Page 2
The following manual is designed to ensure you enjoy your new World Cat for many years to come. We have made every effort to ensure you and your family are safe, enjoy the unique features of a World Cat, and continue to love the World Cat ride that no other boat company can offer.
NFORMATION 1.1 O ’ WNER ORTFOLIO To help you enjoy the many features, benefits, and accessories on your new World Cat, we have provided you with the following materials: • World Cat Owner’s Manual (model specific) • Vendor Supplied Manuals for various accessories •...
Also, you will receive an invitation to join Team World Cat and a survey to rate your purchasing experience and the initial impressions of our company.
2014 World Cat 290DC Owners Manual Chapter 2: NFORMATION Please fill out the following information and leave in this manual for reference. This information will be important for our service personnel to provide fast and accurate service. (For service call 866-485-8899 or email service@worldcat.com.)
When completing registration forms you will be asked for the Hull Identification Number (HIN). On your World Cat, the HIN is located on the starboard side of the transom. This number is unique to your boat and will be important for registering your vessel, as well as, communicating with your dealer and our service department.
This label means your World Cat is certified by the NMMA. With this tag, you are assured your fuel system, electrical system, lighting, ventilation, and steering are not only in compliance with the US Coast Guard regulations, but also meet the more stringent standards of the NMMA.
2014 World Cat 290DC Owners Manual The Refuse Act of 1899 prohibits throwing, discharging or depositing any refuse matter of any kind (including trash, garbage, oil and other liquid pollutants) into the waters of the United States. This information is provided in a pamphlet, that normally received when registering your boat.
Do not allow individuals under the age of 16 to operate the vessel. Maintain direct supervision of inexperi- enced operators. • Ensure that all passengers are safely seated while underway, and are using the hand rails World Cat has pro- vided to remain securely in their seats. •...
ATER Although your World Cat draws a small amount of water for its size, shallow water should be a concern of all boaters. To avoid this hazard, pay particular attention to navigational markers and know the area you are operating in. Be aware of tidal changes, including those that have occurred during your trip.
2014 World Cat 290DC Owners Manual 4.10.4 Reporting Accidents Federal regulations require that operators involved in an accident file a written account of the situation within 48 hours. Reports should be submitted to the State Boating Law Administrator. You can obtain forms through the USCG or local authorities (i.e.
2014 World Cat 290DC Owners Manual Chapter 5: ERFORMANCE 5.1 O VERVIEW This chapter will provide information on the performance characteristics of your catamaran; This is not a substitute for seamanship training or hands-on experience. First time boat owners should use the resources detailed in Chapter 1 to learn proper methods of boat operation.
World Cat hull give operators exceptional maneuverability in even the tightest spaces. Because of the superior tracking abilities of the World Cat hull, oversteering can present a problem, especially for owners accustomed to operating conventional boats. Conventional vessels have a tendency to lose tracking abilities in rough and following sea conditions, making constant course corrections necessary.
2014 World Cat 290DC Owners Manual OWER TEERING YSTEM IAGRAM This is a representation of a typical World Cat power steering system. The lengths of the steering hoses and pigtails will vary depending on the model. Page 5-21...
2014 World Cat 290DC Owners Manual 5.6 P OWER TEERING YSTEM LEEDING NSTRUCTIONS Reference the bleeding instructions provided by the Teleflex™ owner’s manual, which is included in your “Owner’s Portfolio”. Use them in conjunction with the instructions and diagram below to bleed the steering system. This should be done annually.
Planning and paying constant attention to the weather and sea conditions is paramount. If you are forced to operate in dangerous seas however, you can be confident that your World Cat, when operated properly, can handle them safely. Following are some tips on how to handle your boat in adverse sea...
Experience is the best way to determine the handling characteristics of your catamaran. Operating the boat in multiple sea conditions and under various loads will help you predict how the boat will perform in any situation. World Cat provides the following recommendations regarding the performance of your catamaran: •...
