructions contained in the manual. As owner of a Volvo Penta marine engine, we would also like to welcome you to a worldwide network of dealers and service workshops to assist you with technical advice, service require- ments and replacement parts.

  • Page 4: Table Of Contents

    Low speed ............46 Trolling ..............47 Propeller shaft brake ........... 48 Extra equipment ..........49 © 006 AB VOLVO PENTA We reserve the right to make modifications without prior notice. Printed on environmentally compatible paper. (Cover: Department of transport (shipping), license 9809095)

  • Page 5: Safety Information

    If there is still something which is unclear or if you feel un- sure about it, please contact your Volvo Penta dealer for assistance. This symbol is used in the instruction book and on the product, to call your attention to the fact that this is safety information.

  • Page 6: Boat Trips

    Safety information Safety advice for boat operation Manoeuvring Your new boat Read the instruction books and other information Avoid sudden or surprising rudder movements and carefully, which came with your new boat. Learn to gear shifting. There is a risk that passengers could handle the engine, controls and other equipment in a fall over, or overboard.
  • Page 7 Safety information Carbon monoxide poisoning When a boat moves forwards, an area of low pres- Most modern boats are designed so that the problem sure air forms behind the boat. In adverse conditions, of low-pressure suction is very rare, however. If low- this low pressure can be so strong that the boat’s pressure suction does occur anyway, do not open own exhaust fumes are sucked into the cockpit or...

  • Page 8: Care And Maintenance

    Never do a job if you are not entirely sure about how to Store oil and fuel soaked rags and other flammable do it. Contact a Volvo Penta dealer for assistance ins- material in a fire-proof manner. Oil soaked rags can tead.

  • Page 9: Fuel System

    Safety information Hot surfaces and fluids Fuel system A hot engine always offers the risk of burns. Be on Always protect your hands when searching for leaks. your guard against hot surfaces, such as the ex- Fluids which leak under pressure can force their way haust manifold, turbocharger, sump, charge air pipe, into body tissue and cause severe injury.

  • Page 10: Introduction

    Introduction This instruction book has been prepared to give you the greatest possible benefit from your Volvo Penta marine engine. It contains the information you need to be able to operate and maintain the engine safely and correctly. Please read the instruction book carefully and learn to handle the engine, controls and other equipment in a safe manner before you cast off on your maiden voyage.

  • Page 11: Certified Engines

    If this is not done, AB Volvo Penta may fully or partly refuse to honour its warranty undertakings. Please contact your Volvo Penta dealer if you have not received a Warranty and Service book, or...

  • Page 12: Identification Number

    Introduction Identification numbers There are type plates on the engine and transmission, marked with identification numbers. This information must always be used a reference when service and spare parts are ordered. You will probably find similar plates on your boat and its equipment. Note this information below, make a copy of the page and store it in a safe place, so that you can have the information available if the boat is stolen.

  • Page 13: Presentation

    Presentation The D1D-C MH is an in-line, direct injection 6-cylinder marine diesel engine. The engine has electronically controlled fuel injection, a turbocharger, aftercooler, heat exchanger and thermo- statically controlled freshwater cooling, electronically controlled engine speed control and shifting. The exhaust manifold and turbocharger are freshwater cooled to reduce heat radiation to the engine room Technical description Engine and cylinder block Lubrication system...
  • Page 14 Presentation D12D-C MH 1. Alternator . Expansion tank 3. Level glass, coolant 4. Coolant filler cap 5. Charge air cooler (located beneath cover) 6. Air filter 7. Oil cooler, reverse gear 8. Crankcase breather filters 9. Heat exchanger 10. Control unit (located behind heat exchanger) 11.

  • Page 15: Instruments

    Instruments This chapter describes the instrument and control panels sold by Volvo Penta for your engine. If you want to supplement the instrumentation, or if your boat is equipped with instruments not described here, or you are not sure about their function, please contact your Volvo Penta dealer.

