Summary of Contents for Luraco iROBOTICS 9 Series
- Page 2 Massage Chair. We know from experience that you will soon be telling your friends and family about the health benefits of using a massage chair at home, and how enjoyable and easy it is to operate the Luraco i9 Medical Massage Chair.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Page # INTRODUCTION II. IMPORTANT SAFETY INSTRUCTIONS 1. When using any electrical mechanism, basic precautions should always be followed. Read all instructions before using 2. Grounding Instructions Medical Warnings Emergency Stop Caution for User III. INSTALLATION INSTRUCTIONS Step 1: Unpack the boxes Step 2: Assemble the armrests Step 3: Insert remote control through safety loop... -
Page 4: Introduction
Please don’t be misled by 4D or 5D space advertised by other manufactures. If air, speed, or heat is considered a space dimension then Luraco i9 would be a 6D Chair. • NEW TRIPLE FOOT ROLLERS to give full toe-to-heel massage coverage along with new Achilles Heel Massage Nodes. - Page 5 Comforting acupressure-pressure-point massages and a patented advanced stretch-program. Nine pre-programmed and limitless customizable programs including True Zero-Gravity. The Luraco iRobotics 9 series is the newest and most unique chair on the market today and the only chair that qualifies as made in the USA...
-
Page 6: Important Safety Instructions
II. IMPORTANT SAFETY INSTRUCTIONS 1. When using an electrical mechanism, basic precautions should always be followed, including the following: Read all instructions before using. – WARNING To reduce the risk of burns, fire, electric shock, or injury to persons: The main power switch is marked with international symbols “O”... -
Page 7: Grounding Instructions
Doing so will void the warranty. After reading this user’s guide, if you have any questions or comments, please call 1-800-483-9930 or contact our technical support department at Support@Luraco.com or visit our website at www.LuracoChair.com for more information. -
Page 8: Medical Warnings
Fig.1: Grounding Instruction MEDICAL WARNINGS – NOT RECOMMENDED FOR: • Pregnant women • People with distorted joints, broken bones, skin infection or injury • Children under 12 years of age If you have any of the above medical issues or any other concerns, please consult your doctor before using the massage chair. -
Page 9: Caution For User
Additional Safety Precautions • Do not use more than 30 minutes per session. • Do not operate near young children or pets. • Do not move the machine during operation. • Do not place or store the chair near damp places such as swimming pools or bathrooms. - Page 10 • Do not pull the fabric forcefully or stab it with sharp objects which can result in injury or damage to the chair. • Do not move the chair on wooden floor, carpet or other easily damaged flooring. • Children and pets should not be allowed to play around chair. •...
- Page 11 Cleaning Methods • Before cleaning unplug from electrical source to avoid shock. • Clean the chair surface with neutral or mild detergent. • Use leather cleaner and leather conditioner. • Dust can be cleaned off with a damp cloth using mild detergent and let air dry.
-
Page 12: Installation Instructions
III. INSTALLATION INSTRUCTIONS Step 1: Unpack the box Carefully take out the chair main body, remote control, and armrests from the box. Note: i9 chair requires at least two people to assist with assembly. ATTENTION: Be sure no children, pets, or objects are around chair. - Page 13 Roller and Heat Electrical Connector Arm Massage Airbag Connector Wireless Power Connector (Left Arm, i9 Special Edition Only) Fig.3: Air and Electrical Connections...
-
Page 14: Step 3: Insert Remote Control Through Safety Loop
Fig.4: Armrest Installation Step 3: Insert remote control through safety loop. Plug the power cord into the back of the chair. Power is turned on/off by the switch on the back of the chair. (Switch to position “I” to turn on and position “0” to turnoff). -
Page 15: Understanding Remote Control Features
ATTENTION! BEFORE TURNING POWER ON Be sure no objects are behind the chair before reclining. Be sure power cord is plugged into the chair power inlet. 3. Power is turned on/off by a switch near power inlet (Switch to position “I” to turn on and position “0” to turn off). Use the remote to choose the massage functions. -
Page 16: Quick Instruction For Remote Main Screen
1. Quick Instructions for Main Screen • Auto: Allows user to select one of the 9 automatic massage programs. • Manual: Allows user to customize a massage profile that best fits the body needs for optimal results. After an optimized profile is created, user can save it under “Users Profile”. -
Page 17: Manual Massage Modes
• Soft Massage: Applies a very soft and gentle massage throughout the body. This mode is good for relieving headaches, muscle strains and helps improve sleep. • Quick Massage: Provides a quick 10-minute full body massage. It combines the best features of all massage modes into a short cycle. •... - Page 18 Fig.7: Manual Mode Descriptions Program is active Program is inactive NOTE: Tapping is not available on neck area for safety reasons...
-
Page 19: System Settings
5. System Settings Allows for the setup of system preferences and passcode protection (Fig.8). Note: The default passcode to unlock all features of the chair is: 1234 Fig.8: System Settings Screen... - Page 20 Fig. 9: Voice Response Selection and Sleep Setting Fig.10: Bluetooth Setting...