2014 World Cat 290DC Owners Manual Improperly sized props can cause damage to your engine as a result of exceeding the maximum or minimum RPM levels. 5.8.3 Weather Conditions Barometric pressure and humidity can affect the output of your engines. For example, on an extremely hot and humid day, your engine can experience as much as a 10 percent loss in horsepower.
6.3 F YSTEM Due to the nature of the hull design, each World Cat is equipped with a port and starboard fuel system. These systems act independently, providing fuel to the engine on their respective side. Tanks are constructed of polyethylene material to prevent corrosion, and feature dual hull side vents to avoid over-pressurization of the system.
2014 World Cat 290DC Owners Manual with annual maintenance. To access the inspection ports along the gunwale, you will need to remove the cockpit bolsters by removing the screws that hold it in place. To access the screws, pull up gently on the bottom of the bolster and locate the drain grommets.
YSTEM Your World Cat is equipped with three batteries. Two of the batteries are dedicated as “cranking batteries” the third bank controls the DC accessories and is commonly referred to as the “house” bank. To help maintain your batteries, a management system is installed on your boat.
2014 World Cat 290DC Owners Manual 6.5.2 Voltage Sensor Relay (VSR) The twin voltage relay sensors are integrated into the battery switch cluster. They distribute the charging output from the engine alternator to the “cranking” and “house” batteries. After starting an engine, the alternator sends electricity back to the “cranking”...
Page 30
2014 World Cat 290DC Owners Manual World Cat supplies the original batteries onboard your vessel. We use both Group 27 and Group 31 batteries. In the even of a failure, replacements must be of equal size and specifications (see below):...
IRCUIT ROTECTION All World Cat are wired using marine grade tin coated copper wire, instead of standard copper wire. Tin coated copper is manufactured to withstand the harsh saltwater environment better than standard copper, which is used for residential applications. Environmentally sealed Deutsch™ connectors are installed on all accessories located below the waterline to ensure watertight connections.
ONTROL YSTEM World Cat is equipped with a traditional switch operated DC control system. In the traditional setup, circuit protection is located above the switches on the instrument panel. A label is mounted on the control unit to advise you which breaker controls a given appliance. If a breaker trips simply push it in to reset. When possible have your dealer replace defective electrical components.
Navigational Lights Per USCG guidelines, all powered vessels must have navigational and anchor lights. Every World Cat is equipped with navigational lights at the bow, a pole light near the stern, or mast light on the hardtop. These lights must be used in accordance with USCG regulations when anchored or underway.
2014 World Cat 290DC Owners Manual 6.11.13 Anchor Windlass - Freefall Use to deploy and retrieve the anchor. This accessory is controlled by a dedicated switch at the helm and can also be controled at the bow with up & down foot switches. The fuse is located at the battery management panel.
Suzuki™ packages feature a three or four piece digital gauge package (same as Yamaha™) with a tachometer for each engine, and a programmable multifunction gauge(s). World Cat setups a preliminary program at the factory, but it can be modified to suit your needs. Instructions on the operation and features of these gauges is included in your engine owner’s manual.
This chapter provides basic information for maintaining the original appearance and dependable performance of your World Cat. Although your vessel is constructed of the finest materials available, the harsh saltwater environment and other factors, including geography and usage rate, will affect its finish and function over time. It is imperative that you understand how to care for your catamaran properly.
This will help prevent marine growth, such as barnacles, which damage the gelcoat and affect performance. World Cat recommends using an epoxy barrier coat prior to boating painting a new vessel. This will help to prevent, but not eliminate, gelcoat blistering on the hull, which is not warranted by World Cat.
TAINLESS LUMINUM Stainless steel and aluminum are used throughout your vessel. World Cat uses only 316 marine grade stainless hardware and anodized aluminum to provide you with years of service; however, these metals can deteriorate and fail if improperly cared for. Upon returning, clean all hardware using a mild detergent and rinse thoroughly with fresh water.
