- Page 1 2005 OWNER'S MANUAL...
-
Page 2: Table Of Contents
World Class Catamarans Table of Contents Customer Information ..............Chapter 1: Safety and Regulations Operator Responsibilities ............. 1-1 Registration ................. 1-1 Coast Guard Required Safety Equipment ........1-1 Recommended Safety Equipment ..........1-2 Capacity Information ..............1-2 Pollution Regulations..............1-3 Oil and Hazardous Substances..........1-3 Disposal of Plastics/Dunnage/Garbage ........1-3 Boating Safety Guidelines ............ - Page 3 World Class Catamarans Chapter 2: Performance Overview..................2-1 Motor Trim Bow Up Condition ..............2-1 Bow Down Condition..............2-1 Engine Controls................2-2 Steering Controls................. 2-2 Steering Maintenance ..............2-2 Steering System Diagram............. 2-3 Steering System Bleeding Instructions ......... 2-4 Handling Characteristics ............. 2-5 Turning Characteristics ............2-5 Adverse Sea Conditions .............2-5 Boating Tips ................
- Page 4 World Class Catamarans Chapter 3: Systems Information Overview..................3-1 Fueling Guidelines Before Fueling................3-1 During Fueling ................3-1 After Fueling ................3-1 Fuel System................. 3-2 Fuel System Diagram..............3-2 Electrical System ................. 3-3 Battery System ................3-3 Battery Distribution ..............3-3 Voltage Sensor Relay ..............3-4 Emergency Parallel..............3-4 24 Hour Circuits ...............3-4 Anchor Windlass ...............3-4...
- Page 5 World Class Catamarans Chapter 4: Maintenance and Service Overview..................4-1 Gelcoat Maintenance ..............4-1 Cleaning ...................4-1 Waxing ..................4-1 Repair ..................4-2 Bottom Paint ................4-2 Upholstery................... 4-3 Trim/Plexiglass/Polyethylene ............4-3 Stainless/Aluminum ..............4-3 Bilge Compartments ..............4-3 Cockpit Drains ................4-3 Winterization ................
-
Page 6: Customer Information
World Class Catamarans CUSTOMER INFORMATION OWNER’S PORTFOLIO To help you enjoy the many features, benefits, and accessories on your new World Cat, we have provided you with the following materials: • World Class Catamaran Owner’s Manual (model specific) • Vendor Supplied Manuals for various accessories •... - Page 7 Also, you will receive an invitation to join Team World Cat and a survey to rate your purchasing experience and the initial impressions of our company. We ask that you join our family of owners and let us know your feelings about the purchase and the quality of our product.
-
Page 8: Operator Responsibilities
When completing registration forms you will be asked for the Hull Iden- tification Number (HIN). On your World Cat, the HIN is located on the starboard side of the tran- som. This number is unique to your boat and will be important for registering your vessel, as well as, communicating with your dealer and our service department. -
Page 9: Recommended Safety Equipment
World Class Catamarans RECOMMENDED SAFETY EQUIPMENT Although not required, there are several additional items which help to ensure safety, and provide convenience for you and passengers. A list of these items can be found in the Sportfish, Cruisers, Yachts Owner’s Manual on page 18. Perform an annual inventory to keep tools, spare parts, and safety equipment in good condition. -
Page 10: Pollution Regulations
World Class Catamarans POLLUTION REGULATIONS The Refuse Act of 1899 prohibits throwing, discharging or depositing any refuse matter of any kind (including trash, garbage, oil and other liquid pollutants) into the waters of the United States. This information is provided in a pamphlet, that normally received when registering your boat. -
Page 11: Boating Safety Guidelines
World Class Catamarans BOATING SAFETY GUIDELINES As an owner/operator you should be prepared to handle any situation which arises before departure, while underway, or upon return to dock. Careful planning will add safety and plea- sure to your experience and give you the confidence to handle emergencies if they develop. Listed below are some general guidelines which you should follow before any trip: PRE-DEPARTURE: •... -