  • Page 16: Alarm Display (Optional Extra)

    Instruments Alarm display (optional extra) The following warning lamps should never light up during operation. On the other hand, the warning lamps light up when the starter key is first turned to the drive position. Check that all lamps function. When the engine has started, all lamps should have gone out.
  • Page 17 Instruments Battery (orange indication) The battery lamp lights up if the alternator is not charging. Stop the engine if this lamp lights up during operation. If the lamp lights up, this can be due to a fault in the electrical system or because the alterna- tor drive belt is slack.
  • Page 18 Instruments Coolant level (orange indication) The coolant lamp lights up when the coolant level is too low. Check coolant level. Please refer to “Maintenan- ce: Lubrication system”. Please refer to the “If something happens” chapter, and you will find detailed information about recom- mended action in the “Diagnostic function”...

  • Page 19: Evc Control Panel

    Instruments EVC control panel The control panel is used in combination with the EVC system tachometer. The tachometer display shows oper- ating information and menus that can be navigated from the control panel. Tachometer display selection (twin installa- Activation button tion, port or starboard tachometer) Used to activate and lock the control panel and helm- Is used to select which of the engines menu systems...

  • Page 20: Evc System Tachometer

    Instruments EVC System Tachometer Introduction Volvo Penta EVC System Tachometer presents rel- evant boat and engine information to the helmsman. Information is presented on a display in the tachom- eter. Information is depending on engine model, number of sensors and type of accessories.
  • Page 21 Instruments Trip menu (extra optional) In the TRIP MENU the user gets trip information from the EVC System and the user is allowed to select which view that should be presented in the EVC System Tachometers MAIN MENU as trip information. To get trip infor- mation following are required: Multisensor or NMEA 0183/NMEA 000 compatible component (plotter, GPS, paddle wheel etc) NMEA 0183/NMEA 000 compatible component (plotter, GPS, paddle wheel etc)
  • Page 22 Instruments Gauges menu In GAUGES MENU the user gets information from analogue senders, placed on the engine. If the data is not available the parameter will not be displayed. When in GAUGES MENU, select view by turning NAVIGATION WHEEL. To select view as favorite, push NAVI- GATION WHEEL.
  • Page 23 Instruments Settings menu In the SETTINGS MENU the user is allowed to set various options for the EVC system and to calibrate various parameters. IMPORTANT! For all settings and calibration procedures: Activate helm station by pushing the ACTIVA- TION BUTTON. NOTE! For twin installations always perform the settings on the port side system.
  • Page 24 Instruments Depth alarm (extra optional) All depth alarm functions are accessed through this menu. A multisensor needs to be installed. DEPTH ALARM, ON/OFF Depth alarm can be switched ON/OFF. SET DEPTH Adjust the depth alarm value by turning the NAVIGA- TION WHEEL.
  • Page 25 Instruments Select units and language Choose which units and languages to display. NOTE! Language and unit settings must be performed in all EVC system tachometers. US or METRIC 1. Activate helm station by pushing the ACTIVATION BUTTON. . Select SETTINGS from MAIN MENU by turn- ing NAVIGATION WHEEL.
  • Page 26 There are two possible calibration methods for the fuel tank. One approximative, FULL TANK CALIBRATION, and one more precise, FUEL MULTIPOINT CALIBRATION. A fuel level sender need to be installed. NOTE! If FUEL TANK CALIBRATION is not shown in SETTINGS MENU, please contact your Volvo Penta dealer. FUEL MULTIPOINT CALIBRATION...
  • Page 27 Instruments FUEL FULL TANK CALIBRATION When FUEL FULL TANK CALIBRATION is selected, the fuel level sender is calibrated in one step. This only gives an approximated value of the fuel level. Therefore all trip data concerning and based on, remaining fuel volume should be recognized as ap- proximated values only.

  • Page 28: Speed Factor

    Instruments Speed factor The speed factor for the boat´s paddle wheel speed sensor can be adjusted at a resolution of 1% and is used by the EVC to apply a correction to the output from the speed sensor. Set speed factor Set speed factor while driving the boat.

