Dear World Cat Owner:
Thank you for being our customer. Welcome aboard!
We wish to take this opportunity to sincerely thank you for putting your trust in our
boat building team and becoming the newest member of the World Cat Family.
The following manual is designed to ensure you enjoy your new World Cat for many
years to come. We have made every effort to ensure you and your family are safe,
enjoy the unique features of a World Cat, and continue to love the World Cat ride that
no other boat company can offer.
If you should ever need assistance with the care, maintenance or operation of your
boat, then please visit our website at www.worldcat.com to find contact information
for your nearest Factory Authorized Dealer.
Once again, thank you for becoming a part of our family.
Best Regards,
A
NDREW
P
RESIDENT
B
ROWN
1090 West Saint James St.
Tarboro, North Carolina 27886
Best Regards,
A
B
NNA
OSLER
C
C
R
USTOMER
ARE
EPRESENTATIVE
Advertisement
Table of Contents
Related Manuals for World Cat 2016 250cc
Summary of Contents for World Cat 2016 250cc
- Page 1 The following manual is designed to ensure you enjoy your new World Cat for many years to come. We have made every effort to ensure you and your family are safe, enjoy the unique features of a World Cat, and continue to love the World Cat ride that no other boat company can offer.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Chapter 1: Customer Information ..................p. 6 Owner’s Portfolio ......................... p. 6 Warranty Information ......................p. 6 Dealer Responsibilities ......................p. 6 Owner’s Responsibilities ....................... p. 7 Manual Legend ........................p. 7 Chapter 2: Boat Information ....................p. 8 Chapter 3: Boat Specifications .................... - Page 3 Handling Characteristics ..................... p. 21 5.7.1 Turning Characteristics ....................p. 21 5.7.2 Adverse Sea Conditions ..................... p. 21 5.7.3 Cross-Clutching – Twin Engines .................. p. 21 5.7.4 Get the boat on plane ....................p. 21 5.7.5 Keep the boat level ....................p. 22 5.7.6 Handling different sea conditions ................
- Page 4 6.10 Accessories ........................p. 32 6.10.1 Navigational Lights ....................p. 32 6.10.2 Cockpit Lights ......................p. 32 6.10.3 Cabin / Console Lights ....................p. 32 6.10.4 Spreader Lights ......................p. 32 6.10.5 Dome Light ......................p. 32 6.10.6 Bilge Pump / Float Switch ..................p. 32 6.10.7 Seacocks ........................
- Page 5 Chapter 9: Model Year 2016 Warranty Policy ..............p. 49 Chapter 10: Lewmar Deck Switch and Winch Operation ............p. 52 Chapter 11: 295CC Diagrams ..................... p. 54 10.1 Thru-Hull ........................... p. 54 10.2 Access Plate and Rigging Tube Diagram ................p. 55 10.3 Plumbing Systems Diagram ....................
-
Page 6: Chapter 1: Customer Information
Chapter 1: Customer Information 1.1 Owner’s Portfolio To help you enjoy the many features, benefits, and accessories on your new World Cat, we have provided you with the following materials: World Cat Owner’s Manual (model specific) Vendor Supplied Manuals for various accessories ... -
Page 7: Owner's Responsibilities
inspection for the vessel and engines. Once your warranty information is processed, World Cat will maintain a record of your boat using the Hull Identification Number (HIN), which is located on the starboard side of the transom. Information regarding the dealership, owner, and the factory-installed accessories will be recorded to help you should a problem arise. -
Page 8: Chapter 2: Boat Information
Chapter 2: Boat Information Please fill out the following information and leave in this manual for reference. This information will be im- portant for your Authorized Dealer to provide fast and accurate service. Visit our website at www.worldcat.com to locate your nearest dealer. BOAT Model: HIN:... - Page 10 10 10...