Page 12: Returning
SHALLOW WATER Although your World Cat draws a small amount of water for its size, shallow water should be a concern of all boaters. To avoid this hazard, pay particular attention to navigational markers and know the area you are operating in. -
Page 13: Emergency Situations
World Class Catamarans EMERGENCY SITUATIONS Unfortunately, even the safest boating practices cannot eliminate the potential of emergency situations developing. Therefore you should prepare yourself, and your crew, to handle any problems that may arise. Establish specific plans for fires, man overboard, collision, etc., and review them with your passengers prior to departing. -
Page 14: Carbon Monoxide
World Class Catamarans CARBON MONOXIDE (CO) ! DANGER Carbon Monoxide (CO) is a colorless, odorless, and tasteless gas produced by the exhaust system of any combustible engine. CO can cause brain damage or death, if inhaled over an extended period of time. To protect yourself and your passengers, never block the ventilation outlets in cabins, consoles, or other enclosed spaces. -
Page 15: Chapter 2: Performance
World Class Catamarans CHAPTER 2 PERFORMANCE OVERVIEW This chapter will provide information on the performance characteristics of your catamaran; This is not a substitute for seamanship training or hands-on experience. First time boat owners should use the resources detailed in Chapter 1 to learn proper methods of boat operation. Expe- rienced boaters who have never owned a catamaran, should study this chapter completely. -
Page 16: Engine Controls
World Class hull give operators excep- tional maneuverability in even the tightest spaces. Because of the superior tracking abilities of the World Cat hull, oversteering can present a problem, especially for owners accustomed to operating conventional boats. Conventional ves- sels have a tendency to lose tracking abilities in rough and following sea conditions, making constant course corrections necessary. -
Page 17: Steering System Diagram
World Class Catamarans STEERING SYSTEM DIAGRAM THIS IS A REPRESENTATION OF A TYPICAL WORLD CAT STEERING SYSTEM. THE LENGTHS OF THE STEERING HOSES AND PIGTAILS WILL VARY DEPENDING ON THE MODEL YOU HAVE. ITEM QUANTITY DESCRIPTION SEA STAR II HELM KEVLAR STEERING HOSE STEERING SYSTEM VALVE KEVLAR PIGTAIL 4’−6’... -
Page 18: Steering System Bleeding Instructions
World Class Catamarans STEERING SYSTEM - BLEEDING INSTRUCTIONS Reference the bleeding instructions provided by the Teleflex™ owner’s manual, which is included in your “Owner’s Portfolio”. Use them in conjunction with the instructions and diagram below to bleed the steering system. This should be done annually. NOTICE If possible, have your dealer or trained marine technician perform routine mainte- nance or repairs on your steering system. -
Page 19: Handling Characteristics
Do not underestimate a catamaran’s cornering ability however, hard adjustments to the steering wheel can make a World Cat bite quickly and execute high performance turns. Experiment with the handling ability of your cat so you are pre- pared for any situation on the water. -
Page 20: Boating Tips
Experience is the best way to determine the handling characteristics of your catamaran. Operating the boat in multiple sea conditions and under various loads will help you predict how the boat will perform in any situation. World Cat provides the following recommendations regarding the performance of your catamaran: •... -
Page 21: Load
World Class Catamarans LOAD Increased load can obviously affect performance, especially if the load is unbalanced. Pas- sengers, gear, and fuel are all examples of things which can affect your vessel. Fuel levels change through the day, and greatly affect the attitude of your boat. When necessary, make adjustments to engine trim and load distribution to compensate for fuel usage. -
Page 22: Overview
World Class Catamarans CHAPTER 3 SYSTEMS INFORMATION OVERVIEW This chapter will provide you with basic information for all the systems on your boat. Under- standing this information is imperative, as it directly contributes to the safety and enjoyment of your trips on the water. If you need further information on any of these systems talk with your dealer. -