  • Page 29: Evc System Display (Optional Extra)

    Instruments EVC System Display (extra optional) Introduction Volvo Penta EVC system display is an instrument which displays operating information about the engi- ne and allows you to communicate with the engine’s electrical system. Operation information is shown on an LCD display.
  • Page 30 Instruments Start image This is the starting image that is shown on the display for a brief period after starting. If the unit gives a constant audible warning after star- ting, the self-test has failed. The unit will still work, but may behave in an unexpected manner.
  • Page 31 Instruments Set display contrast Press button 5 (furthest right) to set display contrast. Then press the appropriate buttons to adapt the le- vels, then save the settings by pressing EXIT. The display unit has 5 contrast settings. Configuration menu (button 5) (depressed for longer than 3 s) The configuration menu is used to: access the display mode SYSTEM INFORMA-...
  • Page 32 Instruments Display mode System Information SYSTEM INFORMATION is a display mode that functions in the same way as the display in the tacho- meter (EVC System Tachometer). You navigate round these functions, using the buttons on the free-stan- ding control panel. In display mode SYSTEM INFORMATION there are several functions: - Display of operating information, information mes-...
  • Page 33 Eeprom: No. of writes to the EEPROM Vers: Software version number Chk: Flash memory checksum Part no: Volvo’s part number for the software Source: Shows the source of the received data Label: Label allocated on the bus. Each unit on...
  • Page 34 Instruments Display mode Engine (Button 1) This display mode shows the engine speed and boat speed in the form of standard instruments, together with a trip computer and fuel level gauge. The fuel level gauge are displayed if there is a tank sender installed.
  • Page 35 Instruments Display mode Multi (button 2) This display mode shows operating information in four different windows (see below). The user can choose the operating information to be displayed in each window. The information can be displayed as figures or as standard instruments.
  • Page 36 Instruments Display mode Trip (button 3) This display mode shows: - Fuel used after last zeroing - Instantaneous fuel consumption (amount of fuel used per hour) (If speed information is available, instantaneous fuel consumption can also be cal- culated in relation to distance.) - Operation time after last zeroing - Total operating time (can not be zeroed) Figure for single engine installation...

  • Page 37: Controls

    Controls This chapter describes the instrument panels sold by Volvo Penta for your engine. If your boat is equipped with controls which are not described here and you feel uncertain about the function, please contact the dealer you purchased the boat from.

  • Page 38: Friction Brake

    Controls Friction brake The control is also equipped with a friction brake which can be adjusted for easier or stiffer lever movement as necessary. Friction brake adjustment: 1. Stop the engine. . Move the control lever forwards to make the groove in the control lever hub accessible.

  • Page 39: Two Lever Control

    Controls Two lever control. Mechanical Operation The two lever control has separate levers for shifting (1) and speed control (). The control has a neutral position switch that only al- lows the engine to be started with the reversing gear in neutral.

  • Page 40: Starting The Engine

    Starting the engine Make it a habit to give the engine and engine bay a visual check before starting. This will help you to discover quickly if anything abnormal has happened, or is about to happen. Also check that instruments and warning dis- plays show normal values after you have started the engine.

  • Page 41: Starting Method

    Starting the engine Starting method Put the reversing gear in neutral Put the reversing gear in neutral by moving the con- trol lever(s) to neutral at all control positions. Two lever control: Also check that the engine speed lever is in the idling position. Turn the ignition on Turn the starter key to position I to switch the ignition on.

  • Page 42: Start The Engine

    Starting the engine Start the engine Start using the ignition switch Turn the key to position III. Release the key and let it key spring back to position I as soon as the engine has started. NOTE! If repeated start attempts are needed, the key must be turned back to position 0 first.

  • Page 43: Operation

    Operation Learn to handle the engine, controls and other equipment in a safe and correct manner before you cast off on your maiden voyage. Remember to avoid sudden or surprising rudder movements and gear shifting. There is a risk that passengers could fall over, or overboard. WARNING! A rotating propeller can cause severe injury.

  • Page 44: Alarm

    If the engine does not reach the full throttle range, this could be caused by a number of factors which are noted in the “Fault tracing” chapter. If the engine speed exceeds the full throttle range, select a coar- ser pitch propeller. Ask your Volvo Penta dealer for advice.

