OPERATION AFTER ASSEMBLY
Fig. 20
1. Connect two wires from Mother board to the Backrest (Fig. 20)
2. Plug the power cord to the machine (Fig. 21)
3. Connect the remote to the DB9 port on the back of chair as indicated by back label (Fig. 21)
4. Turn on the power switch on the back (Switch to I position)
5. Use the remote to choose the massage functions and enjoy the comfortable massage
6. For MP3 music player function, please insert an SD card with MP3 music files to the back of the remote (Fig. 22). SD
card is not included.
7. For earphone, please insert the earphone to the audio socket as indicated on the back panel of chair
For a more gentle massage, a gentle massage pad is included. Place the pad as shown in photo to
the massage chair back cushion (Fig. 23)
Fig. 21
Gentle Massage Pad
Fig. 23
Fig. 22