Page 23: Fuel System
World Class Catamarans FUEL SYSTEM Due to the nature of the hull design, each World Cat is equipped with a port and starboard fuel system. These systems act independently, providing fuel to the engine on their respective side. Tanks are constructed of polyethylene material to prevent corrosion, and feature dual hull side vents to avoid over-pressurization of the system. -
Page 24: Electrical System
BATTERY SYSTEM Your World Cat is equipped with three batteries, excluding the 330 TE which has four. Two of the batteries are dedicated as “cranking batteries”; the third bank controls the DC accessories and is commonly referred to as the “house” bank. To help maintain your batteries, a manage- ment system is installed on your boat. -
Page 25: Voltage Sensor Relay
Your dealer will install batteries prior to delivery of your World Cat. Use these guidelines, or contact your dealer, when replacements need to be made. -
Page 26: Battery Care
World Class Catamarans BATTERY CARE Batteries should be secured in a non-metallic tray and insulated boots should cover the ter- minals. Depending on the style of battery you choose, inspect the electrolyte and perform rou- tine maintenance as suggested by the manufacturer. Remove corrosion from the terminals quickly to prevent failure. -
Page 27: Wiring And Circuit Protection
When working on your electrical system, disconnect the batteries to prevent shock, or damage to your electrical system. If possible, have an electrician perform repairs. For customers unfamiliar with electrical systems, World Cat recommends the following book: Boating Magazine’s: Powerboater’s Guide to Electrical Systems... -
Page 28: Typical Digital Control Diagram
World Class Catamarans TYPICAL DIGITAL CONTROL DIAGRAM... -
Page 29: Accessories
Per USCG guidelines, all powered vessels must have navigational and anchor lights. Every World Cat is equipped with navigational lights at the bow, a pole light near the stern, or mast light on the hardtop. These lights must be used in accordance with USCG regula- tions when anchored or underway. - Page 30 World Class Catamarans LIVEWELL PUMP (ALL EXCEPT 270 LC) Supplies water to the livewell system and is activated by the switch pod. Use the button as follows: • Press one time for continuous operation, • Press two times for a 3 min. “ON” / 3 min. “OFF” cycle •...
-
Page 31: Gauge Packages
World Class Catamarans GAUGE PACKAGES World Cat provides Honda™, Suzuki™, and Yamaha™ engine packages with manufacturer supplied instrumentation. Below is a list of the standard packages and a description of their function. YAMAHA™ Yamaha™ packages feature a four piece digital gauge package with a tachometer for each engine, speedometer, and fuel management gauge. -
Page 32: Chapter 4: Maintenance And Service
OVERVIEW This chapter provides basic information for maintaining the original appearance and dependable performance of your World Cat. Although your vessel is constructed of the finest materials available, the harsh saltwater environment and other factors, including geography and usage rate, will affect its finish and function over time. It is imperative that you understand how to care for your catamaran properly. -
Page 33: Repair
This will help prevent marine growth, such as barnacles, which damage the gelcoat and affect performance. World Cat recommends using an epoxy barrier coat prior to boating painting a new vessel. This will help to prevent, but not eliminate, gelcoat blistering on the hull, which is not warranted by World Class. -
Page 34: Upholstery
World Class Catamarans UPHOLSTERY Basic Stains - Clean with a mild detergent and a soft to medium brush, or an all purpose cleaner such as Fantastic™. Rinse with fresh water after cleaning. Mildew - Use a 4 to 1 mixture of water and ammonia, brushing the stain vigorously to remove the bacteria responsible for the mildew. -
Page 35: Winterization
World Class Catamarans WINTERIZATION Routine maintenance checks should be performed prior to each trip in accordance with Chapter 1, but a broader analysis should be done before winterizing your catamaran and prior to the first trip of the season. If your local climate does not require winter storage, complete the following steps at least annually to ensure the safe operation of your boat. -