  • Page 45: Synchronising Engine Speed

    Operation Synchronizing engine speed When driving with twin engines, both the operating economy and comfort will be increased when the engines are operating at the same engine speed (rpm). When the synchronization function is activated, the engine speed (rpm) of the starboard engine is au- tomatically adjusted to that of the port engine.
  • Page 46 This function must be enabled to permit the control panel to be changed during operation. The function can only be enabled by authorized Volvo Penta per- sonnel. Please contact your Volvo Penta dealer. 1. Press the activation button (1) to unlock the sys- tem.

  • Page 47: Operation

    Operation Operation Shifting between forward and reverse should be done at idling. Shifting at higher engine speeds can be un- comfortable for passengers and cause unnecessary stress on the stern drive/reversing gear, or cause the engine to stop. If you attempt to shift gear at an excessive engine speed, a safety function cuts in automatically, and delays shifting until engine speed has fallen to 1000 rpm.

  • Page 48: Low Speed

    Operation Lowspeed (option) The Lowspeed function is only available for engines with hydralic reverse gear. For boats with powerful engines, where the boat speed at idle is too high, Lowspeed is used to reduce boat speed by reducing propeller rpm - compared to normal at engine idle speed.

  • Page 49: Trolling

    Operation Trolling (option) The Trolling function is only available for engines with hydralic reverse gear. Trolling requires two control levers, one for throttle/ gear, and the other to control the slip function. Trolling makes it possible to use higher engine power without increasing boat speed.

  • Page 50: Propeller Shaft Brake

    Operation Propeller shaft brake In certain conditions, the propeller can make the pro- peller shaft rotate when the engine is stopped. This parasitic rotation is uncomfortable, and can damage the reversing gear since its oil pump, which is driven by the input shaft, is stationary together with the engine.

  • Page 51: Extra Equipment

    Operation Extra equipment Disengageable clutch The clutch is disengaged when the lever is in position (N) and engaged in position (F) IMPORTANT! The engine speed must not ex- ceed 800 rprm when engaging and disengaging. The clutch should be given extra attention during the first period of operation.

  • Page 52: Stopping The Engine

    Stopping the engine Allow the engine to idle (in neutral) for at least three minutes after the end of your journey. This evens out the temperatures inside the engine, and stops after-boiling. IMPORTANT! The above is particularly important if the engine has been driven at high speed and/or hea- vily loaded.

  • Page 53: Cold Weather Precautions

    Stopping the engie Cold weather precautions If the engine bay can not be kept frost-free, the sea- water system must be drained and the freshwater system coolant must have enough anti-freeze to pre- vent frost damage. Please refer to the “Seawater sys- tem”...

  • Page 54: Maintenance Schedule

    Maintenance schedule General information Your Volvo Penta engine and its equipment are designed for high reliability and long life. They are built to withstand a marine environment, but also to have the smallest possible environmental impact. If given preventive maintenance, according to the maintenance schedule, and if Volvo Penta original spares are used, these quali- ties are retained and unnecessary malfunctions can be avoided.
  • Page 55 Maintenance schedule Every 250 hours / at least every 12 months Fuel pre-filter (twin filter). Inspection ............... page 74 ● Only applies to the double filter: Check the pressure gauge and change the filter as necessary every 1000 hours of operation, or at least once every 1 months. Every 500 hours / at least every 12 months Crankcase ventilation.

  • Page 56: Maintenance

    Maintenance This chapter contains general technical information and instructions for carrying out the specified maintenance points. Read them carefully before starting work. The times when maintenance points need to be attended to are given in the previous chapter: Maintenance schedule WARNING! Read through the safety advice for care and maintenance work in the Safety information chapter before you start work.
  • Page 57 Maintenance. Engine, general Crankcase ventilation. Changing the filter If oil and air begin to find their way out of the over- pressure valve (), change the filters (1) earlier than recommended. IMPORTANT! Change both filters at the same time. 1. Remove the old filters by unscrewing them anti- clockwise.

