HyperWare Restaurant Software
Quick Reference Card
T7Plus with SPOS 09A
Note: Printing a second receipt, the customer receipt, is an option for all transactions.
Terminal Display
SWIPE CUSTOMER CARD
ENTER SERVER NUMBER
BASE AMOUNT $0.00
TIP AMOUNT $0.00
TOTAL CORRECT? $0.00
COMMS
RESPONSE
Approval 123456
Terminal Display
SWIPE CUSTOMER CARD
SWIPE CUSTOMER CARD
ENTER SERVER NUMBER
BASE AMOUNT $0.00
TIP AMOUNT $0.00
Waiting for PIN
COMMS
RESPONSE
Approval 123456
Terminal Display
SWIPE CUSTOMER CARD
SWIPE CUSTOMER CARD
ENTER SERVER NUMBER
AMOUNT $0.00
COMMS
RESPONSE
Approval 123456
Terminal Display
SWIPE CUSTOMER CARD
SWIPE CUSTOMER CARD
ENTER SERVER NUMBER
AMOUNT $0.00
Waiting for PIN
COMMS
RESPONSE
Approval 123456
Server Sign-On
Terminal Display
SWIPE CUSTOMER CARD
ENTER SERVER NUMBER
SIGN-ON? Y or N
TRANSACTION ACCEPTED
Credit Sale
Action
Swipe credit card through card reader.
Enter Server number, press ENTER.
Enter amount of sale, press ENTER.
Enter Tip amount, press ENTER;
or just press ENTER and complete tip adjust later.
Press YES to confirm, NO to change amount.
Terminal dials host.
Approval number is displayed on screen, and printed on
receipt.
Debit Sale
Action
Press Debit button.
Swipe card through card reader.
Enter Server number, press ENTER.
Enter amount of sale, press ENTER.
Enter Tip amount, press ENTER.
Customer enters PIN on attached PIN Pad.
Terminal dials host.
Approval number is displayed on screen, and printed on
receipt.
Credit Refund
Action
Press Refund button.
Swipe card through card reader.
Enter server number, press ENTER.
Enter amount of refund, press ENTER.
Terminal dials host.
Approval number is displayed on screen, and printed on
receipt.
Debit Refund
Action
Press Debit and Refund buttons.
Swipe card through card reader.
Enter server number, press ENTER.
Enter amount of refund, press ENTER.
Customer enters PIN on attached PIN Pad.
Terminal dials host.
Approval number is displayed on screen, and printed on
receipt.
Action
Press Function, 77, then ENTER.
Enter Server ID, press ENTER.
Touch YES to add this Server ID to terminal.
Server Sign-On is complete.
HyperWare
Terminal Display
SWIPE CUSTOMER CARD
1–OPEN 2–CLOSE 3–PRINT
SWIPE CUSTOMER CARD
ENTER SERVER NUMBER
BASE AMOUNT $0.00
TOTAL CORRECT? $0.00
COMMS
RESPONSE
Approval 123456
Terminal Display
SWIPE CUSTOMER CARD
1–OPEN 2–CLOSE 3–PRINT
PRESS HERE FOR MENU
ENTER INVOICE NUMBER
CORRECT?
TOTAL CORRECT? $0.00
TRANSACTION ACCEPTED
Terminal Display
SWIPE CUSTOMER CARD
ENTER INVOICE NUMBER
BASE AMOUNT $0.00
ENTER TIP $0.00
TOTAL CORRECT? $0.00
TRANSACTION ACCEPTED
Terminal Display
SWIPE CUSTOMER CARD
ENTER INVOICE NUMBER
XXXXXX $00.00.
CORRECT? YES or NO
COMMS
TRANSACTION ACCEPTED
Reprint Last Receipt
Terminal Display
SWIPE CUSTOMER CARD
1-MERCHANT RECPT
2-CUSTOMER RECPT
REPRINT COMPLETE
2851 West Kathleen Road • Phoenix, AZ 85053
602.504.5000 • 877.HYPERCOM within USA • Fax: 602.866.5380
e-mail: info@hypercom.com • web: www.hypercom.com
© Hypercom Corporation, 2004. Printed in the United States of America
940365-009, rev. D
®
Restaurant Software
Open Tab
Action
Press Function, 20, then ENTER.
Press 1, then ENTER to open a Tab.
Swipe credit card through card reader.
Enter Server number, press ENTER.
Enter amount of sale, press ENTER.
Touch YES to confirm adjusted total amount.
Terminal dials host.
Approval number is displayed on screen, and printed on
receipt.
Close Tab
Action
Press Function, 20, then ENTER.
Press 2, then ENTER to close a Tab.
Touch Menu Bar at top of screen.
Enter invoice number of Open Tab, press ENTER.
Touch YES if this is correct Invoice Number.
Touch YES to confirm, NO to change amount.
Close Tab is complete.
Tip Adjust
Action
Press Adjust button.
Enter invoice number of original sale, press ENTER.
Enter tip amount, press ENTER.
Touch YES to confirm adjusted total amount.
Tip Adjust is complete.
Void
Action
Press Void button.
Enter invoice number, press ENTER.
Press YES to void this transaction. Touch NO if this is
not correct invoice number.
Terminal dials host.
Void is complete.
Action
Press Function, 72, then ENTER.
Press 1 to reprint MERCHANT RECEIPT or
press 2 to reprint CUSTOMER RECEIPT, then ENTER.
Receipt is printed.