Page 36: Table Of Contents
World Class Catamarans CHAPTER 5 TABLE OF CONTENTS MODEL SPECIFICATIONS / OPTIONAL FEATURES ..... 5-2 STANDARD FEATURES ............5-3 Battery Layout and Management ............5-3 Digital Control System ............... 5-4 Bilge Pump Location / Access ............5-4 Freshwater System................5-4 Seacocks .................... -
Page 37: Model Specifications / Optional Features
World Class Catamarans MODEL SPECIFICATIONS DIMENSIONS LENGTH (W/O BOW PULPIT)..............26’ 6” LENGTH (W/ BOW PULPIT) ..............28’ BEAM (AMIDSHIPS) ................8’ 6” BEAM (TRANSOM) ................8’ 6” TRAILERING HEIGHT (KEEL TO HARDTOP)* ........10’ BRIDGE CLEARANCE (FLOAT LINE TO HARDTOP)* ......9’... -
Page 38: Standard Features
World Class Catamarans STANDARD FEATURES BATTERY LAYOUT AND MANAGEMENT The 270 SD is equipped with three batteries, which are located in the aft rigging compart- ments. They can be reached using the access hatches located on the aft transom wall beneath the livewell and fishbox. -
Page 39: Digital Control System
World Class Catamarans DIGITAL CONTROL SYSTEM Your 270 SD comes equipped with the digital control system discussed in Chapter 3 of this manual. The switch pod is located on the console forward of the helm. The control unit and accessory fuse block are mounted behind the console insert and can be accessed using the opening beneath the helm. -
Page 40: Seacocks
In the closed position the handle is perpendicular to the valve (see pic- ture below). World Cat recommends that the seacocks remain in the closed position when not in use, or when the boat is left unattended to prevent the vessel from taking on water due to a plumbing failure. -
Page 41: Raw Water System
World Class Catamarans RAW WATER SYSTEM The raw water pump is located in the aft rigging compartment on the port side, and can be accessed through the hatch located on the vertical wall beneath the livewell. The pump and wir- ing are mounted on the rigging wall at the back of the compartment. -
Page 42: Optional Features
Outriggers enhance the fishability of your catamaran and can be a great asset when hunting a trophy catch. World Cat offers 15‘ Taco™ outriggers as an option on the 270 SD. The units are mounted on the fiberglass hardtop and operated using the handles above and outboard of the console. -
Page 43: Initial Start-Up
World Class Catamarans INITIAL START UP On each trip, prior to using the head, complete the following steps: 1. Turn on the raw or freshwater system, depending on the setup in your boat. 2. Fill 1/3 of the bowl with water (by garden hose, glass, cup etc). -
Page 44: Access Plate And Rigging Tube Diagram
World Class Catamarans ACCESS PLATE AND RIGGING TUBE DIAGRAM... -
Page 45: Hull Wiring Diagram
World Class Catamarans HULL WIRING DIAGRAM TO TERMINAL STRIP (BEHIND DASH) TO BATT. MANAGEMENT PANEL 14 GA. BRN/RED (PORT FLOAT) 14 GA. BRN/RED (STBD. FLOAT) 14 GA. YELLOW (MEMORY) 5-10... -
Page 46: Deck Wiring Diagram
World Class Catamarans DECK WIRING DIAGRAM BOW LIGHT BOW LIGHT 14 GA. GRY/WHT 14 GA. GRY/WHT ANCHOR LOCKER LIGHT 14 GA. BLUE (COCKPIT CIRCUIT) COCKPIT LIGHT COCKPIT LIGHT 14 GA. BLUE 14 GA. BLUE SPEAKER (STEREO OPTION ONLY) SPEAKER (STEREO OPTION ONLY) 14 GA. -
Page 47: Battery Management System Diagram
World Class Catamarans BATTERY MANAGEMENT SYSTEM DIAGRAM 24 HOUR CIRCUITS DC MAIN 50A to float switches and/or memory circuits sense sense house port stbd. start start battery battery battery 5-12... -
Page 48: Freshwater System Diagram
World Class Catamarans FRESHWATER SYSTEM DIAGRAM 20 GAL. WATERTANK FILL/VENT COCKPIT SHOWER TO MARINE HEAD INLET RIGGING TUBE FRESHWATER PUMP 5-13... -
Page 49: Livewell / Raw Water System Diagram
World Class Catamarans LIVEWELL / RAW WATER SYSTEM RAW WATER OUTLET RAW WATER PUMP 5-14... -
Page 50: Marine Head Diagram
World Class Catamarans MARINE HEAD DIAGRAM DECK PUMP−OUT FITTING HOLDING TANK VENT DISCHARGE HOLDING HOSE TANK HEAD INLET DISCHARGE HOSE TO FRESHWATER PUMP 5-15... -
Page 51: Thru Hull Diagram
World Class Catamarans THRU HULL DIAGRAM 5-16...
