The following manual is designed to ensure you enjoy your new World Cat for many years to come. We have made every effort to ensure you and your family are safe, enjoy the unique features of a World Cat, and continue to love the World Cat ride that no other boat company can offer.
NFORMATION 1.1 O ’ WNER ORTFOLIO To help you enjoy the many features, benefits, and accessories on your new World Cat, we have provided you with the following materials: • World Cat Owner’s Manual (model specific) • Vendor Supplied Manuals for various accessories •...
Also, you will receive an invitation to join Team World Cat and a survey to rate your purchasing experience and the initial impressions of our company.
2013 World Cat 320EC Owners Manual Chapter 2: NFORMATION Please fill out the following information and leave in this manual for reference. This information will be important for our service personnel to provide fast and accurate service. (For service call 866-485-8899 or email service@worldcat.com.)
When completing registration forms you will be asked for the Hull Identification Number (HIN). On your World Cat, the HIN is located on the starboard side of the transom. This number is unique to your boat and will be important for registering your vessel, as well as, communicating with your dealer and our service department.
This label means your World Cat is certified by the NMMA. With this tag, you are assured your fuel system, electrical system, lighting, ventilation, and steering are not only in compliance with the US Coast Guard regulations, but also meet the more stringent standards of the NMMA.
2013 World Cat 320EC Owners Manual The Refuse Act of 1899 prohibits throwing, discharging or depositing any refuse matter of any kind (including trash, garbage, oil and other liquid pollutants) into the waters of the United States. This information is provided in a pamphlet, that normally received when registering your boat.
Do not allow individuals under the age of 16 to operate the vessel. Maintain direct supervision of inexperi- enced operators. • Ensure that all passengers are safely seated while underway, and are using the hand rails World Cat has pro- vided to remain securely in their seats. •...
ATER Although your World Cat draws a small amount of water for its size, shallow water should be a concern of all boaters. To avoid this hazard, pay particular attention to navigational markers and know the area you are operating in. Be aware of tidal changes, including those that have occurred during your trip.
2013 World Cat 320EC Owners Manual 4.10.4 Reporting Accidents Federal regulations require that operators involved in an accident file a written account of the situation within 48 hours. Reports should be submitted to the State Boating Law Administrator. You can obtain forms through the USCG or local authorities (i.e.
2013 World Cat 320EC Owners Manual Chapter 5: ERFORMANCE 5.1 O VERVIEW This chapter will provide information on the performance characteristics of your catamaran; This is not a substitute for seamanship training or hands-on experience. First time boat owners should use the resources detailed in Chapter 1 to learn proper methods of boat operation.
World Cat hull give operators exceptional maneuverability in even the tightest spaces. Because of the superior tracking abilities of the World Cat hull, oversteering can present a problem, especially for owners accustomed to operating conventional boats. Conventional vessels have a tendency to lose tracking abilities in rough and following sea conditions, making constant course corrections necessary.
2013 World Cat 320EC Owners Manual OWER TEERING YSTEM IAGRAM This is a representation of a typical World Cat power steering system. The lengths of the steering hoses and pigtails will vary depending on the model. Page 5-22...
• If bubbles are still present in lines, then bleeding was not successful. Repeat entire process. 5.7 H ANDLING HARACTERISTICS World Cat’s patented Vectroflo™ hull is a semi-displacement hull, which exhibits characteristics of both planing and Page 5-23...
Planning and paying constant attention to the weather and sea conditions is paramount. If you are forced to operate in dangerous seas however, you can be confident that your World Cat, when operated properly, can handle them safely. Following are some tips on how to handle your boat in adverse sea...
Experience is the best way to determine the handling characteristics of your catamaran. Operating the boat in multiple sea conditions and under various loads will help you predict how the boat will perform in any situation. World Cat provides the following recommendations regarding the performance of your catamaran: •...
2013 World Cat 320EC Owners Manual day, your engine can experience as much as a 10 percent loss in horsepower. Although you should monitor your engines’ performance, be aware that the weather could be a major factor in your boats performance.
6.3 F YSTEM Due to the nature of the hull design, each World Cat is equipped with a port and starboard fuel system. These systems act independently, providing fuel to the engine on their respective side. Tanks are constructed of polyethylene material to prevent corrosion, and feature dual hull side vents to avoid over-pressurization of the system.
2013 World Cat 320EC Owners Manual with annual maintenance. To access the inspection ports along the gunwale, you will need to remove the cockpit bolsters by removing the screws that hold it in place. To access the screws, pull up gently on the bottom of the bolster and locate the drain grommets.