  • Page 58: Drive Belts Inspection/Adjustment

    Maintenance. Engine, general Drive belts. Inspection/adjustment WARNING! Stop the engine before doing any maintenance work. General information Check belt tension and condition regularly. A belt which is to tense can damage the bearings and a belt which is too loose can slip. IMPORTANT! Always change a belt which looks worn or cracked (belts which operate in pairs must be changed together).

  • Page 59: Lubrication System

    If sulphur content is > 1.0% by weight, use oil with TBN > 15. ACEA E7 has replaced ACEA E5, but if available ACEA E5 can be used. ACEA E3 can be replaced by ACEA E4, E5 or E7. = Volvo Drain Specification ACEA = Association des Constructeurs Européenne d’Automobiles...
  • Page 60 Maintenance. Lubrication system Oil level. Checking and filling The oil level must be inside the marked area on the dipstick (1) and should be checked daily before the first start. Top up the oil through the filling hole on the side of the engine () .
  • Page 61 Maintenance. Lubrication system Switchable oil filters IMPORTANT! Though possible, the switchable filters should not be replaced during engine ope- ration other than in case of an emergency 1. Clean the filter bracket. . Disconnect the left filter by turning the lever to the right-hand end position.
  • Page 62 Maintenance. Lubrication system Oil filter and bypass filter. Change Change the oil filter and bypass filter during each oil change. Remember to hand the old filters in to a re-cycling sta- tion. WARNING! Hot oil and hot surfaces can cause burns.

  • Page 63: Freshwater System

    The coolant should contain ethylene glycol of a good quality with a suitable chemical consistency for an ade- quate protection of the engine. Using anti-corrosion aditive exclusively is not permitted in Volvo Penta’s engines. Never use water by itself as coolant.

  • Page 64: Water Quality

    (18°F). (Using 60 % glycol lowers the freezing point to -54 °C (-65°F)). Never mix more than 60 % con- centrate (Volvo Penta Coolant) in the cooling liquid, this will give reduced cooling effect and increase the risk of overheating, and will give reduced freezing protection.
  • Page 65 Maintenance. Freshwater system Coolant level. Inspection Note. Coolant level can be checked through a level glass on top of the expansion tank. The green float must be visible in the level glass. WARNING! Never open the pressure cap when the engine is hot. Steam or hot coolant can spray out at the same time as the pressure which has built up is lost.
  • Page 66 Maintenance. Freshwater system 4. Fill up with coolant via the filling hole on the ex- pansion tank. Fill slowly, to allow the air which is forced out a chance to flow out of the vent tap(s) and filling hole. 5. Close the vent tap(s) as and when air-free coo- lant flows out.
  • Page 67 Maintenance. Freshwater system Freshwater system. Flushing The cooling system should be flushed when the cool- ant is changed, to avoid loss of cooling performance due to deposits in the cooling system. 1. Drain the coolant, as in the description on the previous page.

  • Page 68: Seawater System

    Maintenance. Seawater system Seawater system The seawater system is the engine’s external cooling system. The seawater system sucks in water through the seawater inlet and pumps it through the heat exchanger and the reverse gear oil cooler. The system is protected from galvanic corrosion by means of zinc anodes located in the heat exchanger and the reverse gear oil cooler.
  • Page 69 Maintenance. Seawater system Zinc anodes. Check/change WARNING! Risk of water entry. Close the sea cock before doing any work on the seawater system. 1. Close the sea cock. . Open the drain tap (1) on the reverse gear oil cooler, and the tap () on the heat exchanger, and drain off the seawater.
  • Page 70 Maintenance. Seawater system Impeller. Check/change WARNING! Risk of water entry. Close the sea cock before doing any work on the seawater system. 1. Remove the seawater pump lid, and pull the im- peller out with water pump pliers. . Check the impeller. If any cracks or other defects are visible, the impeller must be changed.
  • Page 71 Maintenance. Seawater system Inlet manifold. Checking the drain hole Water can condense in the aftercooler during opera- tion. The condensate is drained via a hose connected to a nipple under the rear of the inlet manifold. Check that the nipple is not blocked. WARNING! If a large amount of water flows out of the drain hole, from the inlet manifold, the af- tercooler must be removed and proof tested.

