Summary of Contents for Luraco iROBOTICS 5
-
Page 2: Important Safety Instructions
19. Do not attempt to repair or adjust any electrical or mechanical functions on this unit. Doing so will void the warranty. After reading this owner’s guide, if you have any questions or comments, please call +1-817-633-1080 or contact our technical support department at support@luraco.com or visit our website at www.luraco.com for more information GROUNDING INSTRUCTIONS This product must be grounded. -
Page 3: Medical Warnings
2. This product is for use on a nominal 120V circuit, and has a grounding plug that looks like the plug illustrated in sketch A in the Figure below. Make sure that the product is connected to an outlet having the same configuration as the plug. -
Page 4: Space Requirement
DO NOT operate near young children DO NOT move the machine during operation Space requirement iRobotics 5 Overall Dimensions... -
Page 5: Caution For User
NOTE: Do not use this apparatus as a bed or fall asleep in the course of massage. Do not use more than 20 minutes, the recommended time of use is 20 minutes. Prolonged massaging may cause aches, muscle or nerve issues. (The preferred total duration of massaging within the day should be 30 minutes total or less). -
Page 6: Installation Instruction
iRobotics 5 Parts Pillow Back Rest Controller Controller Holder Arm Massage Seat Cushion Mini Tray Foot Massager Casing of Seat Frame INSTALLATION INSTRUCTION 1. Unpack the chair completely 2. Carefully take out wood brace and then raise the back gently. Fix the back to the locked upright position Wood brace... - Page 7 3. Under the chair near control box, connect both wire 1 and wire 2 to the male/female connections (Note: They can only fit in one way) (Fig. 2) 4. Zip up and affix the back pad to the backrest and match the Velcro of leg massager windshield leather and seat leather Velcro and affix in correct position (Fig.
- Page 8 7. Place seat cushion in correct position. 8. Installation of arm massage Restrictions: a. DO NOT use lubricating grease on shaft when connecting arm airbag assembly to arm rest. b. DO NOT pierce or touch airbag with needle or sharp object. c.
- Page 9 Fig. 9 Fig.10 c. Install mini-cup tray on to massage chair using three screws already inserted into support (Fig.11) Fig. 11 OPERATION AFTER ASSEMBLY 1. Plug the power cord to the machine (Fig.12) 2. Connect the remote to the DB9 port on the back of chair as indicated by back label (Fig. 12)
- Page 10 SD Card Fig. 12 Fig. 13 3. Turn on the power switch on the back (Switch to I position) 4. Use the remote to choose the massage functions and enjoy the comfortable massage 5. For MP3 music player function, please insert an SD card with MP3 music files to the back of the remote (Fig.13). SD card is not included.
-
Page 11: Understanding The Remote Control
Understanding the Remote Control Fig. 15 13 4 13 4 4 Remote Control Instructions and Button Description 0. Power/Stop: This button starts/stops the massage system. The default mode is Japanese massage. The timer for each massage session is 20 minutes. When timer is up, the chair maintains its position to avoid sleep disruption. Pressing this button will put the chair back to its initial position automatically. - Page 12 2. Manual Massage Modes: • Kneading: Turns On/Off kneading function. • Tapping: Turns On/Off tapping function. • Width: This function is available only when tapping is active. This adjusts the width of the robotic massage arm. • Combo: Turns On/Off both kneading & tapping functions simultaneously. 3.
-
Page 13: Troubleshooting Of Massage Chair
Unplug the power cord before attempting any troubleshooting or service. LURACO iRobotics 5 massage chairs come with advanced state of the art electronics and software technology which support self diagnostic features to detect the individual failure of critical components in the massage system. -
Page 14: Troubleshooting Guide
Trouble Shooting Guide Problem/Issue Possible Cause Trouble Shooting Method 1. Power switch is not turned on 1. Turn power switch (on the back) 2. Bad connection between power plug Does not work after powered and socket 2. Connect power cord again 3. -
Page 15: Maintenance Instruction
WARRANTY INFORMATION Introduction LURACO Technologies is dedicated to offering our valued customers the best massage chair buying experience available. As part of this commitment, the company works very hard to provide customers with the best warranty plan available. We guarantee that defective massage chairs will be repaired or replaced during the effective warranty period. - Page 16 5 year portion of this warranty for home use, and 6 month portion of this warranty for commercial use. • In no case will LURACO be liable for incidental or consequential damages, whether such damages are claimed on account of breach of warranty, breach of contract, negligence or strict/product liability, including without limitation, damage to property (other than the product) or other economic losses.
- Page 17 Technologies aggregate and cumulative liability towards customer for the products described herein shall be limited in accordance with the terms and conditions of commercial sale of LURACO Technologies. Right to make changes — LURACO Technologies reserves the right to make changes to information published in this document, including without limitation specifications and product descriptions, at any time and without notice.
- Page 18 THANK YOU FOR BUYING LURACO TECHNOLOGIES’ PRODUCTS LURACO TECHNOLOGIES, INC. 1132 107 STREET ARLINGTON, TX 76011, USA. TEL: +1-817-633-1080 FAX: +1-817-633-1085 WWW.LURACO.COM...