YSTEM Your World Cat is equipped with four batteries. Two of the batteries are dedicated as “cranking batteries” the third & forth bank controls the DC accessories and is commonly referred to as the “house” bank. To help maintain your batteries, a management system is installed on your boat.
2013 World Cat 320EC Owners Manual 6.5.2 Voltage Sensor Relay (VSR) The twin voltage relay sensors are integrated into the battery switch cluster. They distribute the charging output from the engine alternator to the “cranking” and “house” batteries. After starting an engine, the alternator sends electricity back to the “cranking”...
Page 32
2013 World Cat 320EC Owners Manual World Cat supplies the original batteries onboard your vessel. We use both Group 27 and Group 31 batteries. In the event of a failure, replacements must be of equal size and specifications (see below):...
IRCUIT ROTECTION All World Cat are wired using marine grade tin coated copper wire, instead of standard copper wire. Tin coated copper is manufactured to withstand the harsh saltwater environment better than standard copper, which is used for residential applications. Environmentally sealed Deutsch™ connectors are installed on all accessories located below the waterline to ensure watertight connections.
ONTROL YSTEM World Cat is equipped with a traditional switch operated DC control system. In the traditional setup, circuit protection is located above the switches on the instrument panel. A label is mounted on the control unit to advise you which breaker controls a given appliance. If a breaker trips simply push it in to reset. When possible have your dealer replace defective electrical components.
Navigational Lights Per USCG guidelines, all powered vessels must have navigational and anchor lights. Every World Cat is equipped with navigational lights at the bow, a pole light near the stern, or mast light on the hardtop. These lights must be used in accordance with USCG regulations when anchored or underway.
2013 World Cat 320EC Owners Manual The marine head is powered by the fuse panel, and has a separate control panel mounted near the head. The control panel activates the solenoid to allow for water intake and discharge. A macerator pump is incorporated into the head.
Suzuki™ packages feature a three or four piece digital gauge package (same as Yamaha™) with a tachometer for each engine, and a programmable multifunction gauge(s). World Cat setups a preliminary program at the factory, but it can be modified to suit your needs. Instructions on the operation and features of these gauges is included in your engine owner’s manual.
This chapter provides basic information for maintaining the original appearance and dependable performance of your World Cat. Although your vessel is constructed of the finest materials available, the harsh saltwater environment and other factors, including geography and usage rate, will affect its finish and function over time. It is imperative that you understand how to care for your catamaran properly.
This will help prevent marine growth, such as barnacles, which damage the gelcoat and affect performance. World Cat recommends using an epoxy barrier coat prior to boating painting a new vessel. This will help to prevent, but not eliminate, gelcoat blistering on the hull, which is not warranted by World Cat.
7.1.9 Stainless / Aluminum Stainless steel and aluminum are used throughout your vessel. World Cat uses only 316 marine grade stainless hardware and anodized aluminum to provide you with years of service; however, these metals can deteriorate and fail if improperly cared for. Upon returning, clean all hardware using a mild detergent and rinse thoroughly with fresh water.
Page 42
2013 World Cat 320EC Owners Manual • Inspect fuel system components and replace fuel/water separators. You can keep the system fuel but do not overfill, and use a fuel additive to prevent condensation. • Lubricate hinges and coat all metal surfaces with Boeshield T-9™ or other metal protector. Tighten down hardware if necessary.
(b) windshield leakage or breakage; (c) repaired or replacement components not installed by World Cat, unless installed by World Cat selling dealer in accordance with this warranty; (d) fading, chalking, blistering or cracking of any varnish, gelcoat, paint, anti-fouling coating or metallic finish; (e) tears, cracking, fading, discoloration or mildewing of curtains, cushions, tops, headliners or other fabric or upholstered items;...
Page 53
(5) years of the original date of retail sale. The transfer fee must be paid within thirty (30) days of purchase of the used boat to transfer the warranty. A copy of the bill of sale from the original owner or Authorized World Cat Dealer is required and completion of this form.
2013 World Cat 320EC Owners Manual Chapter 10: 320EC O PERATION AND CHEMATICS 10.1 O PERATION OF TANDARD QUIPMENT 10.1.1 Battery Layout and Management The 320EC is equipped with four batteries which are located in the aft rigging compartment. They can be reached using the access hatches located on the vertical wall behind the port and starboard jumpseats.
2013 World Cat 320EC Owners Manual 10.1.2 Bilge Pumps / Float Switches Your 320EC is equipped with two 1500 GPH bilge pumps and two 500 GPH bilge pumps. Each pump is connected to a float switch which automatically triggers the pump when water comes to rest in the bilge. The float switches are connected to the battery management panel and receive power from the breaker along the top of the panel.
