Model No. HRCCEL18011.0
Serial No.
USER'S MANUAL
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts
are damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-888-936-4266
Mon.–Fri. 7:30 until 16:30 ET
(excluding holidays)
OR E-MAIL US:
customerservice@iconcanada.ca
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H 92E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Healthrider H 92E

Summary of Contents for Healthrider H 92E

  • Page 1 Model No. HRCCEL18011.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, PLEASE CONTACT OUR CUSTOMER SERVICE DEPARTMENT DIRECTLY. CALL TOLL-FREE: 1-888-936-4266 Mon.–Fri.

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decal(s) may (inside the frame covers) not be shown at actual size. 258865 HEALTHRIDER is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this HEALTHRIDER H 92 E elliptical. The H 92 E elliptical manual. To help us assist you, note the product model ®...

  • Page 5: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts of the elliptical in a cleared area and remove the packing mate- rials. Do not dispose of the packing materials until assembly is completed. In addition to the included tool(s), assembly requires a Phillips screwdriver , an adjustable wrench , and a rubber mallet...
  • Page 6 1. Have a second person hold the Folding Frame (2) to prevent the elliptical from tipping until this step is completed. Attach the Rear Stabilizer (4) to the Folding Frame (2) with two M10 x 95mm Screws (100). Handle Next, hold the handle on the Rear Stabilizer (4), press the Latch Button (67), and unfold the ellip- tical so that the Rear Stabilizer is resting on the floor.
  • Page 7 3. Orient the Upright (5) and the Top Cover (27) as shown, and slide the Top Cover upward onto the Wire Tie Upright. Have a second person hold the Upright (5) and the Top Cover (27) near the Main Frame (1). Avoid pinching the Locate the wire tie in the Upright (5).
  • Page 8 5. Identify the Right Pedal (14), the Right Gel Pad (55), and the Right Pedal Arm (12), which are marked with “Right” stickers, and orient them as shown. Set the Right Gel Pad (55) on the Right Pedal Arm (12). Then, set the Right Pedal (14) on the Right Gel Pad.
  • Page 9 7. Press the Ramp Cover (131) downward onto the Ramp (130). 8. Identify the Right Link Arm (43), which is marked with an “R” sticker. Orient the Right Link Arm as shown. Apply grease to the axle on the Right Pedal Arm (12).
  • Page 10 9. Identify the Right Upper Body Arm (8), which is marked with a “Right” sticker, and orient it as shown. Avoid pinching the Right Grip Wire (45) Have a second person hold the Right Upper Body Arm (8) near the Right Upper Body Leg (6). Locate the wire tie in the right side of the Upright (5).
  • Page 11 11. Attach the Front Upright Cover (24) to the Upright (5) with four M4 x 16mm Screws (106). 12. Attach the Rear Upright Cover (25) around the Upright (5) by pressing the tabs on the Rear Upright Cover into the Front Upright Cover (24). 13.

  • Page 12: The Chest Heart Rate Monitor

    THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR • Do not expose the heart rate monitor to direct sun- light for extended periods of time; do not expose it to The heart rate temperatures above 122° F (50° C) or below 14° F monitor consists of (-10°...

  • Page 13: How To Use The Elliptical

    HOW TO USE THE ELLIPTICAL HOW TO PLUG IN THE POWER CORD box cover is grounded before using an adapter. The temporary adapter should be used only until This product must be grounded. If it should malfunc- a properly grounded outlet can be installed by a qualified electrician.
  • Page 14 HOW TO MOVE THE ELLIPTICAL HOW TO EXERCISE ON THE ELLIPTICAL To move the elliptical, first fold it as described on page To mount the elliptical, hold the upper body arms or the 13. Next, stand in front of the elliptical, hold the upright, handlebars and step onto the pedal that is in the lowest and place one foot against one of the wheels.
  • Page 15 CONSOLE DIAGRAM FEATURES OF THE CONSOLE With the iFit Live mode, you can download personal- ized workouts, create your own workouts, track your workout results, and access many other features. See The advanced console offers an array of features www.iFit.com for complete information. To pur- designed to make your workouts more effective and enjoyable.
  • Page 16 HOW TO TURN ON THE POWER 3. Change the resistance of the pedals and the incline of the ramp as desired. IMPORTANT: If the elliptical has been exposed to cold temperatures, allow it to warm to room tem- As you pedal, change the resistance of the pedals perature before you turn on the power.
  • Page 17 Resistance—This display mode will show the When your pulse is detected, your heart rate will resistance level of the pedals for a few seconds appear in the display. For the most accurate heart each time the resistance level changes. rate reading, hold the contacts for at least 15 seconds.
  • Page 18 HOW TO USE A PRESET WORKOUT When the first segment of the workout ends, the resistance level, ramp incline, and the target rpm 1. Begin pedaling or press any button on the for the second segment will appear in the display console to turn on the console.
  • Page 19 HOW TO USE THE IFIT TRAINING MODE Next, press the play button on your MP3 player or CD player. Adjust the volume level using the volume The optional iFit Live module allows the console to control on your MP3 player or CD player or press the communicate with your wireless network and unlocks Volume Increase and Decrease buttons on the console.

  • Page 20: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING HOW TO ADJUST THE REED SWITCH Inspect and tighten all parts of the elliptical regularly. Replace any worn parts immediately. If the console does not display correct feedback, the To clean the elliptical, use a damp cloth and a small reed switch should be adjusted.
  • Page 21 HOW TO ADJUST THE DRIVE BELT Using the flat screwdriver, release the tabs on the Access Cover (20), and lift the Access Cover off the elliptical. Then, remove the seven indicated M4 x If you can feel the pedals slip while you are pedaling, 16mm Screws (106), and remove the Left Shield (19).

  • Page 22: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 23: Part List

    PART LIST Model No. HRCCEL18011.0 R0312A Key No. Qty. Description Key No. Qty. Description Main Frame Large Latch Spring Folding Frame Latch Insert Front Stabilizer Long Latch Spring Rear Stabilizer Leg Bearing Assembly Upright Right Gel Pad Right Upper Body Leg Small Axle Cover Left Upper Body Leg Upright Bushing...
  • Page 24 Key No. Qty. Description Key No. Qty. Description Small Snap Ring Chest Strap M8 x 16mm Screw Ramp M8 Split Washer Ramp Cover Left Grip Wire Ramp Bushing Pulse Wire Ramp Axle M4 x 16mm Screw Lift Motor M10 x 25mm Screw Lift Motor Stop M10 x 32mm Washer Ramp Roller...

  • Page 25: Exploded Drawing

    EXPLODED DRAWING A Model No. HRCCEL18011.0 R0312A...
  • Page 26 EXPLODED DRAWING B Model No. HRCCEL18011.0 R0312A...
  • Page 27 EXPLODED DRAWING C Model No. HRCCEL18011.0 R0312A...

  • Page 28: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) • the name of the product (see the front cover of this manual) • t he key number and description of the replacement part(s) (see the PART LIST and the EXPLODED DRAWING near the end of this manual) LIMITED WARRANTY ICON of Canada, Inc.