-
Page 11: Chapter 4: Safety And Regulations
4.1 Operator Responsibilities Prior to enjoying your World Cat, it is important to read and understand all of the information detailed in your “Owner’s Portfolio”. Knowing how to operate and maintain the systems on your vessel can make your experi- ences safe and enjoyable, as well as increase the performance and longevity of your boat. -
Page 12: Recommended Safety Equipment
This label means your World Cat is certified by the NMMA. With this tag, you are as- sured your fuel system, electrical system, lighting, ventilation, and steering are not only in compliance with the US Coast Guard regulations, but also meet the more stringent standards of the NMMA. -
Page 13: Boating Safety Guidelines
4.5.1 Oil and Hazardous Substances The Federal Water Pollution Control Act prohibits the dis- charge of oil or hazardous substances which may be harm- ful into U.S. navigable water. Vessels 26 feet in length and over must display a placard at least 5 by 8 inches, made of durable material. -
Page 14: Launching
Do not allow individuals under the age of 16 to operate the vessel. Maintain direct supervision of inexperi- enced operators. Ensure that all passengers are safely seated while underway, and are using the hand rails World Cat has provided to remain securely in their seats. -
Page 15: Anchoring
4.9 Shallow Water Although your World Cat draws a small amount of water for its size, shallow water should be a concern of all boaters. To avoid this hazard, pay particular attention to navigational markers and know the area you are operating in. -
Page 16: Communication
4.10.2 Communication If you witness an emergency or become involved in one, you should request assistance via radio communica- Sportfish, Cruisers, Yachts Owner’s Manual tion or visual signals. Review the information in Section 4 of the for detailed information on how and when to request assistance. 4.10.3 Rendering Assistance Owners are required by law to render assistance to other boaters involved in an emergency situation such as fire, collision, casualty, etc., as long as it does not endanger your vessel or its passengers. -
Page 17: Chapter 5: Performance
Chapter 5: Performance 5.1 Overview This chapter will provide information on the performance characteristics of your catamaran; this is not a sub- stitute for seamanship training or hands-on experience. First time boat owners should use the resources de- tailed in Chapter 1 to learn proper methods of boat operation. Experienced boaters who have never owned a catamaran should study this chapter completely. -
Page 18: Steering Controls - Twin Engines
World Cat hull give operators exceptional maneuverability in even the tightest spaces. Because of the superior tracking abilities of the World Cat hull, oversteering can present a problem, especially for owners accustomed to operating conventional boats. Conventional vessels have a tendency to lose track- ing abilities in rough and following sea conditions, making constant course corrections necessary. -
Page 19: Power Steering
5.6 Power Steering The power assist unit provides automobile like steering on your catamaran. The unit is installed in the con- sole between the helm and steering rams. The power for the unit is connected to the port and starboard key switch. - Page 20 SEA STAR HELM TELEFLEX POWER STEERING ASSIST PUMP HYDRAULIC STEERING HOSE (x3) PIGTAIL HOSE (x3) ALIGNMENT VALVE STEERING CYLINDER (x2)
-
Page 21: Handling Characteristics
5.7.3 Cross-Clutching – Twin Engines World Cat 295CC twin engines are mounted at a specific distance, based on the configuration of the boat, allowing you to cross-clutch (one motor in forward while one in reverse) To dock, reverse the boat into a slip: put the outside motor in reverse and turn to face aft. -
Page 22: Keep The Boat Level
Experience is the best way to determine the handling characteristics of your catamaran. Operating the boat in multiple sea conditions and under various loads will help you predict how the boat will perform in any situation. World Cat provides the following recommendations regarding the performance of your cata- maran: Establish an RPM chart which details the speed and fuel consumption at various RPM levels to achieve ... -
Page 23: Weather Conditions
5.8.3 Weather Conditions Barometric pressure and humidity can affect the output of your engines. For example, on an extremely hot and humid day, your engine can experience as much as a 10 percent loss in horsepower. Although you should monitor your engines’ performance, be aware that the weather could be a major factor in your boat’s performance. -
Page 24: Chapter 6: Systems Information
Chapter 6: Systems Information 6.1 Overview This chapter will provide you with basic information for all the systems on your boat. Understanding this in- formation is imperative, as it directly contributes to the safety and enjoyment of your trips on the water. Talk with your dealer if you need further information on any of these systems. -
Page 25: Fuel System
