2. Align armrest to the perfect position with chair frame, and then match the couple axle between armrest and backrest. Finally,
once aligned tighten with provided tool as shown in (Fig. 6 and Fig. 7).
Fig. 6
Tighten by hand the knob
screw handle as shown in
next photo.
Two armrest axis
Washer and nut
Install axis in the chute, use
the hex screw and washer to
tighten with tool provided
Fig. 7
