Backside
1
Fig. 2
2
3 4
5
6 7 8 9
10 11 12 13
1) Locking Mechanism (Hex key 8mm separately available, ordercode SPHK016)
2) Powercon
3) Automatic Fuse 10A
4) Earth/Ground
5) ON/OFF
6) LCD Display
7) Mode Button
8) Up Button
9) Down Button
10) DMX signal connector (IN) 5-pin
11) DMX signal connector (IN) 3-pin
12) DMX signal connector (OUT) 5-pin
13) DMX signal connector (OUT) 3-pin
7