6.3 Fuel System Due to the nature of the hull design, your World Cat 295CC is equipped with separate port and starboard fuel systems. These systems act independently, providing fuel to the engine on their respective side. Tanks are constructed of polyethylene material to prevent corrosion. -
Page 26: Fuel Distribution System
6.3.4 Fuel Distribution System The fuel is delivered from the tank to the engine through the “Integrated Fuel Demand Valve” (IFDV), anti- siphon valve, and the fuel line. The IFDV prevents built up pressure inside the tank from being transferred to the engine, while still allowing fuel to flow to the engine for operation. -
Page 27: Troubleshooting Tips
6.3.7 Troubleshooting Tips Possible Failures Loss of prime on the engine and/or fuel starvation: Engine stalls out Engine runs lean Engine does not draw fuel properly Find possible leakage points and take corrective action: Fuel line leak from tank to engine—replace components as needed ... -
Page 28: Ethanol-Blended Fuel
6.5.1 Battery System Your World Cat is equipped with three batteries. Two of the batteries are dedicated as “cranking batteries” while the third battery, commonly referred to as the “house bank,” controls the DC accessories. To help maintain your batteries, a management system is installed on your boat. -
Page 29: Emergency Parallel
7.11 for details provided by Lewmar. 6.6 Battery Selection World Cat supplies the original batteries onboard your vessel. We use both Group 27 and Group 31 batteries. In the event of a failure, replacements must be of equal size and specifications (see below):... -
Page 30: Safety
6.7 Wiring and Circuit Protection Your World Cat is wired using marine grade tin coated copper wire instead of standard copper wire. Tin coated copper is manufactured to withstand the harsh saltwater environment better than standard copper, which is used for residential applications. -
Page 31: Control System
6.8 Control System Your World Cat is equipped with a traditional switch operated DC control system. In the traditional setup, circuit protection is located above the switches on the instrument panel. A label is mounted on the control unit to advise you which breaker controls a given appliance. If a breaker trips simply push it in to reset. -
Page 32: Accessories
6.10.1 Navigational Lights Per USCG guidelines, all powered vessels must have navigational and anchor lights. Your World Cat is equipped with navigational lights at the bow or a pole light near the stern. These lights must be used in ac- cordance with USCG regulations when anchored or underway. -
Page 33: Seacocks
When open, the handle will be parallel to the valve. In the closed position the handle is perpendicular to the valve (see picture below). World Cat recommends that the sea- cock remain in the closed position when not in use, or when the boat is left unattended to prevent the vessel from taking on water due to a plumbing failure. -
Page 34: Livewell And Livewell Pump
6.10.11 Livewell and Livewell Pump The livewell on your 295CC has a capacity of 30 gallons. It is equipped with a dual purpose livewell pump and adjustable flow regulator. The pump is located in the port bilge compartment, can be activated by a tog- gle switch on the dash switch panel, and can be reached through the inspection port in the motorwell. -
Page 35: Yamaha 300 Hp 4-Strokes W/Command Link
6.10.20 Sea Vision SV55 LED Underwater Light Package (Optional) Your World Cat offers optional Sea Vision SV55 LED surface mounted light utilizing the latest high powered LED’s. These lights are installed on the port & starboard transom and can be turned on using the corresponding switch on the master switch panel. -
Page 36: Optimus Electronic Power Steering Package
6.10.22 Optimus Electronic Power Steering Package (Optional) The Optimus Electronic Power Steering package provides increased comfort, lighter steering loads and car- like steering response when on the water. See the Optimus EPS user’s manual for additional information. FEATURES User adjustable speed sensitive helm turns, wheel effort and steering response ... -
Page 37: Optimus 360 Package
6.10.23 Optimus 360 Package (Optional) The Optimus 360 package includes Electronic Power Steering, Electronic Joystick Control System and, using state-of-the-art electronics, provides easy 360-degree maneuvering capabilities when docking, negotiating crowded areas or loading a vessel onto a trailer. See the Optimus 360 user’s manual for additional infor- mation. -
Page 38: Marine Head
6.10.24 Marine Head The marine head is powered by the fuse panel, and has a separate control pan- el mounted near the head. Water is supplied to the system from the freshwater tank; therefore, to operate the toilet the freshwater system must be pressur- ized. -
Page 39: Plumbing System
The intake and discharge of water is integral to several of the features and accessories provided on your boat, including sanitation devices and water systems. World Cat installs the plumbing components for these systems using high quality marine hoses and stainless clamps. However, this does not eliminate the need for routine checks of plumbing components or connections. -
Page 40: Chapter 7: Maintenance And Service