Page 40
2014 World Cat 290DC Owners Manual • Inspect all plumbing components and connections to prevent leaks. Replace any damaged hoses. Drain all lines and devices to prevent damage from freezing. Lubricate valves to maintain proper operation. Use the manufacturers recommendations for portable and marine heads.
(b) windshield leakage or breakage; (c) repaired or replacement components not installed by World Cat, unless installed by World Cat selling dealer in accordance with this warranty; (d) fading, chalking, blistering or cracking of any varnish, gelcoat, paint, anti-fouling coating or metallic finish; (e) tears, cracking, fading, discoloration or mildewing of curtains, cushions, tops, headliners or other fabric or upholstered items;...
Page 51
(5) years of the original date of retail sale. The transfer fee must be paid within thirty (30) days of purchase of the used boat to transfer the warranty. A copy of the bill of sale from the original owner or Authorized World Cat Dealer is required and completion of this form.
Battery Layout and Management The 290DC is equipped with three batteries, which are located in the helm storage compartment. They can be reached using the access hatch located on the floor in the aft section of the starboard liner. A cranking battery is installed on each side, and a dedicated house battery is installed in the center.
Livewell System The 290DC has a 30 gallon livewell standard. It is equipped with a dual purpose livewell pump and adjustable flow regulator. The pump is located in the port bilge compartment and can be reached through the inspection port in the motorwell.
Marine Head The 290DC comes equipped with a marine head. The control panel for the head, is located in the rigging space on the outboard vertical wall. Power is supplied to this panel through a 25 amp breaker located on the DC Sub Panel in the head compartment.
10.1.9 Anchor Windlass (Freefall) World Cat provides an anchor windlass manufactured by Simpson Lawrence™. You will receive the windlass, an anchor, anchor rope, and chain which is matched to your vessel’s size. The rocker switch to control the windlass is mounted at the helm, and foot switches are installed at the windlass.
Stereo If chosen, your 290DC can be equipped with an optional stereo unit. The unit is mounted in the port head compartment. Two speakers are mounted in the forward bow area, and the remaining two are installed in the aft cockpit area.
2014 World Cat 290DC Owners Manual 10.4.5 Battery Management System Diagram port bilge stbd bilge stereo port memory bilge 16 GA RED 16 G A BRN stbd 16 G A BRN bilge 16 GA Y EL 16 GA RED accy...
2014 World Cat 290DC Owners Manual 10.4.7 Livewell / Raw Water System raw water pump (stbd seatbox cabinet) quick connect 8" Access Pl ate 6" Access Pl ate washdown fitting livewell inlet livewell drain 8" Access Pl ate 6" Access Pl ate...
2014 World Cat 290DC Owners Manual 10.4.8 Marine Head Diagram discharge hose (toilet to tank) macerator pump holding tank (15 gal) ob discharge seacock (access via inspection plate in the stbd liner floor) threaded tee deck pump-out fitting freshwater supply...
Page 66
/ 0 * 1 2 - These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 67
0 # $ These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 68
* :- These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 69
B< These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 70
( ,!- These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 71
! $ , These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 72
& - These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 73
*/ & ( These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 74
& These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 75
2 , 5( These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 76
5 4 ( These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 77
! $ # 4 + These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 78
* 7 :- These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 79
! 5 # These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 80
2 , 5( These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 81
& 9 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 82
*/ & These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 83
7@ ( These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 84
* & & - These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 85
< These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 86
10 * 37%: 4 37%:- These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 87
7 : 9 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 88
" 7 : These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 89
" < These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 90
( ( . These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 91
* 7%:- These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 92
29 < These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 93
; " 2 7 : These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 94
& These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 95
7, >7C & - These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 96
7 # $ These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 97
/ !- 7 7 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
Page 98
/ !- 7 7 These parts should be installed by a certified World Cat dealer. Installation by a non-authorized 3rd party may result in improper erforcemance and create safety concerns. Please contact your local, authorized, World Cat dealer to buy these parts at the same price.
