Luraco iRobotics 6 User Manual page 11

3. Connect the air pipes (Fig. 8) and power wire (Fig. 9) to chair body carefully and completely.
Fig. 8 Fig. 9
4. Repeat procedures 1. 2. and 3. for the armrest assembly on other side.
Step 6: Assemble cushion and pillow
1. Connect two air pipes of the back cushion as shown in Fig. 10 and Fig. 11. These two air pipes are for Head massage.
Back Cushion
Fig. 10 Fig. 11
2. Place the backrest cushion via Velcro. First remove Velcro covers (Fig. 12) and then line up Velcro to seat cushion (Fig. 13)
Fig. 12 Fig. 13
11