When open, the handle will be parallel to the valve. In the closed position the handle is perpendicular to the valve (see picture below). World Cat recommends that the seacocks remain in the closed position when not in use, or when the boat is left unattended to prevent the vessel from taking on water due to a plumbing failure.
2013 World Cat 320EC Owners Manual and off as needed to maintain 45 psi. Most owners leave the pump “on” throughout the day, and use the system when necessary. On the 320EC, the raw water pump feeds the raw water fitting on the aft vertical wall of the starboard lounge, and the faucet in the bait prep sink.
2013 World Cat 320EC Owners Manual 3. Hold down the flush lever for 5 seconds to evacuate the bowl. 1.1.1.2.Normal Use Use the steps below for normal operation. 1. Fill 1/3 of the bowl with water by lifting up on the flush lever 2.
2013 World Cat 320EC Owners Manual • Connect the cordset to the boat first, by plugging it into the receptacle and tightening the trim ring. • Once these steps are completed, attach the cordset to the outlet supplied by the marina.
10.1.18 Anchor Windlass (Freefall) Your World Cat is equiped with a free-fall windlass manufactured by Simpson Lawrence™. You will receive the windlass, an anchor, anchor rope, and chain which is matched to your vessel’s size. The controls for the windlass are mounted at the helm, and the manufacturer’s instruction manual is provided, in the “Owner’s Portfolio”, detailing its...
2013 World Cat 320EC Owners Manual displayed on the LCD screen, do not attempt to start the unit. Contact your dealer and schedule a maintenance check. 5. Use the start button on the control panel to crank the generator. If the generator does not start within the first three attempts, turn the panel off and contact your dealer prior to further use.
Outriggers Outriggers enhance the fishability of your catamaran and can be a great asset when hunting a trophy catch. World Cat offers 18‘ Taco™ outriggers as an option on the 320 EC. The units are mounted on the fiberglass hardtop and operated using the handles above and outboard of the console.
2013 World Cat 320EC Owners Manual 11.2.2 Hull Wiring Diagram DASH ASSEMBLY (ACCESS IN SHOWER COMPARTMENT) COND. RELAY 14 GA WHT 14 GA GRN 14 GA BLK (AC Pump) 14 GA WHITE 14 GA GRN 14 GA BLK RIGGING RIGGING TUBE 16 GA.
2013 World Cat 320EC Owners Manual 11.2.3 Forward Deck Wiring Diagram ANCHOR ANCHOR LOCKER LT LOCKER LT 16 GA GRY 16 GA GRY ANCHOR WINDLASS 16 GA 16 GA 4 GA RED GRY/WHT GRY/WHT 14 GA ORG/BLU 14 GA ORG/YEL...
2013 World Cat 320EC Owners Manual 11.2.6 Battery Management System Diagram 24 HOUR CIRCUITS DC MAIN 50A to float switches and/or memory circuits sense sense windlass breaker windlass lead port start port stbd. stbd. stbd. battery house house start start...
2013 World Cat 320EC Owners Manual 11.2.7 Freshwater System Diagram FEEDS HEAD FAUCET FEEDS GALLEY FAUCET (ACCESS BY REMOVING (ACCESS BY REMOVING CABINET UNDER HEAD SINK) CABINET UNDER GALLEY SINK) TO MARINE HEAD WATER TANK HOT WATER (ACCESS BY REMOVING...
2013 World Cat 320EC Owners Manual Chapter 12: S PARE ARTS IST FOR ARRANTY EPAIRS Page 12-72...
Page 74
,. 0 12 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 75
,+ :2 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 76
&, 3 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 77
,. 0 12 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 78
< These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 79
< These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 80
8 3 ' > These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 81
! $ / - These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 82
& These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 83
/( > 2 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 84
; / . These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 85
" These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 86
& 2 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 87
< * 8 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 88
'> > + These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 89
&+* +,+ ? These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 90
@ .;2 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 91
3 < These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 92
/ ?!,(&2 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 93
/ = 2 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 94
/ - - 2 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 95
! $ # B / 7 2 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 96
() / ',%; B ',%;2 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 97
& These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 98
; 0 # These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 99
$ ? H ) These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 100
8 8 * These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 101
> , 2 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 102
< , + These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 103
= " 3 ,%; These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 104
/ 3 , ;2# These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 105
3 '3 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 106
/ B . B %@ '2 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 107
93 +2 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 108
93 +2 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 109
- 6 ) / These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