This chapter provides basic information for maintaining the original appearance and dependable performance of your World Cat. Although your vessel is constructed of the finest materials available, the harsh saltwater environment and other factors, including geography and usage rate, will affect its finish and function over time. -
Page 41: Repair
This will help prevent marine growth, such as barnacles, which damage the gelcoat and affect performance. World Cat recommends using an epoxy barrier coat prior to painting a new vessel. This will help to prevent, but will not eliminate, gelcoat blistering on the hull, which is not covered by the warranty. -
Page 42: Trim / Plexiglas / Polyethylene
® 7.6 Stainless / Aluminum Stainless steel and aluminum are used throughout your vessel. World Cat uses only 316 marine grade stain- less hardware and anodized aluminum to provide you with years of service; however, these metals can dete- riorate and fail if improperly cared for. Upon returning, clean all hardware using a mild detergent and rinse thoroughly with fresh water. -
Page 43: Winterization
7.9 Winterization Routine maintenance checks should be performed prior to each trip in accordance with Chapter 1, but a broader analysis should be done before winterizing your catamaran and prior to the first trip of the season. If your local climate does not require winter storage, complete the following steps at least annually to ensure the safe operation of your boat: Do not leave loose items or personal effects onboard during storage. -
Page 44: Maintenance Schedule
7.10 Maintenance Schedule Maintenance Clean hull below the waterline Bottom paint the hull Check/replace sacrificial anodes Wash boat hardware and canvas Wax exterior gelcoat Clean & protect hardware Clean exterior upholstery Clean cabin & interior upholstery Flush engines with fresh water Spray metal components in bilge Clean bilge Check bilge for leaks... -
Page 45: Maintenance Log
7.11 Maintenance Log Service Date Engine Hours Dealer Service / Repairs... -
Page 46: Chapter 8: Hurricane Preparedness
Chapter 8: Hurricane Preparedness Customer Checklist Equipment To Be Kept On Board: Chafing gear Flashlight with spare batteries Fenders Battery-operated radio Two sufficient anchors with 300’ or more oversized rode Check Monthly: Exterior lights operable Engine battery charged Auto bilge pump operating (check battery) Flashlight battery charged charged Hatches are watertight... - Page 47 Moored Boat Preparations Make Plans To Have Someone Pick You Up From Your Boat Before The Storm Arrives Strip all removable items, including spare rigging Clear self-bailing cockpit drains Close all through hull fittings Remove portable fuel and oil storage containers Remove ship papers Shut off fuel tanks Leave anchor light on...
- Page 48 Anchored Boat Preparations Make Plans To Have Someone Pick You Up From Your Boat Before The Storm Arrives Strip all removable items, including spare rigging Clear self-bailing cockpit drains Close all through-hull fittings Remove portable fuel and oil storage containers Remove ship papers Shut off fuel tanks Leave auto bilge pump on...
-
Page 49: Chapter 9: Model Year 2016 Warranty Policy
Chapter 9: Model Year 2016 Warranty Policy... -
Page 52: Chapter 10: Lewmar Deck Switch And Winch Operation
Deck Switch Advisory Overview Electric deck switches operate in a hostile environment and are subject to salt water, extremes of temperature, direct sunlight and UV effect. They are also susceptible to wear and tear following repeated use and can in some instances suffer accidental damage during boat operations. -
Page 53: Additional Information
Specific Considerations for Winch Operation Manual B2303 Issue 7 Winch Operation Please ensure that you thoroughly understand the operation and safety requirements of the winch before commencing the installation. Only persons who are completely familiar with the controls and those who have been fully made aware of the correct use of the winch should be allowed to use it. -
Page 54: Chapter 11: 295Cc Diagrams
Chapter 10: 295CC Diagrams 10.1 Thru-Hull Aft Bilge Pump Cockpit Floor Drain Overboard Discharge Holding Tank Vent Fish Box Drain Deck Floor Drain Bow Storage Box Drain Anchor Locker Rain Lip Drain Raw Water/Wash-down Storage Drain Freshwater Tank Vent Livewell Console Drain Starboard Port Side... -
Page 55: Access Plate And Rigging Tube Diagram
10.2 Access Plate and Rigging Tube Diagram... -
Page 56: Plumbing Systems Diagram
10.3 Plumbing Systems Diagram... -
Page 57: Battery Management Panel
10.7 Battery Management Panel... -
Page 58: Switch Panel Fuses
10.8 Switch Panel Fuses... -
Page 59: Wire Code
10.9 Wire Code FUNCTION COLOR GAUGE BREAKER/FUSE AMPS BREAKER/FUSE LOCATION Horn 10A Fuse Switch Panel Fuse Block Cockpit Lights 10A Fuse Switch Panel Fuse Block Fresh Water Pump 15A Fuse Switch Panel Fuse Block Raw Water Pump 15A Fuse Switch Panel Fuse Block Port Fishbox 10A Fuse Switch Panel Fuse Block... -
Page 60: Chapter 12: Spare Parts List For Non-Warranty Repairs
Chapter 12: Spare Parts List for Non-Warranty Repairs...
