HDMI Extender over Cat5e/Cat6
CS-HDBTPOE-100 (HD BaseT)
User manual
Thank you for purchasing this product. For optimum performance and safety, please
read these instructions carefully before connecting, operating or adjusting this
product. Please keep this manual for future reference.
Advertisement
Related Manuals for Metra Electronics CS-HDBTPOE-100HDMI Extender over Cat5e/Cat6
Summary of Contents for Metra Electronics CS-HDBTPOE-100HDMI Extender over Cat5e/Cat6
- Page 1 HDMI Extender over Cat5e/Cat6 CS-HDBTPOE-100 (HD BaseT) User manual Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.
- Page 2 I. Introduction The HDMI Extender over cat5e/cat6 is a tool for extending your HDMI signal over long distances to a compatible display. It is designed to convert HDMI signal to standard HDBaseT signal and transmit by LAN cable. It also supports Transfer Bidirectional Infrared control signal together with the HDMI signal, so you can control the Source in the Display side up to 100 meters outside, also you can control the Display in the Source side up to 100 meters outside using the HDMI Extender.
- Page 3 Consumption less than 10W. Use single UTP LAN cable (CAT-5E/6) to substitute HDMI cable to achieve long distance transmission. UTP cable termination follows the standard of IEEE-568B. Transmission distance: 100 meters: 1080P @60Hz36bit; 3D1080P@30Hz36bit; 70 meters: 1080P @60Hz@48bit; 1080P @120Hz@24bit; 3D1080P@60Hz@36bit 4K x 2K@30Hz@24bit.
-
Page 4: Specifications
III. Package HDMI Extender Transmitter -------------------------------------------------------- 1PC HDMI Extender Receiver ------------------------------------------------------------ 1PC IR Transmitter -------------------------------------------------------------------------- 2PCS IR Receiver ----------------------------------------------------------------------------- 2PCS 12V2.5A DC Power Supply adapter ------------------------------------------------ 1PCS Operation Manual --------------------------------------------------------------------- 1PC IV. Specifications Frequency Bandwidth 2.97Gbps HDMI Transmitter Input/Output Ports 1x HDMI Female port/1 x CAT6 1x IR Transmitter/1x IR Receiver... - Page 5 HDMI Receiver Input/Output Ports 1 x HDMI Female port/1 x CAT6 1x IR Transmitter/1x IR Receiver Power Supply DC 12V 2.5A ESD Protection Human Body Model: ± 8kV (air-gap discharge) ± 4kV (contact discharge) Dimensions (mm) 65(W) X 100 (D) X 25 (H) Weight 200g x 2 Operating Temperature...
- Page 6 V. Operation controls and Functions Transmitter DC IN: Plug the 12V DC power supply into the unit. IR OUT: Channel 1 IR Transmitter. IR IN: Channel 2 IR Receiver. HDMI IN: HDMI Input port.
- Page 7 HDMI Signal OUT: Standard HDBaseT signal output port LINK LED: This red LED illuminates when the Transmitter and Receiver is connected with LAN cable. Receiver DC IN: Plug the 12V DC power supply into the unit. IR IN: Channel 1 IR Receiver. IR OUT: Channel 2 IR Transmitter.
- Page 8 LINK LED: This red LED illuminates when the Transmitter and Receiver is connected with LAN cable. VI. Application Example...
- Page 9 © Copyright 2014 Metra Electronics Corporation 460 Walker Street, Holly Hill, FL 32117-2699 Specifications are subject to change without notice. All trademarks are the property of their respective owners. 1.866.839.9187...