  • Page 72: Fuel System

    Maintenance. Fuel system Fuel system Only use the grades of fuel recommended in the fuel specification, see Technical Data. Always observe the greatest cleanliness during re-fuelling and work on the fuel system. All work on the unit injectors of the engine must be carried out by an authorised workshop. WARNING! Fire hazard.

  • Page 73: Fuel Filter

    Maintenance. Fuel system Fuel filter Drain WARNING! Hot fuel can cause burns. Stationary engine: 1. Put a suitable vessel underneath the filter. . Open the tap (1) and drain water and contamina- tion from the water trap () by pumping with the hand pump (3) until clean fuel flows out.
  • Page 74 Maintenance. Fuel system Change the filter elements Stationary engine: (Single and switchable filters) 1. Close the fuel valve/valves. . Clean the filter bracket and put a suitable vessel under the filter. 3. Relieve pressure inside the filter by first opening the drain tap (1) at the bottom of the water trap and then the venting nipple () to drain the filter of fuel.
  • Page 75 Maintenance. Fuel system Change the filter elements Running engine (switchable filters only): WARNING! Hot fuel can cause burns. 1. Clean the filter bracket and put a suitable vessel under the filter. . Remove the protective cap from the venting nipp- le (1) on the filter bracket.
  • Page 76 Maintenance. Fuel system Fuel pre-filter The fuel pre-filter supplied by Volvo Penta is available in single and twin versions. Fuel pre-filter. Inspection This filter is equipped with a pressure gauge (1) which indicates when it is time to change the filter insert.
  • Page 77 Maintenance. Fuel system Change the filter elements If the engine is not running close the fuel cocks on the tank before changing filters. If the engine is run- ning cut off the flow of fuel with the handle (1) on the filter itself.

  • Page 78: Electrical System

    IMPORTANT! Never disconnect the current with the main switches when the engine is running. Electrical connections Check that electrical connections are dry, free from oxide and that they are securely tightened. Spray these connections as necessary with water-repellent spray (Volvo Penta universal oil).
  • Page 79 Maintenance. Electrical system Batteries. Maintenance WARNING! Fire and explosion hazard. Batter- ies must never be exposed to open flames or sparks. WARNING! Never confuse the positive and negative poles on the batteries. Risk of arcing and explosion. WARNING! Battery electrolyte is highly corro- sive.
  • Page 80 Maintenance. Electrical system Batteries. Charging WARNING! Explosion risk! Hydrogen is given off when batteries are charged. This forms an explosive mixture with air. A short circuit, open flame or spark could cause a violent explosion. Ventilate well. WARNING! Battery electrolyte is highly corro- sive.

  • Page 81: Electrical Installations

    Maintenance. Electrical system Electric welding Remove the positive and negative cables from the batteries. Then disconnect all cables connected to the alternator. Also undo the two connectors for the EVC system from the control unit. Press the lock tab down and pull the connector out.
  • Page 82 Maintenance. Electrical system 3. Protective earth cables for radio, navigation equipment, rudder, bathing steps etc., or other equipment which uses protective earthing, shall be connected to a common earthing point which is not connected to the engine or reverse gear. IMPORTANT! The engine and reverse gear must never be used as earth planes.

  • Page 83: Reverse Gear

    Maintenance. Reverse gear Reverse gear Oil level. Checking and filling Inspection Check the oil level when the reverse gear has reached operating temperature, with the engine idling and the control lever in neutral. WARNING! Working with, or going close to a running engine is a safety risk.
  • Page 84 Maintenance. Reverse gear Oil. Change 1. Remove the dipstick. Connect a hose from the oil scavenging pump to the dipstick tube. . Suck the oil up and put the dipstick back. 3. Fill up with oil to the correct level. Oil grade and vol- ume: Please refer to the “Technical Data”...