- Page 21 1. Go to Bluetooth setting Select Search for available Devices 3. Select - "Luraco" and pair together. If “Luraco” is not visible on the phone, reboot the chair and/or the phone 4. Play whatever you want on your Smartphone, Tablet or Laptop 5.
-
Page 22: Heat On/Off And Intensity Adjustment
6. Heat On/Off and Intensity Settings This screen allows the user to turn heat function on/off and control intensity level. There are 5 heat levels with 1 being the lowest and 5 being the warmest. Simply touch HEAT ON to start this feature except for the Health, Quick, and Shiatsu Modes where it turns on automatically. -
Page 23: Chair Adjustments
7. Chair Adjustments Allows the user to adjust the chair to their preferred position. The chair position will also be stored under user profile when saved. (Fig.14). Fig.12: Chair Adjustments... -
Page 24: Massage Intensity Adjustments
8. Intensity Adjustments This screen allows the user to manually adjust intensity settings for 6 different zones of the body. Fig.13: Intensity Adjustments... -
Page 25: User Profiles
User Profiles How to Use the Save User Feature: After chair adjustments have been made, hit “Save User,’ enter name of new user and then ‘OK. Up to 5 unique users can be saved. Fig.14: User Profile Save Screens 1 & 2 How to Use the Open Saved Users: When returning to your chair you can bypass the body scan by going to “USER’, then ‘OPEN”... -
Page 26: Special Edition Screens
Fig.15: User Profile Open Screens 1 & 2 10. i9 Special Edition Only Custom Fig.16: Customized Screens (i9 Special Edition Only) For customers who have ordered the Special Edition i9, the start screen will show the owner’s name. -
Page 27: How To Use The I9'S Unique Features
Customized package also includes: • Blood Pressure Monitor • Customized Leather Name Tag of Owner • Wireless Charging • Back Up Emergency Power NOTE: Customized chairs are returnable, but $3000 customization fees are not refundable. V. HOW TO USE I9’S UNIQUE FEATURES Fig.17: Armrest Open and Close for Easy Side Access To get into the chair, pull the knob located below the padding between seat and the armrest. -
Page 28: Helpful Tips
If you want to skip the body scan and get directly to a massage, you should first save a user profile and open it. Luraco i9 Series implements a high-speed processor and advanced embedded operating system (OS) and complex software applications. Thus, it requires system reboot sometimes for software to reset and sensors and electronics to be reinitialized. - Page 29 Health Benefits of Massage Massage is the manipulation of superficial layers of muscle and connective tissue to enhance function and promote relaxation and well-being. Peer-reviewed medical research has shown that the benefits of massage include pain relief, reduced anxiety and depression, and temporarily reduces blood pressure, heart rate, and state of anxiety.
-
Page 30: Health Care Device- Bp Monitor (Optional)
WARNING: Unplug the power cord before attempting any troubleshooting or service. Luraco iRobotics 9 Series comes with advanced state-of-the-art electronics and software technology which support self-diagnostic features to detect individual failures of critical components in the massage system. The chair has different LED indicators, which help the user to narrow down a troubleshooting failure, if any. - Page 31 Problem/Issue Possible Cause Trouble Shooting Method Reboot the chair by turning power switch on the back of the chair ALWAYS TRY Chair needs a OFF, wait at least 10 THIS FIRST reset seconds before turning it back ON Bad connection Unplug and reconnect between power power cord again...
-
Page 32: Warranty Information
Table 3: iRobotics 9 Series Specifications VIII. WARRANTY INFORMATION Introduction Luraco Health & Beauty, LLC is dedicated to offering our valued customers the best massage chair buying experience available. As part of this commitment, the company works very hard to provide customers with the best warranty plan available. -
Page 33: For Home Use
What is covered in this warranty: 1) For Home Use: • This warranty includes parts and in-home labor costs customer. covered for the first 3 years at no cost to the • This warranty includes an addition two (2) years for parts at no cost to the customer. - Page 34 (other than the product) or other economic losses. • Luraco shall not be liable for any personal injury, property, or any incidental or consequential damages of any kind resulting from malfunctions, defects, misuse, improper installation or alteration of this product.
- Page 35 Customer must obtain a return authorization number in order to ship the chair to a service center. Important Return Instructions: If you decide to return a purchased chair to Luraco Health & Beauty, LLC, please follow the steps below: A return must be coordinated by the dealer where the chair was purchased.
-
Page 36: Disclaimers
In no event shall Luraco Health & Beauty, LLC be liable for any indirect, incidental, punitive, special or consequential damages... -
Page 37: Extended Warranty Information
1-800-483-9930. You may also fill out the enclosed warranty registration card and mail with payment and a copy of your receipt to: Luraco Health & Beauty, LLC, Warranty Dept., 1140 107th Street, Arlington, Texas 76011-USA. If you have already purchased your 2- Year Extended Warranty, please register your extended warranty purchase by mailing in the warranty registration card.