  • Page 85: Accessoties

    Maintenance: Accessories Accessories Disengageable clutch. Adjusting Stop the engine and put the clutch lever in neutral. Remove the inspection hatch and turn the clutch until the locking device on the adjusting ring is accessible. The locking devices have slightly different appearanc- es depending on the make (see illustrations).

  • Page 86: Laying Up/Launching

    Before the boat is taken out of service for a long period of time, an authorised Volvo Penta workshop should over the engine and other equipment. Have any faults and deficiencies attended to, so that the equipment is in order, ready for the next start.

  • Page 87: Bringing Out Of Storage

    Laying up/Launching Bringing out of storage Remove any covers from the engine, air inlet and ● Insert the impeller in the seawater pump, using a ● exhaust pipe. rotating movement (anti-clockwise). Top the engine up with the correct grade of oil, if ●...

  • Page 88: In Case Of Emergency

    In case of emergency Despite regular maintenance according to the maintenance schedule and perfect operation, it may occur that a fault occurs which must be attended to before the boat can travel further. This chapter contains tips for rectifying some of the possible faults. There are safety functions which are activated when certain faults occur, to protect the engine.

  • Page 89: Emergency Shifting

    In case of emergency Emergency shifting If a fault occurs which prevents the revers gear from being operated (shifted) with the control lever, it is possible to shift manually, using the description be- low. Note. The descriptions refer to electrically shifted revers gear.

  • Page 90: Fault-Tracing

    A number of symptoms and possible causes of engine malfunctions are described in the table below. Always contact your Volvo Penta dealer if problems occur which you can not solve by yourself. WARNING! Read through the safety advice for care and maintenance work in the “Safety information”...

  • Page 91: Diagnostic Function

    In case of emergency Diagnostic function The diagnostic function monitors and checks that the engine, stern drive/reverse gear and EVC system function normally. The diagnostic function has the following tasks: Discover and localize malfunctions ● Notify that malfunctions have been discovered ●...
  • Page 92 In case of emergency Malfunction message engine and EVC- system If the diagnostic function discovers a malfunction, it warns the driver by showing pop-ups in the tachome- ter display and the buzzer will sound. Pop-ups will alternate between “cause of fault” and “measures to take”.

  • Page 93: Faults List

    In case of emergency Faults list A faults list can be viewed from the MAIN MENU, if a fault is registered. When in MAIN MENU, select FAULTS by pushing NAVIGATION WHEEL. Number after FAULTS indica- tes number of faults stored in faults list. Show faults in faults list by turning NAVIGATION WHEEL.

  • Page 94: Fault Register

    Empty the water trap underneath the fuel filters, please refer to Please refer to “Maintenance: Fuel system”. • Please contact a Volvo Penta workshop if the fault remains. Seawater pressure Explanation: Seawater pressure too low. Reaction: Engine power is reduced.
  • Page 95 Check coolant level. Please refer to "Maintenance: Freshwater system". • Check that no leakage occurs in auxiliary equipment connected to the engine cooling system. • Please contact a Volvo Penta workshop if the fault remains. Coolant pressure Explanation: Coolant pressure too low. Reaction: Engine power is reduced. Action: •...
  • Page 96 Open the fuel taps and check that no leakage occurs. • Check that the fuel filters are not blocked. Please refer to “Maintenance: Fuel system” • Please contact a Volvo Penta workshop if the fault remains. Fuel temperature Explanation: Fuel temperature too high. Reaction: Engine power is reduced. Action: •...
  • Page 97 Check that the oil filters are not blocked. Please refer to "Maintenance: Lubrication system". • Check that no leakage occurs. • Please contact a Volvo Penta workshop if the fault remains. Engine oil filter Explanation: Oil pressure differential too big. Reaction: Engine power is reduced. Action: •...
  • Page 98 Action: • Check battery fluid level. • Check belt tension. • Please contact a Volvo Penta workshop if the fault remains. Auxiliary stop Explanation: External stop signal. Reaction: Engine stops or can not be started Action: • Check emergency stop button. Reset if necessary. Please refer to "Stopping the engine: Emergency stop"...
  • Page 99 If the engine can not be operated from the chosen control panel, use an alternative control panel. • Please contact a Volvo Penta workshop if the fault remains. Lever calibration Explanation: Incorrect lever calibration. Reaction: It is not possible to choose active helm station.
  • Page 100 Fault register System failure Explanation: Miscellaneous fault. Reaction: Action: • Restart engine(s). • Please contact a Volvo Penta workshop if the fault remains. Check joystick Explanation: Fault in joystick. Reaction: Engine power is reduced. Action: • Restart engine(s). • If the engine can not be operated from the chosen control panel, use an alternative control panel.
  • Page 101 Reaction: Engine power is reduced on both sides. No steering. Action: • Restart both engines. • Please contact a Volvo Penta workshop if the fault remains. No gear/throttle and steering Explanation: Fault in steering system. Reaction: No steering. No propulsion. Action: •...

  • Page 102: Technical Data

    Technical data Engine model Engine model ............D12-300 D12-350 D12-400 Crankshaft power @ 1800 rpm, kW (hp) ... 16 (94) 56 (348) 94 (400) Max. torque @ 1000 rpm, Nm (lbf.ft) ....1461 (1078) Max. torque @ 100 rpm, Nm (lbf.ft) ....

  • Page 103: Lubricating System

    Technical data Lubricating system Oil capacity including oil filters, approx., no engine inclination ......... 56 liters (11.6 US gals) Oil pressure, hot engine, at normal running rpm ........400–550 kPa (57–80 psi) at idling rpm (min.) ........... 175 kPa (5.3 psi) Oil grade ..............

  • Page 104: Reverse Gear

    Technical data Reverse gear Twin Disc Type designation MG5114SC MG5114DC Oil capacity, approx..........13 liters (3.4 US gals) 19,7 liters (5. US gals) Oil grade (in accordance with API system) ....CC, CD, CE CC, CD, CE Viscosity at oil temperature 66–85°C ...... SAE30* SAE30* Viscosity at oil temperature 85–100°C ....
  • Page 105 Notes ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 106 ✂ Yes please, I would like an operator’s manual in English at no charge. Publication number: 7746214 Post or fax this coupon to: Document & Distribution Center Name Order Department ARU , Dept. 6460 Address SE-405 08 Göteborg Sweden Fax: +46 31 545 77 Orders can also be placed via the Internet: http://www.volvopenta.com/...
  • Page 107 ✂ Sí gracias, deseo recibir gratuitamente un libro de instrucciones en español. Número de publicación: 7746218 Franquear o enviar fax a: Document & Distribution Center Nombre Order Department ARU , Dept. 6460 Dirección SE-405 08 Göteborg Suecia Fax: +46 31 545 77 El pedido puede hacerse tam- bién por internet: http://www.volvopenta.com/...
  • Page 108 ✂ Ja graag, Ik wil kosteloos een instructieboek in het Nederlands ontvangen. Publicatienummer: 7746224 Stuur of fax de coupon naar: Document & Distribution Center Naam Order Department ARU , Dept. 6460 Adres SE-405 08 Göteborg Zweden Fax: +46 31 545 77 U kunt ook bestellen via internet: http://www.volvopenta.com/...
  • Page 109 ✂ Sim, obrigado(a)! Gostaria de receber gratuitamente um manual de instruções em português. Número de publicação: 7746225 Envie o talão pelo correio ou um fax para: Nome Document & Distribution Center Order Department Endereço ARU , Dept. 6460 SE-405 08 Göteborg Sweden Fax: +46 31 545 77 A encomenda também pode...
  • Page 110 ✂ Evet lütfen, ücretsiz Türkçe kullaným el kitabý istiyorum Bu kuponu þu adrese posta- Yayýn numarasý: 7746227 layýn veya fakslayýn: Ýsim Dokument & Distribution center Ordermottagningen Adres ARU , Avd. 6460 SE-405 08 Göteborg Ýsveç Faks: +46 31 545 77 Sipariþler Ýnternet üzerinden de verilebilir: Ülke...
